Prospects for an Energy-Frontier Muon Collider

1
Prospects for an Energy-Frontier Muon Collider

• Tom Roberts
• Muons, Inc.
• Illinois Institute of Technology

2
Outline

• Background
• Why muons?
• The major challenges
• Surmounting the challenges
• Recent innovations that have improved the
  prospects for success
• Viewgraph-level design of a Muon Collider
• Current RD Efforts
• Summary

3
Background Reminders

• Historically, every significant increase in
  energyhas taught us something completely new.
• Every new type of particle beam has alsotaught
  us something completely new.
• The LHC is turning on later this year, so the
  energy frontier is above 14 TeV for protons,or
  above 1.5 TeV for leptons.

4
The Livingston Plot
X
5 TeV MC
Constituent Center-of-Mass Energy
X
ILC
2025
Panofsky and Breidenbach, Rev. Mod. Phys. 71,
s121-s132 (1999)
5
Why Muons?

• Electrons have problems at the energy frontier
• At the TeV scale, radiative processes limit both
  energy and luminosity for electrons
• Synchrotron radiation losses ? linear, large, and
  very expensive
• Beamstrahlung E2, approaches the beam energy in
  one crossing? low luminosity at peak energy,
  huge beam energy spread
• Remember those beautiful, narrow peaks for the
  J/?? They wont happen again because
• The beam energy spread is very large
• Resonances above 2MW will have large weak-decay
  widths
• Protons have problems at the energy frontier
• Without some tremendous breakthrough in
  high-field magnets, the machine must be truly
  enormous (expensive)
• As composite particles, beam energy must be
  considerably higher than for leptons

6
Muons

• Clearly a whole new window into electroweak
  processes
• A path to the energy frontier
• Radiative processes are far from limiting (as for
  electrons)
• Circular machine is possible, as are
  recirculating linacs
• Lepton, so beam energy and machine size are
  significantly lower than for protons
• For S-channel Higgs production, cross-section
  m2 40,000 times larger than for ee-.

7
Muons
A 5 TeV muon collider could fit on the
existingFermilab site.
Ankenbrandt et al., PRST-AB 2, 081001 (1999)
8
The Major Challenges

• Muons decay in 2.2 microseconds
• Muons are created with a very large emittance,
  too large for conventional accelerators, too
  large to give reasonable luminosity
• Muon production from 8-40 GeV protons scales
  roughly as proton beam power, independent of
  energy
• A 1 to 4 Megawatt proton beam is required
• The production target is also a challenge
• Muons decay into an electron plus neutrinos
• Electron backgrounds in detector
• Neutrino radiation problem (!)

9
Reducing the Phase Space Cooling

• Loosely the muons produced occupy the size of a
  beach ball (60 cm), the ILC accelerating cavities
  can accept a BB (4 mm)
• take advantage of ILC RD and optimization.
• overall reduction in phase space 106.
• Luminosity N2e--2 so lower transverse
  emittance permits a reduction in N (which reduces
  other problems).
• Must select a process that avoids Liouvilles
  theorem.
• Must select a method consistent with the muon
  lifetime (2.2 µsec).
• Desirable to select a method consistent with the
  peak momentum of the produced muons (300 MeV/c).

10
Muon Ionization Cooling
p- reduced, p unchanged
Absorber dp/dz -p
RF Cavity dp/dz z

• Alternate absorbers and RF cavities
• RF cavities restore the energy lost in the
  absorbers
• A factor of 1/e reduction in transverse phase
  space occurs when the total energy lost in
  absorbers equals the beam energy (both planes)
• Optimal energy corresponds to a momentum of
  100-250 MeV/c
• Works only for muons (electrons shower, hadrons
  interact)
• Transverse cooling only (small longitudinal
  heating due to straggling)

(Skrinsky Parkhomchuk, 1981)
11
Muon Ionization Cooling
Transverse Emittance change per unit length in
the absorber
Heating term (multiple scattering)
Cooling term (energy loss)

• Want
• Lower ß- (stronger focusing at the absorber)
• Minimize multiple scattering
• Maximize energy loss

Lattice design
Absorber Material
Here ? is the normalized emittance, Eµ is the
muon energy, dEµ/ds and X0 are the energy loss
and radiation length of the absorber material, ??
is the transverse beta-function of the magnetic
channel, and ? is the particle velocity.
12
Absorber Materials
Fcool (Energy Loss) / (Multiple Scattering)
13
Emittance Exchange
Ionization cooling is only transverse. To get
longitudinal cooling,use emittance exchange.
14
Innovation Helical Cooling Channel
These coils just surround the beam region. All
coils are normal to the Z axis their centers are
offset in X and Y to form the helix. The helical
solenoid is filled with a continuous absorber,
and perhaps with RF cavities.
Beam Follows Helix

• Cools in all 6 dimensions higher-energy
  particles have longer path length in the absorber
• A remarkable thing occurs for specific values of
  the geometry, the solenoid, helical dipole, and
  helical quadrupole fields are all correct.
• With absorber and RF, parameters remain constant
  with absorber only, parameters decrease with
  momentum.
• Acceptance is quite large compared to most
  accelerator structures.

15
HCC Simulation

• Four sequential HCCs with decreasing diameter and
  period, increasing field (8 T max)
• Emittance reduction is 50,000 over 160 m(15
  decay)
• In the analogy of starting with a beach ball and
  needing a BB, this is a small marble (1 cm dia.)

16
Related Innovation Guggenheim Cooling Channel

• Helix with radius gtgt period
• Also capable of emittance exchange
• More like a ring cooler that has been stretched
  vertically

Figure is mine concept is Palmer et al, BNL
17
Innovation High Pressure Gas RF Cavities

• High-pressure hydrogen reduces breakdown via the
  Paschen effect
• No decrease in maximum gradient with magnetic
  field
• Need beam tests to show HPRF actually works for
  this application.

805MHz
18
Innovation High Pressure Gas RF Cavities

• Copper plated, stainless-steel, 805 MHz test cell
• H2 gas to 1600 psi and 77 K
• Paschen curve verified (at Fermilabs Lab G and
  MuCool Test Area)
• Maximum gradient limited by breakdown of metal
• Fast conditioning seen
• Unlike vacuum cavities, theres no measurable
  limitation for magnetic field!

19
Understanding RF Breakdown
Scanning electron microscope images Be (top) and
Mo (bottom).
20
Innovation Parametric Resonance Ionization
Cooling

• Clever method to greatly reduce ?? without
  increased magnetic fields.
• Excite ½ integer parametric resonance (in Linac
  or ring)
• Like vertical rigid pendulum or ½-integer
  extraction
• Elliptical phase space motion becomes hyperbolic
• Use xxconst to reduce x, increase x
• Use IC to reduce x
• Detuning issues are being addressed (chromatic
  and spherical aberrations, space-charge tune
  spread). Simulations are underway.
• Smaller beams from 6D HCC cooling are essential
  for this to work!

X
X
X
X
21
Innovation Reverse Emittance Exchange

• p(cooling)200MeV/c, p(colliding)2.5 TeV/c ?
  room in ?p/p space
• After cooling and acceleration, the beam has much
  smaller longitudinal emittance than necessary.
• Reduce transverse emittance to increase
  luminosity, trading it for increased longitudinal
  emittance (limited by accelerator acceptance and
  interaction point ?).

22
Innovation Bunch Coalescing

• Start with 100 MeV/c cooled bunch train.
• Accelerate to 20 GeV/c with high-frequency RF.
• Apply low-frequency RF to rotate the bunches
  longitudinally.
• Permit them to drift together in time.
• Avoids space charge problems at low energy.

23
Innovation Dual-Use Linac

• Fermilab is considering Project X, a
  high-intensity 8 GeV superconducting linac
• Use it also to accelerate muons (after cooling)

NeutrinoFactoryaimed atSoudan, MN
24
Innovation Pulsed Recirculating Linac

• Accelerating from 20 GeV to 2,500 GeV requires a
  lot of RF!
• Muon decay dictates high ratio of RF/length.
• A dogbone recirculating linac is a reasonable
  trade-off between cost, size, and muon decay.
• By pulsing the quadrupoles of the linac, more
  passes can be made without losing transverse
  focusing.
• This linac is several km long, so pulsing is
  feasible.
• With careful design this can handle both µ and
  µ (time offset in RF cavities, FODO vs DOFO
  lattice, travel opposite directions in arcs).

Injection
Extraction
Linac
25
Innovation High-Field HTS Superconducting Magnets

• The high-temperature superconductors have a
  remarkable property at low temperature (2-4 K)
  they sustain a high current density at large
  magnetic fields.
• Measured up to 40 T, expected to hold to even
  higher fields.
• It is likely that solenoids in the range of 30 T
  to 50 T can be constructed.
• Higher field ? lower ??, so lower emittance can
  be achieved via ionization cooling.
• These materials are a challenge to work with

26
Many New Arrows in the Quiver

• New Ionization Cooling Techniques
• Helical Cooling Channel
• Momentum-dependent Helical Cooling Channel
• Guggenheim cooling channel
• Ionization cooling using a parametric resonance
• Methods to manipulate phase space partitions
• Reverse emittance exchange using absorbers
• Bunch coalescing (neutrino factory and muon
  collider share injector)
• Technology for better cooling
• Pressurized RF cavities
• High Temperature Superconductor for up to 50 T
  magnets
• Acceleration Techniques
• Dual-use Linac
• Pulsed Recirculating Linac

27
Conceptual Block Diagram of a Muon Collider
Proton Driver(8-40 GeV)
ProductionTarget
Pion Capture, Decay Channel,Phase Rotation, and
Pre-Cooling
Muon Ionization Cooling
Acceleration(0.2 to 20 GeV)
Reverse EmittanceExchange
Bunch Coalescing
Acceleration (20 to 2,500 GeV)
Storage Ring andInteraction Regions
Experiments
Must of course deal with both µ and µ-.
28
Fernow-Neuffer Plot
Start Cooling After Capture, Decay, Phase
Rotation, Pre-Cooling
End CoolingStart Acceleration to2.5 TeV
HCC 400 MHz
REMEX Coalescing
HCC 800 MHz
PIC
HCC 1600 MHz
AccelerationTo 20 GeV
29
Viewgraph-level Design
2.5 2.5 TeV muon storage ring with two IRs 1 km
radius ( Fermilab Main Ring,but its not deep
enough)
L 1035 cm-2 s-1
µ
2.5 km ILC-like linacs
10 recirculating arcs In one tunnel
µ
Final cooling, preacceleration
Helical cooling channel
Target, pion capture, Phase rotation
Proton driver
30
Related Facility Neutrino Factory

• Muons in a storage ring with a long straight
  section aimed at the far neutrino detector
• Concept is more fleshed out that a muon collider
• Cheaper, of striking current interest, perhaps
  more feasible
• Thousands of times more neutrino intensity than
  alternatives
• Higher energy neutrinos, with narrower energy
  spectrum
• Essentially perfect purity (no p decays) great
  for wrong-sign appearance measurements of
  oscillation
• Near detector looks a lot like old fixed-target
  hadron experiments
• 30 cm liquid hydrogen target
• Event rate 1-100 Hz
• Must be careful about material (spontaneous
  muons!)

31
Neutrino Factory
32
Current RD Efforts

• Six different (but greatly overlapping)
  collaborations, more than 200 physicists
• Neutrino Factory and Muon Collider Collab.
• Umbrella U.S. collaboration
• MERIT Collab.
• Mercury jet target in 15 Tesla solenoid
• 24 GeV protons at CERN
• Analyzing data
• MuCool Collab.
• Engineering studies for individual components
• 4 years of studies so far, at Fermilab
• Test beam (400 MeV H-) SUMMER
• MICE Collab.
• Single-particle demonstration of emittance
  reduction
• First muon Beam (140-300 MeV/c µ) Real Soon
  Now
• MANX Collab.
• Just forming
• Fermilabs Muon Collider task Force
• Plus other Neutrino Factory organizations

33
Merit Target Test

• High-power target test using a mercury jet in a
  15 T solenoid, at CERN
• Data taking completed last fall, data analysis in
  progress
• Preliminary conclusion concept validated up to 4
  MW at 50 Hz

34
MuCool
Tests in progress at Fermilab MuCool Test Area
(MTA) near Linac, with full-scale (201 MHz) and
1/4-scale (805 MHz) closed-cell (pillbox)
cavities with novel Be windows for higher
on-axis field
35
MICE(10 4d Cooling in 5.5 m)

• Installation in ISIS R5.2 is progressing
• Beamline commissioning Real soon now (2-3
  weeks)
• A month or two until beamline is complete
• Summer or fall until trackers are complete

36
The MANX Experiment(500 6d Cooling in 4 m)

• Purpose is to demonstrate the Helical Cooling
  Channel.
• Could well become a Phase III of MICE
  (total is 2.5 m longer than MICE Stage VI
  fits in hall).

37
Summary

• A number of clever innovations have made a Muon
  Collider much more feasible than previously
  thought.
• To make it possible to actually construct such a
  new facility, an ongoing program of research and
  development is essential.
• We are hosting a Low Emittance Muon Collider
  Workshop, at Fermilab in April.
• There is lots to do come join us!
• http//www.muonsinc.com
