Imperium Accelero 9K

1
Imperium Accelero 9K

• Group Members
• Ian Ferguson
• Nathan Liesch
• Luis Ramirez
• Mark Willson

2
Overview

• Image Processing / DSP on a FPGA
• IA9K operates on 96x64 8-bit Grayscale
  Uncompressed Bitmaps
• IA9K attempts to streamline sequential filtering
  algorithms by taking advantage of 2 memory
  controllers
• 3x3 Convolution and Linear Filters are the basis
  of the IA9K Image Processing

3
Features

• 8-bit Video Display
• RS232 Upload / Download
• LCD User Interface
• 2 LPM RAM Memory Controllers
• 3x3 Convolution Module
• Linear Filter Module

4
RS-232

• Detects data sent serially from PC and converts
  to 24-bit signal sent to RAM
• Data can be received at 9600 or 19200 baud
  depending on clock dividers
• Will only accept data inside valid RS232 packets
  by sensing start and stop bits. No parity.
• 10 second timeout

5
From SDRAM to LPM_RAM

• SDRAM
• Much more capacity (128MB)
• Pre-built SDRAM controller
• Requires a complex memory controller
• LPM_RAM
• Easy to implement
• Can be simulated
• Simple interface
• Limited capacity to 106,496 bits

6
Memory Controller

• Controls access to ram
• Developed 3 access modes
• Write
• Read (no handshake signals)
• Read (with handshake signals)
• Random access of memory is not required
• Design implements two instances of the memory
  controller

7
Display

• 96 x 64 image expanded to 576 x 384 resolution
• 8bit grayscale output
• 33MHz pixel clock

8
User Interface

• User Commands are sent via 2 push buttons (Enter
  and Select)
• Menu and Status Messages are displayed using a
  2x16 char LCD
• IA9K Modules are disabled at startup and enabled
  / disabled as needed by the User Interface
• Modules are responsible for their own
  Interactions with other modules

9
UI Control Flow
10
UI Data Flow
11
Filters

• 3x3 Shift Register
• 3x3 Convolution Calculation
• Pixel-by-Pixel Calculations
• 2 stages of buffering are used in the reading and
  writing of image data in order to achieve one
  result every clock cycle

12
Pixel-by-Pixel Manipulations

• Sequential access of pixel data
• Calculate new pixel value independently of
  surrounding pixels
• Negative Threshold

13
3x3 Shift Register

• Shift Register is large enough to store 2
  complete rows of image data plus 3 additional
  pixels

14
2D Convolver

• the heart of the system is the fully programmable
  3x3 convolver
• 8bit image data and 9bit signed coefficient
  kernel weights
• allows for a wide range of filters to be applied
• blur, sharpen, edge enhance, find edges, and
  emboss
• required significant pipelining to match rest of
  system
• uses adder trees, pipelined multipliers and
  dividers to yield one result per clock cycle

15
Java Convolution Demo
16
Summary of Filters

Light Blur Heavy Blur Edge Enhance


Original
1 1 1
1 1 1
1 1 1
1 2 1
2 4 2
1 2 1
-1 -1 -1
-1 9 -1
-1 -1 -1
Emboss Sharpen Find Edge

Images generated by GIMP
-1 0 0
0 0 0
0 0 1
-1 -2 -1
-2 16 -2
-1 -2 -1
-1 -1 -1
-1 8 -1
-1 -1 -1
17
IA9K Stats

• 7544 / 8320 (91) Logical Elements Used
• 98k / 106k (92) Memory Elements Used
• 3x3 Convolution Filter takes approx 190us
• Linear Filter takes approx 185us
• Max Simulated Frequency 50MHz
• RS232 currently runs 9600 bps

18
Questions?
From anyone other than Jason?
19
Accomplishments

• 3 forests killed
• Quad 720O synchronized rolly chair spin
• 90m 5-storey paper airplane flight
• 44254 max simulation length
• 29 Sun workstation crashes
• 1500 man-hours of work
• 24L of beer consumed
