Empowering SIP Applications with J2EE Technology

1
(No Transcript)
2
Empowering SIP Applications with J2EE Technology

• Marcelo Oliveira Sudhrity Mondal
• Principal Architects, BEA Systems

3
Agenda

• VoIP Landscape
• SIP with J2EE
• Use Case Audio/Video conferencing application

4
IMS

• IP Multimedia Subsystems
• Next generation mobile specification
• SIP as the signaling protocol
• Driver for Fixed / Mobile / IP Convergence
• Cutting edge services
• Increase ARPU
• Telephony applications and services look more
  like HTTP applications

5
VoIP Overview

• Signaling plane
• SIP Application Servers
• Session Setup
• Session Management
• Session teardown

• Media Plane
• Media Servers
• Control and processing of real-time multimedia
  data

Application Server
Endpoint
Media Server
6
SIP

• Session Initiation Protocol
• Base Protocol ? IETF RFC 3261
• Leading Signaling Protocol for VoIP development
• Create, Modify and Teardown Multimedia Sessions
• Mobility
• Event Subscription / Notification
• Presence
• IM

7
Media Servers

• Essential to Multimedia Applications
• Controlled via Media Gateway Control Protocols
• Mature Standards
• MGCP
• MEGACO H.248
• Standardized as IMS Media Gateway Control
  Protocol
• Recently Introduced
• MSCML
• MSML/MOML

8
MSCML Overview

• Media Server Control Markup Language
• XML based
• Transported over SIP messages
• INVITE transactions
• INFO transactions
• APIs
• Create / Terminate Conference
• Add / Remove Conference Participant
• Modify Conference Leg
• Play / Record Announcement
• Collect DTMF Digits
• etc

9
VoIP Applications

• VoIP enables an extensive new set of applications
  and revolutionaizes some of the traditional
  services like
• Softswitches
• Voice Mail
• Push to Talk
• Voice and Video Conferencing
• Application Sharing
• IVR
• etc

10
Challenges on SIP App Development

• SIP and MEGACO / MGCP Stacks

• Build
• High Development Cost
• High Maintenance Cost
• Buy
• Vendor Specific Interfaces
• Complex Integration
• Maintenance

11
Challenges on SIP App Development

• Application Platform
• C/C ? Intrinsic Platform Dependency
• HW / OS platforms
• Development Environment
• OS abstraction layer

• Build
• High Development Cost
• High Maintenance Cost

• Buy
• Cost
• Vendor Specific Interfaces
• Complex Integration
• Limited OS Support

12
Challenges on SIP App Development

• User Management Interfaces
• Complex Integration with Application
• Application Scalability
• Architecture
• Testing
• Application Fault Tolerance
• Architecture
• Testing

13
Challenges on SIP App Development

• Integration with other applications
• Databases
• Web Services
• Enterprise Information Systems
• Reusability
• No resources to create reusable components
• New Application ? Same Challenges

14
Agenda

• VoIP Landscape
• SIP with J2EE
• Use Case Audio/Video conferencing

15
What does J2EE provide for VoIP?

• JSR 116 SIP Servlet container
• J2EE Framework
• Web-tier Servlets, JSP
• Infrastructure JDBC, JNDI, JMS, JTA, JTS, JAAS,
  Mail, JMX
• Business-tier JavaBeans, EJB
• Integration RMI, JRMP, IIOP, J2EE-CA, Web
  Services
• J2EE Application servers
• Clustering, Replication, High Availability,
  Failover
• Integrated Security, Management
• Platform independence
• Enhanced development and deployment tools
• Technologies around J2EE (Struts, JSF, Spring, )

16
VoIP using J2EE
Network Resources not standalone apps
Voicemail
ACD
CTI
IVR/Speech
Quality
Monitoring
IP Network
SIP (JSR 116)
J2EE Platform
JSP
JMS
JTS
JNDI
JAAS
EJB
JCA
IIOP
JMX
JDBC
Order Mgmt
Customer Data Mart
Trouble Ticketing
Applications
17
JAVA Solutions for VoIP

• SIP Application Servers
• BEA WebLogic SIP Server
• Ubiquity
• IBM WAS
• Oracle SDP
• SIP Java Toolkits
• JAIN SIP
• Radvision
• SIP Development Environments/Applications
• Eclipse
• WebLogic Workshop
• WebSphere WSAD
• Pactolus
• www.sipcenter.com

18
J2EE Advantages

• Fusion of cutting edge communications technology
  and proven enterprise reliability
• Simplified SIP handling using SIP Servlets
• Natural convergence of web-tier with business
  tier
• Standards based infrastructure
• Easy integration with back-end applications
• XML Automation
• Support for Workflow
• Support for heterogeneous environments
• Availability of tools and solutions around J2EE
• Cost of development, deployment and maintenance

19
J2EE SIP Application Enablement
J2EE Enablement
20
SOA for VoIP Services

• Expose SIP servlet features as generic,
  re-useable web services
• Create composite services by orchestrating low
  level granular SIP features
• Expose services to Enterprise Service Bus
• Implement complex VoIP applications using
  composite services
• Quick turnaround from concept to deployment of
  services

21
Modularization Extensibility using SOA

• Java web services can be used to modularize SIP
  features
• Web service modules are re-useable and generic
• VoIP applications can be extended easily using
  service orchestration by adding additional
  services

22
SOA for VoIP Services
IT Network
Enterprise Service Bus
Core Network
Web Service Access
J2EE Application Server
Billing
23
Agenda

• VoIP Landscape
• SIP with J2EE
• Use Case Audio/Video conferencing

24
Use case Audio/Video Conferencing

• Service provider offers conferencing service
• Conference host schedules a conference with
  conferees
• Conferees get notified of conference via e-mail
  or SMS, accepts/denies participation
• Host and conferees receive call at time of
  conference
• Conferees enter PIN, record name to join the
  conference
• Conferees switches video on/off
• Host Manages Conference
• Extend/Terminate Conference
• Remove Conferees
• Mute / Unmute Conferees

25
Use case Architecture

• To be added

26
Use case Message Flow

• To be added

27
QA
28
References

• To be added
