Principles of

1
Chapter 10

• Principles of
• Six Sigma

2
Key IdeaIntroduction
Although we view quality improvement tools and
techniques from the perspective of Six Sigma, it
is important to understand that they are simply a
collection of methods that have been used
successfully in all types of quality management
and improvement initiatives, from generic TQM
efforts, to ISO 9000, and in Baldrige processes.
3
Six Sigma

• A simple quality metric
• An overall strategy to quality improvement

4
Six-Sigma Metrics

• Defect any mistake or error that is passed on
  to a customer
• Defects per unit (DPU) number of defects
  discovered ? number of units produced
• Defects per million opportunities (dpmo) DPU ?
  1,000,000 ? opportunities for error

5
Six-Sigma Quality

• Ensuring that process variation is half the
  design tolerance (Cp 2.0) while allowing the
  mean to shift as much as 1.5 standard deviations,
  resulting in at most 3.4 dpmo.

6
k-Sigma Quality Levels
7
Six Sigma(Chapter 3)

• Based on a statistical measure that equates to
  3.4 or fewer errors or defects per million
  opportunities
• Pioneered by Motorola in the mid-1980s and
  popularized by the success of General Electric

8
Key Idea (Chapter 3)
Six Sigma can be described as a business
improvement approach that seeks to find and
eliminate causes of defects and errors in
manufacturing and service processes by focusing
on outputs that are critical to customers and a
clear financial return for the organization.
9
Key Concepts of Six Sigma (1 of 2) (Chapter 3)

• Think in terms of key business processes,
  customer requirements, and overall strategic
  objectives.
• Focus on corporate sponsors responsible for
  championing projects, support team activities,
  help to overcome resistance to change, and
  obtaining resources.
• Emphasize such quantifiable measures as defects
  per million opportunities (dpmo) that can be
  applied to all parts of an organization

10
Key Concepts of Six Sigma (2 of 2) (Chapter 3)

• Ensure that appropriate metrics are identified
  early and focus on business results, thereby
  providing incentives and accountability.
• Provide extensive training followed by project
  team deployment
• Create highly qualified process improvement
  experts (green belts, black belts, and
  master black belts) who can apply improvement
  tools and lead teams.
• Set stretch objectives for improvement.

11
Key Idea
Although originally developed for manufacturing
in the context of tolerance-based specifications,
the Six Sigma concept has been operationalized to
any process and has come to signify a generic
quality level of at most 3.4 defects per million
opportunities.
12
Projects as Value-Creation Processes

• Projects - temporary work structures that start
  up, produce products or services, and then shut
  down.
• Project management all activities associated
  with planning, scheduling, and controlling
  projects

13
Six Sigma Project Teams

• Champions senior managers who promote Six Sigma
• Master Black Belts highly trained experts
  responsible for strategy, training, mentoring,
  deployment, and results.
• Black Belts Experts who perform technical
  analyses
• Green Belts functional employees trained in
  introductory Six Sigma tools
• Team Members Employees who support specific
  projects

14
Key IdeaProject Management
Successful project managers have four key skills
a bias toward task completion, technical and
administrative credibility, interpersonal and
political sensitivity, and leadership ability.
15
Project Life Cycle Management (1 of 2)

• Project Quality Initiation Define directions,
  priorities, limitations, and constraints.
• Project Quality Planning Create a blueprint for
  the scope of the project and resources needed to
  accomplish it.
• Project Quality Assurance Use appropriate,
  qualified processes to meet technical project
  design specifications.

16
Project Life Cycle Management (2 of 2)

• Project Quality Control Use appropriate
  communication and management tools to ensure that
  managerial performance, process improvements, and
  customer satisfaction is tracked.
• Project Quality Closure Evaluate customer
  satisfaction with project deliverables and assess
  success and failures that provide learning for
  future projects and referrals from satisfied
  customers.

17
The Definition of a Project
Performance
Required performance
Target
Cost
Cumulative
Budget limit
Due Date
Time (schedule)
18
Problem Solving

• Problem any deviation between what should be
  and what is that is important enough to need
  correcting
• Problem Solving the activity associated with
  changing the state of what is to what should
  be

19
Quality Problem Types

1. Conformance problems
2. Unstructured performance problems
3. Efficiency problems
4. Product design problems
5. Process design problems

20
Project Selection

• One of the more difficult challenges in Six Sigma
  is the selection of the most appropriate problem
  to attack.
• Two ways to generate projects
• Top-down
• Bottom-up

21
Key Factors in Six Sigma Project Selection

• Financial return, as measured by costs associated
  with quality and process performance, and impacts
  on revenues and market share
• Impacts on customers and organizational
  effectiveness
• Probability of success
• Impact on employees
• Fit to strategy and competitive advantage

22
Problem Solving Process

1. Redefining and analyzing the problem
2. Generating ideas
3. Evaluating and selecting ideas
4. Implementing ideas

23
Key IdeaProblem Solving
A structured problem-solving process provides all
employees with a common language and a set of
tools to communicate with each other,
particularly as members of cross-functional teams.
24
DMAIC Methodology

1. Define
2. Measure
3. Analyze
4. Improve
5. Control

DMAIC
25
Define

• Describe the problem in operational terms
• Drill down to a specific problem statement
  (project scoping)
• Identify customers and CTQs, performance metrics,
  and cost/revenue implications

26
Measure

• Key data collection questions
• What questions are we trying to answer?
• What type of data will we need to answer the
  question?
• Where can we find the data?
• Who can provide the data?
• How can we collect the data with minimum effort
  and with minimum chance of error?

27
Analyze

• Focus on why defects, errors, or excessive
  variation occur
• Seek the root cause
• 5-Why technique
• Experimentation and verification

28
Improve

• Idea generation
• Brainstorming
• Evaluation and selection
• Implementation planning

29
Control

• Maintain improvements
• Standard operating procedures
• Training
• Checklist or reviews
• Statistical process control charts

30
Tools for Six-Sigma and Quality Improvement

• Elementary statistics
• Advanced statistics
• Product design and reliability
• Measurement
• Process control
• Process improvement
• Implementation and teamwork

31
Design for Six Sigma

• Focus on optimizing product and process
  performance
• Features
• A high-level architectural view of the design
• Use of CTQs with well-defined technical
  requirements
• Application of statistical modeling and
  simulation approaches
• Predicting defects, avoiding defects, and
  performance prediction using analysis methods
• Examining the full range of product performance
  using variation analysis of subsystems and
  components

32
Six Sigma in Services and Small Organizations

• Six Sigma is equally applicable to services.
  However, services have some unique
  characteristics.

33
Key IdeaSix Sigma in Services
All Six Sigma projects have three key
characteristics a problem to be solved, a
process in which the problem exists, and one or
more measures that quantify the gap to be closed
and can be used to monitor progress.
34
Key Six Sigma Metrics in Services

• Accuracy
• Cycle time
• Cost
• Customer satisfaction

35
Lean Production and Six Sigma

• The 5Ss seiri (sort), seiton (set in order),
  seiso (shine), seiketsu (standardize), and
  shitsuke (sustain).
• Visual controls
• Efficient layout and standardized work
• Pull production
• Single minute exchange of dies (SMED)
• Total productive maintenance
• Source inspection
• Continuous improvement

36
Traditional Economic Model of Quality of
Conformance
Total cost
Cost due to nonconformance
Cost of quality assurance
100
optimal level of quality
37
Modern Economic Model of Quality of Conformance
Total cost
Cost due to nonconformance
Cost of quality assurance
100
