PROTEINS

1
(No Transcript)
2
PROTEINS

• C, H, O, N, (S)
• Polymers made from chains of amino acids
• 20 amino acids used
• Linked by a peptide bond

3
In addition fibrous proteins (collagen) form
structural components in cells and tissues
4
(No Transcript)
5
Amino Acids

• Central carbon has attached
• Amine group
• Acid group
• Functional group (R) determines nature of amino
  acid
• R groups fall into 4 categories
• Non-polar - only carbons chains or aromatic
  rings (methionine has sulphur)
• Uncharged Polar- carbons with amine groups (NH2)
  or - hydroxyl groups (OH)
• Acidic - carboxylic acid groups (COOH) ionizes to
  negative charge COO-
• Basic - terminal amine groups (not next to CO)
  ionizes to NH3

6
(No Transcript)
7
Peptide bond

• Amino acids joined by a peptide bond
• Condensation reaction between
• COOH of 1st amino acid and NH2 of 2nd amino acid

• Chains are called peptides (short)/ polypeptides
  (longer)
• Peptide bond is rigid
• Bonds either side can rotate
• Introduces flexibility allowing proteins to take
  up variety of shapes.

8
Protein Structure

• 4 levels
• Primary
• Secondary
• Tertiary
• Quaternary

9
PRIMARY STRUCTURE
PRIMARY STRUCTURE DETERMINES other levels of
STRUCTURE

• Order in which amino acids are linked together
• Written starting at the N (amino) terminus
• e.g.
• Arg-Lys-Phe-Glu-Ser-Gly-
• R K F E S G

N
C
10
SECONDARY STRUCTURE

• Two possible shapes in the protein chain each
  stabilised by Hydrogen bonds
• ?-pleated sheet
• ?-helix

11
?-pleated sheet

• Peptide chains arranged side by side
• Held together by H-bonds between the two chains
• Parallel (chains running same direction)
• N ? C
• N ? C
• Antiparallel (chains in opposite directions)
• N ? C
• C ? N

12
?-pleated sheet

• Silk
• Resistant to stretch (very strong)

13
?-helix

• Peptide chain coils into a helix
• Held by H-bond between N-H group and the CO 4
  residue away
• 4 residues per turn

14
?-helix

• Hair/Wool (keratin)
• Stretchy (er)
• ?-helices coiled together to form a superhelix
• For horn/hoof more disulphide bridges are present
  (covalent)

15
Tertiary Structure

• The overall folded shape of a protein held
  together by (usually) weak forces.
• Hydrogen bonding which doesnt form secondary
  structure
• Hydrophobic interactions
• Place non-polar amino acids inside protein
• Polar amino acids on surface
• Van der Waals forces
• Ionic interactions (strong)
• Disulphide bridges (strong)
• Covalent bond between cysteine residues

16
(No Transcript)
17

• With reference to bonding, explain why enzyme
  activity decreases as you increase the
  temperature above the optimum, and as you move pH
  away from the optimum.

18
Proteins fold to take up their shape
Shape is determined by primary structure order
of hydrophobic/ hydrophilic amino acids
relative positions of polar/charged amino
acids. Loss of tertiary structure is called
denaturation.
19
Proteins are 3D
Lysozyme
20
Primary structure determines tertiary structure
Mutation acid (polar) for non polar changes
folding pattern
21
Prosthetic groups

• Some proteins have permanently bound non protein
  groups, called prosthetic groups
• e.g. myoglobin haemoglobin bind to a porphyrin
  (haem) chelating an Iron atom
• e.g. Chlorophyll has a similar prosthetic group
  chelating Mg
• The protein without its prosthetic group is
  called an apoprotein, with its group it is called
  a holoprotein

22
Co-factors/ Co-enzymes

• Other proteins have inorganic ions temporarily
  bound to them
• E.g. copper/ zinc on enzymes
• Others have carbon containing molecules
  temporarily attached
• e.g. Coenzyme A, NAD, FAD

23
Quaternary Structure

• Only present if protein has more than one
  polypeptide chain
• Describes the shape adopted by the interacting
  polypeptide chains

24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Nucleic Acids

• DNA
• Deoxyribonucleic Acid
• RNA
• Ribonucleic Acid
• Video

28
Nucleic Acids

• Summary Knowledge
• DNA deoxyribose sugar,
• RNA ribose sugar
• DNA double stranded (antiparallel)
• RNA single stranded
• DNA thymine,
• RNA uracil
• A double (hydrogen) bonds to T (A 2 T)
• G triple (hydrogen) bonds to C (G 3 C)
• G A purines (small word, big molecule A Giant)
• C,T U pyrimidines (big word, small molecule)

29
(No Transcript)
