Waves

1
Waves

• conceptual physics level 2

2
What is harmonic motion?

• Harmonic motion is any motion that repeats
  itself over and over again.
• Harmonic motion is different than linear motion
  because harmonic motion is a repetitive motion.
• So anything that repeats it motion has harmonic
  motion
• Can you think of examples of this?
•
•
•
•
•  These systems of harmonic motion are known as
  oscillators.
• An oscillation/vibration is a motion that repeats
  itself.

3
How do we describe harmonic motion?

• cycle
• one complete back and forth motion (pendulum)
• period
• the time it takes for one cycle
• measured in seconds (s)
• frequency
• the number of cycles per second
• measured in hertz (Hz)
• amplitude
• the distance from the equilibrium point

4
Pendulums

• The period of a pendulum is only affected by the
  length of the pendulum.
• The period is not affected by the angle of the
  pendulum or by the mass of the pendulum.
• Period and frequency are inversely related, so
• of 15Hz?

5
Period vs Frequency

• Period  T 1/f
• and
• Frequency   f 1/T
• Practice problems
• What is the frequency of a pendulum that has a
  period of 2.5s?
• What is the period of a pendulum that has a
  frequency of 0.25Hz?

6
Anatomy of a wave

•
•

7
Waves

• A wave is a vibration that transfers energy (not
  matter) over a distance.
• There are two general types of waves
• mechanical waves
• sound
• water
• etc
• electromagnetic waves
• Visible light
• radio
• x-rays

8
Mechanical Waves

• Mechanical waves, unlike electromagnetic waves,
  need a medium to travel through.
• This means the need some type of matter to travel
  through, solid, liquid, or gas.
• There are two types of mechanical waves
• Transverse
• The wave moves up and down.
• Longitudinal
• The wave moves in one path (also known as a
  compression wave).

9
More about longitudinal waves
The reason that a longitudinal wave is called a
compression wave is that the vibration occurs in
a series of areas of compression and then areas
of rarefaction.

• Compression Where particles are closer together
  and bunch up. (Literally, the particles are
  compressed)
• Rarefaction Where particles are further apart
  and are fewer in number. (Literally, the
  particles are becoming rarer)

10
Comparing Longitudinal and Transverse
