MPLS Architecture
2
MPLS Network Model
MPLS
LSR Label Switched Router LER Label Edge
Router
3
MPLS Benefits

• Comparing MPLS with existing IP core and IP/ATM
  technologies, MPLS has many advantages and
  benefits
• The performance characteristics of layer 2
  networks
• The connectivity and network services of layer 3
  networks
• Improves the price/performance of network layer
  routing
• Improved scalability

4
MPLS Benefits (contd)

• Improves the possibilities for traffic
  engineering
• Supports the delivery of services with QoS
  guarantees
• Avoids need for coordination of IP and ATM
  address allocation and routing information

5
Necessity of L3 Forwarding

• For security
• To allow packet filtering at firewalls
• Requires examination of packet contents,
  including the IP header
• For forwarding at the initial router - used when
  hosts dont support MPLS
• For Scaling
• Forward on a finer granularity than the labels
  can provide

6
MPLS Architecture

• Down stream label assignment for unicast traffic
• On demand
• Unsolicited
• Path selection
• Hop by hop
• Explicit
• Ordered vs. independent control
• Loop detection and prevention mechanisms

7
Label Distribution Protocol (LDP)

• Set of procedures used by LSRs to establish LSPs
• Mapping between network-layer routing information
  directly to data-link layer switched paths
• LDP peers
• Two LSRs which use LDP to exchange label/stream
  mapping
• Information exchange known as LDP Session

8
LDP Messages

• Discovery messages
• Used to announce and maintain the presence of an
  LSR
• Session/Adjacency messages
• Used to establish, maintain and terminate
  sessions between LDP peers
• Advertisement messages
• Used to create, change, and delete label mappings
• Notification messages
• Used to provide advisory information and to
  signal error information

9
Forwarding Equivalence Class (FEC)

• Introduced to denote packet forwarding classes
• Comprises traffic
• To a particular destination
• To destination with distinct service requirements

10
LSP - FEC Mapping

• FEC specified as a set of two elements
• IP Address Prefix - any length from 0 32
• Host Address - 32 bit IP address
• A given packet matches a particular LSP if and
  only if IP Address Prefix FEC element matches
  packets IP destination address

11
Label Spaces

• Useful for assignment and distribution of labels
• Two types of label spaces
• Per interface label space Interface-specific
  labels used for interfaces that use interface
  resources for labels
• Per platform label space Platform-wide incoming
  labels used for interfaces that can share the
  same label space

12
LDP Discovery

• A mechanism that enables an LSR to discover
  potential LDP peers
• Avoids unnecessary explicit configuration of LSR
  label switching peers
• Two variants of the discovery mechanism
• Basic discovery mechanism used to discover LSR
  neighbors that are directly connected at the link
  level
• Extended discovery mechanism used to locate LSRs
  that are not directly connected at the link level

13
LDP Discovery (Contd)

• Basic discovery mechanism
• To engage - send LDP Hellos periodically
• LDP Hellos sent as UDP packets for all routers on
  that subnet
• Extended discovery mechanism
• To engage - send LDP targeted Hellos periodically
• Targeted Hellos are sent to a specific address
• Targeted LSR decides whether to respond or to
  ignore the targeted Hello

14
Session Establishment

• Exchange of LDP discovery Hellos triggers session
  establishment
• Two step process
• Transport connection establishment
• If LSR1 does not already have a LDP session for
  the exchange of label spaces LSR1a and LSR2b,
  it attempts to open a TCP connection with LSR2
• LSR1 determines the transport addresses at its
  end (A1) and LSR2s end (A2) of the TCP
  connection
• If A1gtA2, LSR1 plays the active role otherwise
  it is passive
• Session initialization
• Negotiate session parameters by exchanging LDP
  initialization messages

15
Label Distribution and Management

• Two label distribution techniques
• Downstream on demand label distribution
• An LSR can distribute a FEC label binding in
  response to an explicit request
• Downstream Unsolicited label distribution
• Allows an LSR to distribute label bindings to
  LSRs that have not explicitly requested them
• Both can be used in the same network at the same
  time however, each LSR must be aware of the
  distribution method used by its peer

16
Label Distribution Control Mode

• Independent Label Distribution Control
• Each LSR may advertise label mappings to its
  neighbors at any time
• Independent Downstream on Demand mode - LSR
  answers without waiting for a label mapping from
  next hop
• Independent Downstream Unsolicited mode - LSR
  advertises label mapping for a FEC whenever it is
  prepared
• Consequence upstream label can be advertised
  before a downstream label is received

17
Distribution Control Mode (contd)

• Ordered Label Distribution Control
• Initiates transmission of label mapping for a FEC
  only if it has next FEC next hop or is the egress
• If not, the LSR waits till it gets a label from
  downstream LSR
• LSR acts as an egress for a particular FEC, if
• Next hop router for FEC is outside of label
  switching network
• FEC elements are reachable by crossing a domain
  boundary

18
Label Retention Mode

• Conservative Label Retention Mode
• Advertised label mappings are retained only if
  they are used for forwarding packets
• Downstream on Demand Mode typically used with
  Conservative Label Retention Mode
• Advantage only labels required are maintained
• Disadvantage a change in routing causes delay
• Liberal Retention Mode
• All label mappings are retained regardless of
  whether LSR is next hop or not
• Faster reaction to routing changes

19
Label Information Base

• LSR maintains learned labels in Label Information
  Base (LIB)
• Each entry of LIB associates an FEC with an (LDP
  Identifier, label) pair
• When next hop changes for a FEC, LSR will
  retrieve the label for the new next hop from the
  LIB

20
Hierarchical Routing in MPLS

• External Routers A,B,C,D,E,F - Talk BGP
• Internal Routers 1,2,3,4,5,6 - Talk OSPF

Domain 2
C
D
1
Domain 3
Domain 1
6
2
3
4
5
B
F
E
A
Note Internal routers in domains 1 and 3 not
shown
21
Hierarchical Routing (contd)

• When IP packet traverses domain 2, it will
  contain two labels, encoded as a label stack
• Higher level label used between routers C and D,
  which is encapsulated inside a lower level label
  used within Domain 2
• Operation at C
• C needs to swap BGP label to put label that D
  expects
• C also needs to add an OSPF label that 1 expects
• C therefore pushes down the BGP label and adds a
  lower level label

22
Explicit Routing in MPLS

• Two options for route selection
• Hop by hop routing
• Explicit routing
• Explicit Routing (Source Routing) is a very
  powerful technique
• With pure datagram routing, overhead of carrying
  complete explicit route is prohibitive
• MPLS allows explicit route to be carried only at
  the time the LSP is setup, and not with each
  packet
• MPLS makes explicit routing practical

23
Explicit Routing (Contd)

• In an explicitly routed LSP
• LSP next hop is not chosen by the local node
• Selected by a single node, usually the ingress
• The sequence of LSRs may be chosen by
• Configuration (e.g., by an operator or by a
  centralized server)

24
Loops and Loop Handling

• Routing protocols used in conjunction with MPLS
  are based on distributed computation which may
  contain loops
• Loops handling - 3 categories
• Loop Mitigation/Survival
• Loop Detection
• Loop Prevention

25
Loop Mitigation

• Minimizes the impact of loops by limiting the
  amount of resources consumed by the loop
• Method
• Based on use of TTL field which is decremented at
  each hop
• Use of dynamic routing protocol converging
  rapidly to non-looping paths

26
Loop Detection

• Loops may be setup but they are subsequently
  detected
• The detected loop is then broken by dropping
  label relationship
• Broken loops now necessitates packets to be
  forwarded using L3 forwarding

27
Loop Detection (Contd)

• Method is based on transmitting a Loop Detection
  Control Packet (LDCP) whenever a route changes
• LDCP is forwarded towards the destination until
• Last MPLS node along the path is reached
• TTL of the LDCP expires
• It returns to the node which originated it

28
Loop Prevention

• Ensures that loops are never set up
• Labels are not used until it is sure to be loop
  free
• Methods
• Labels are propagated starting at the egress
  switch
• Use source routing to set up label bindings from
  the egress switch to each ingress switch
