Section III Population Ecology

1
Section III Population Ecology

• ???
• ????? Ayo
• Japalura_at_hotmail.com

2
Section Three Population Ecology

• Chap.6 Population growth (????)
• Chap.7 Physical environment (????)
• Chap.8 Competition and coexistence (?????)
• Chap.9 Mutualism (??)
• Chap.10 Predation (??)
• Chap.11 Herbivory (??)
• Chap.12 Parasitism (??)
• Chap.13 Evaluating the controls on population size

3
Chap. 6 Population Growth
Road Map

• Tabulating changes in population age structure
  through time
• Time-specific life tables
• Age-specific life tables
• Fecundity schedules and female fecundity, and
  estimating future population growth
• Population growth models
• Deterministic models
• Geometric models
• Logistic models
• Stochastic models

4
6.1 Life tables

• The construction of life tables is termed
  demography.
• Construct life tables
• Demonstrate the age structure of a population
• Time-specific life table
• Snapshot age structure at a single point in
  time (time-specific life table)
• Useful in examining long-lived animals
• Ex. Dall Mountain Sheep (Figure 6.1 and Table
  6.1)

5
Time-specific life table

• Snapshot age structure at a single point in
  time (time-specific life table)
• Useful in examining long-lived animals
• Ex. Dall Mountain Sheep (Figure 6.1 and Table 6.1)

6
Life Tables

• Useful parameters in the life tables
• x age class or interval
• nx number of survivors at beginning of age
  interval x.
• dx number of organisms dying between age
  intervals nx nx1
• lx proportion of organisms surviving to the
  beginning of age interval x ns / n0

7
Life Tables

• Useful parameters in the life tables
• qx rate of mortality between age intervals dx
  / ns
• ex the mean expectation of life for organisms
  alive at the beginning of age x
• Lx average number alive during an age class
  (nx nx1) / 2
• Tx intermediate step in determining life
  expectancy SLx
• ex Tx / nx

8
(No Transcript)
9
Fig. 6.2 Time-specific survivorship curve
3.5
3
2.5
2
n (log scale)
10
1.5
x
1
0.5
0
1
14
2
3
4
5
6
7
8
9
10
11
12
13
Age (years)
10
Assumptions that limit the accuracy of
time-specific life tables

• Equal number of offspring are born each year
• Favorable climate for breeding?
• A need for an independent method for estimating
  birth rates of each age class
• As a result, age-specific life tables are
  typically reported
• Of 31 life tables examined, 26 were age specific
  and only 5 were time specific.

11
Age-specific life tables

• Needed for short-lived organisms
• Time-specific life tables biased toward the stage
  common at the moment
• Follows one cohort or generation
• Population censuses must be frequent and
  conducted over a limited time
• Ex. Table 6.2 and Figure 6.3
• Comparison in the accuracy of life tables (Figure
  6.5)

12
(No Transcript)
13
3.5
3
2.5
2
n (log scale)
1.5
x
1
0.5
0
1
2
7
6
3
4
5
Age (years)
Fig. 6.3 Age-specific survivorship curve for the
American robin.
14
Fig. 6.5 Hypothetical comparison of cohort
survivorship of humans born in 1930.
Comparison in the accuracy of life tables
15
General types of survivorship curves (Figure 6.4)

• Type I
• Most individuals are lost when they are older
• Vertebrates or organisms that exhibit parental
  care and protect their young
• Small dip at young age due to predators
• Type II
• Almost linear rate of loss
• Many birds and some invertebrates
• Type III
• Large fraction are lost in the juvenile stages
• Invertebrates, many plants, and marine
  invertebrates that do not exhibit parental care
• Large losses due to predators

16
Type I
1000
Many birds, small mammals, lizards, turtles
Many mammals
100
x
Number of survivors (n ) (log scale)
Type II
10
Many invertebrates
1
Type III
0.1
Fig. 6.4
Age
17
6.2 Reproductive rate

• Fecundity
• Age-specific birth rates
• Number of female offspring produced by each
  breeding female
• Fecundity schedules
• Fecundity information in life table
• Describe reproductive output and survivorship of
  breeding individuals.
• Ex. Table 6.3

18
(No Transcript)
19
Fecundity schedules

• Table components
• lx survivorship (number of females surviving in
  each age class
• mx age-specific fecundity
• Ro populations net reproductive rate Slx mx
• Ro 1 population is stationary
• Ro gt 1 population is increasing
• Ro lt 1 population is decreasing
• Table 6.3

20
Fecundity schedules

• Variation in formula for plants
• Age-specific fecundity (mx ) is calculated
  differently
• Fx total number of seeds, or young deposited
• nx total number of reproducing individuals
• mx Fx / nx
• Table 6.4

21
(No Transcript)
22
6.3 Deterministic Models
Geometric Growth

• Predicting population growth (???????),????
• Ro
• Initial population size
• Population size at time t
• Population size of females at next generation
  Nt1 RoNt
• Ro net reproductive rate
• Nt population size of females at this generation

23
Geometric Growth

• Dependency of Ro
• Ro lt 1 population becomes extinct
• Ro 1 population remains constant
• Population is at equilibrium
• No change in density
• Ro gt 1 population increases
• Even a fraction above one, population will
  increase rapidly
• Characteristic J shaped curve
• Geometric growth
• Figure 6.7

24
R 1.20
0
500
R 1.15
0
R???,???????
400
300
Population in size (N)
N 1 R N
200
t 0 t
R 1.10
0
100
R 1.05
0
0
10
20
30
Fig. 6.7
Generations
25
Geometric Growth

• Ro gt 1 population increases (cont.).
• Something (e.g., resources) will eventually limit
  growth
• Population crash
• Figure 6.8a
• Figure 6.8b
• Figure 6.8c

26
2000
1500
Number of reindeer
1000
500
0
1910
1920
1930
1940
1950
Fig. 6.8 a
Year
27
Fig6.8b?c
28
Geometric GrowthHuman population growth

• Prior to agriculture and domestication of animals
  (10,000 B.C.)
• Average annual rate of growth 0.0001
• After the establishment of agriculture
• 300 million people by 1 A.D.
• 800 million by 1750
• Average annual rate of growth 0.1

29
Geometric GrowthHuman population growth

• Period of rapid population growth
• Began 1750
• From 1750 to 1900
• Average annual rate of growth 0.5
• From 1900 to 1950
• Average annual rate of growth 0.8
• From 1950 to 2000
• Average annual rate of growth 1.7
• Reasons for rapid growth
• Advances in medicine
• Advances in nutrition
• Trends in growth (Figure 6.9)

30
14
Year
13
12
11
2100
2046
10
2033
9
2020
8
Billions of people
2009
7
1998
6
1987
5
1975
4
1960
3
1930
2
1830
1
0
2-5 million Years ago
7,000 BC
6,000 BC
5,000 BC
4,000 BC
3,000 BC
2,000 BC
1,000 BC
1 AD
1,000 AD
2,000 AD
3,000 AD
4,000 AD
Fig. 6.9 The world population explosion.
31
Human population statistics

• Population is increasing at a rate of 3 people
  every second
• Current population over 6 billion
• UN predicts population will stabilize at 11.5
  billion by 2150
• Developed countries
• Average annual rate of growth from 1960-1965
  1.19
• Average annual rate of growth from 1990-1995
  0.48
• Developing countries
• Average annual rate of growth from 1960-1965
  2.35
• Average annual rate of growth from 1990-1995
  2.38

32
(No Transcript)
33

• Fertility rates
• Theoretic replacement rate 2.0
• but Actual replacement rate 2.1

34
Overlapping generations

• Many species in warm climates reproduce
  continually and generations overlap.
• Rate of increase is described by a differential
  equation
• dN / dt rN (b d)N
• N population size
• t time
• r per capita rate of population growth
• b instantaneous birth rate
• d instantaneous death rate
• dN the rate of change in numbers
• dN / dt the rate of population increase

35
5
r 0.02
4
r 0.01
3
In (N)
r 0 (equilibrium)
2

• r is analogous to Ro
• In a stable population
• r (ln Ro) / Tc
• Tc generation time

1

• The starting population is N10

0
20
60
80
100
40
Fig. 6.10
Time (t)
36
???????

• r 0.01 t 69.3
• r 0.02 t 34.7
• r 0.03 t 23.1
• r 0.04 t 17.3
• r 0.05 t 13.9
• r 0.06 t 11.6

• Nt N0ert
• Nt / N0 ert
• If Nt / N0 2, ert 2
• ln(2) rt
• 0.69315 rt
• t 0.69315 / r

37
Logistic growth equations

• dN / dt rN(K-N)/K or
• dN / dt rN1-(N/K)
• dN / dt Rate of population change
• r per capita rate of population growth
• N population size
• K carrying capacity
• S-Shaped Curve Figure 6.11

38
K
Geometric J shaped curve
Population size
Logistic S shaped curve
Time
39
Logistic growth assumptions

• Relation between density and rate of increase is
  linear
• Effect of density on rate of increase is
  instantaneous
• Environment (and thus K) is constant
• All individuals reproduce equally
• No immigration and emigration

40
Logistic growth assumptions

• Testing assumptions
• Early laboratory cultures Pearl 1927
• Figure 6.12
• Complex studies and temporal effects
• Figure 6.13

41
750
K 665
600
450
Amount of yeast
300
150
0
2
4
6
8
10
12
14
16
18
20
Time (hrs)
Fig. 6.12 yeast
42
Logistic curve predicted by theory
N
Time
800
600
Rhizopertha dominica
Number per 12 grams of wheat
Callandra oryzae
400
200
50
180
100
Time (weeks)
Fig. 6.13 grain beetles
43
Difficulty in meeting assumptions in nature

• Each individual added to the population probably
  does not cause an incremental decrease to r
• Time lags, especially with species with complex
  life cycles
• K may vary seasonally and/or with climate
• Often a few individuals command many matings
• Few barriers to prevent dispersal

44
Effect of time lags

• Robert May (1976)
• Incorporated time lags into logistic equation
• dN / dt rN1-(Nt-t /K)
• dN / dt Rate of population change
• r per capita rate of population growth
• N population size
• K carrying capacity.
• Nt-t time lag between the change in population
  size and its effect on population growth, then
  the population growth at time t is controlled by
  its size at some time in the past, t - t
• Nt-t population size in the past

45
Effect of time lags

• Ex. r 1.1, K 1000 and N 900
• No time lag, new population size
• dN / dt 1.1 x 900 (1 900/1000) 99
• New population size 900 99 999
• Still below K
• With time lag, where a population is 900,
  although the effects of crowding are being felt
  as though the population was 800
• dN / dt 1.1 x 900 (1 800/1000) 198
• New population size 900 198 1098
• Possible for a population to exceed K

46
Effect of response time

• Ratio of time lag (t) to response time (1/r) or
  rt controls population growth (Figure 6.14)
• rt is small (lt0.368)
• Population increases smoothly to carrying
  capacity
• rt is large (gt1.57)
• Population enters into a stable oscillation
  called a limit cycle
• Rising and falling around K
• Never reaching equilibrium
• rt is intermediate (gt0.368 and lt1.57)
• Populations undergo oscillations that dampen
  with time until K is reached

47
r small (lt0.368)
Smooth response
Number of individuals (N)
K
Time (t)
r t medium (gt0.368,lt1.57)
Damped oscillations
Number of individuals (N)
K
Time (t)
r t large (gt1.75)
Stable limit cycle
period
Number of individuals (N)
K
amplitude
Fig. 6.14
Time (t)
48
Species with discrete generations

• Nt1 Nt rNt 1 (Nt / K)
• In discrete generations, the time lag is 1.0
• r is small (2.0)
• Population generally reaches K smoothly
• r is between 2.0 and 2.449
• Population enters a stable two-point limit
  cycle with sharp peaks and valleys
• r is between 2.449 and 2.570
• More complex limit cycles
• r is larger than 2.57
• Limit cycles breakdown
• Population grows in a complex, non-repeating
  patterns, know as chaos
• Figure 6.15

49
r small (2.0002.499)
N
t
r medium (2.4992.570)
N
t
r large (gt2.570)
N
Fig. 6.15
t
50
6.4 Stochastic Models

• Models are based on probability theory
• Figure 6.16
• dN / dt rN (b d) N
• If b 0.5, d 0, and N0 10,
• integral form of equation Nt N0ert
• So for the above example, Nt 10 x 1.649 16.49
• Path of population growth (Figure 6.17)

51
0.30
0.20
Proportion of observations
0.10
0
8
6
10
12
14
Population size
Fig. 6.16 stochastic frequency distribution
52
Fig. 6.17
Population density
Possible stochastic path
Extinction
Time
53
Stochastic Models

• Probability of extinction (d/b)N0
• The larger the initial population size
• The greater the value of b d
• The more resistant a population is to extinction
• Introduce biological variation into calculations
  of population growth
• More representative of nature
• More complicated mathematics

54
Applied EcologyHuman Population growth and the
use of contraceptives

• 1992 Johns Hopkins study
• Developed countries
• 70 of couples use contraceptives
• Developing countries
• 45 of couples use contraceptives
• Africa, 14
• Asia, 50
• Latin America, 57

55
Human Population growth

• China
• 1950s and 1960s
• Fertility was six children per woman
• 1970s
• Government planning and incentives to reduce
  population growth
• 1990
• 75 use birth control
• Fertility rate dropped to 2.2

56
Human Population growth

• Other governments
• 1976, only 97 governments supported family
  planning
• 1988, 125 governments supported family planning
• As of 1989, in 31 countries, couples have no
  access to family planning
• Women
• Women in developing countries want fewer children
• In virtually every country outside of Saharan
  Africa, the desireds number of children is below
  3

57
Low growth rates

• Countries concerned about low growth rates
• Some Western European countries and other
  developed countries
• Total fertility has dropped below the replacement
  level of 2.1
• Reduced populations concerns
• Affect political strength
• Economic structure

58

• ?????!

Japalura_at_hotmail.com Ayo ???
http//mail.nutn.edu.tw/hycheng/
