Single Variable Regression

1
Single Variable Regression
2
Which Approach Is Appropriate When?

• Choosing the right method for the data is the key
  statistical expertise that you need to have.

3
Do I Need to Know the Formulas?

• You do not need to know exact formulas.
• You do need to understand the concept behind them
  and the general statistical concepts imbedded in
  the use of the formulas.
• You do not need to be able to do correlation and
  regression by hand.
• You must be able to do it on a computer using
  Excel.

4
Table of Content

• Objectives
• Purpose of Regression
• Correlation or Regression?
• First Order Linear Model
• Probabilistic Linear Relationship
• Estimating Regression Parameters
• Assumptions

• Sum of squares
• Tests
• Percent of variation explained
• Example
• Regression Analysis in Excel
• Normal Probability Plot
• Residual Plot
• Goodness of Fit
• ANOVA For Regression

5
Objectives

• To learn the assumptions behind and the
  interpretation of single and multiple variable
  regression.
• To use Excel to calculate regressions and test
  hypotheses.

6
Purpose of Regression

• To determine whether values of one or more
  variable are related to the response variable.
• To predict the value of one variable based on the
  value of one or more variables.
• To test hypotheses.

7
Correlation or Regression?

• Use correlation if you are interested only in
  whether a relationship exists.
• Use Regression if you are interested in building
  a mathematical model that can predict the
  response variable.
• Use regression if you are interested in the
  relative effectiveness of several variables in
  predicting the response variable.

8
First Order Linear Model

• A deterministic mathematical model between y and
  x
• y ?0 ?1 x
• ?0 is the intercept with y axis, the point at
  which x 0
• ?1 is the angle of the line, the ratio of rise
  divided by the run in figure to the right. It
  measures the change in y for one unit of change
  in x.

9
Probabilistic Linear Relationship

• But relationship between x and y is not always
  exact. Observations do not always fall on a
  straight line.
• To accommodate this, we introduce a random error
  term referred to as epsilon y ?0 ?1 x
  ?
• The task of regression analysis then is to
  estimate the parameters b0 and b1 in the
  equation
• b0 b1 x
• so that the difference between y and is
  minimized

10
Estimating Regression Parameters

• Red dots show the observations
• The solid line shows the estimated regression
  line
• The distance between each observation and the
  solid line is called residual
• Minimize the sum of the squared residuals
  (differences between line and observations).

11
Assumptions

• The dependent (response) variable is measured on
  an interval scale
• The probability distribution of the error is
  Normal with mean zero
• The standard deviation of error is constant and
  does not depend on values of x
• The error terms associated with any particular
  value of Y is independent of error term
  associated with other values of Y

12
Sum of Squares

• Variation in y SSR SSE
• MSR divided by MSE is the test statistic for
  ability of regression to explain the data

13
Tests

• The hypothesis that the regression equation does
  not explain variation in Y and can be tested
  using F test.
• The hypothesis that the coefficient for x is zero
  can be tested using t statistic.
• The hypothesis that the intercept is 0 can be
  tested using t statistic

14
Percent of Variation Explained

• R2 is the coefficient of determination.
• The minimum R2 is zero. The maximum is 1.
• 1- R2 is the variation left unexplained.
• If Y is not related to X or related in a
  non-linear fashion, then R2 will be small.
• Adjusted R2 shows the value of R2 after
  adjustment for degrees of freedom. It protects
  against having an artificially high R2 by
  increasing the number of variables in the model.

15
Example

• Is waiting time related to satisfaction ratings?
• Predict what will happen to satisfaction ratings
  if waiting time reaches 15 minutes?

16
Regression Analysis in Excel

• Select tools
• Select data analysis
• Select regression analysis
• Identify the x and y data of equal length
• Ask for residual plots to test assumptions
• Ask for normal probability plot to test assumption

17
Normal Probability Plot

• Normal Probability Plot compares the percent of
  errors falling in particular bins to the
  percentage expected from Normal distribution.
• If assumption is met then the plot should look
  like a straight line.

18
Residual Plot
The difference between the observed value of the
dependent variable (y) and the predicted value
(y) is called the residual (e). Each data point
has one residual. Residual Observed value -
Predicted value

• Tests that residuals have mean of zero and
  constant standard deviation
• Tests that residuals are not dependent on values
  of x

19
Residual Plot

• A residual plot is a graph that shows the
  residuals on the vertical axis and the
  independent variable on the horizontal axis.
• If the points in a residual plot are randomly
  dispersed around the horizontal axis, a linear
  regression model is appropriate for the data
  otherwise, a non-linear model is more
  appropriate.
• Below the chart displays the residual (e) and
  independent variable (X) as a residual plot.
• This random pattern indicates that a linear model
  provides a decent fit to the data.

20
Residual Plot

• Below, the residual plots show three typical
  patterns.
• The first plot shows a random pattern, indicating
  a good fit for a linear model.
• The other plot patterns are non-random (U-shaped
  and inverted U), suggesting a better fit for a
  non-linear model.

Random pattern Non-random U-shaped Non-random Inverted U
21
Linear Equation

• Satisfaction 121.3 4.8 Waiting time
• At 15 minutes waiting time, satisfaction is
  predicted to be
• 121.3 - 4.8 15 48.87
• The t statistic related to both the intercept and
  waiting time coefficient are statistically
  significant.
• The hypotheses that the coefficients are zero are
  rejected.

22
Goodness of Fit

• 57 of variation in satisfaction ratings is
  explained by the equation
• 43 of variation in satisfaction ratings is left
  unexplained

23
ANOVA For Regression

• The regression model has mean sum of square of
  347.
• The mean sum of errors is 33. Note the error
  term is called residuals in Excel.
• F statistics is 10, the probability of observing
  this statistic is 0.02.
• The hypothesis that the MSR and MSE are equal is
  rejected. Significant variation is explained by
  regression.

24
Null Hypothesis

• The null hypothesis corresponds to a general or
  default position.
• For example, the null hypothesis might be that
  there is no relationship between two measured
  phenomena or that a potential treatment has no
  effect.

• It is important to understand that the null
  hypothesis can never be proven.
• A set of data can only reject a null hypothesis
  or fail to reject it.
• For example, if comparison of two groups (e.g.
  treatment, no treatment) reveals no statistically
  significant difference between the two, it does
  not mean that there is no difference in reality.
• It only means that there is not enough evidence
  to reject the null hypothesis (in other words,
  the experiment fails to reject the null
  hypothesis)

25
What is a P value?

• P stands for probability
• Measures the strength of the evidence against the
  null hypothesis (that our regression has no
  significance)
• Smaller P values indicate stronger evidence
  against the null hypothesis
• By convention, p-values of lt.05 are often
  accepted as statistically significant but this
  is an arbitrary cut-off.
