Asset Management

1
Asset Management

• Lecture 21

2
Outline

• Technical analysis
• Bar Charts and Japanese Candlestick Charts
• Major Chart Patterns
• Price-based Indicators
• Volume-based Indicators

3
(No Transcript)
4
Introduction

• Technical analysis is the attempt to forecast
  stock prices on the basis of market data.
• Technicians usually look at price, volume and
  psychological indicators over time.
• Focus on trends and patterns in the data that
  indicate future price movements.
• Strict chartists dont care about fundamentals at
  all.
• Focus on short-term forecasts

5
Drawing Bar (OHLC) Charts

• Each bar is composed of 4 elements
• Open
• High
• Low
• Close
• Note that the candlestick body is empty (white)
  on up days, and filled (some color) on down days

6
Types of Charts Bar Charts

• This is a bar (open, high, low, close or OHLC)
  chart of AMAT from early July to mid October
  2001.

7
Types of Charts Japanese Candlesticks

• This is a Japanese Candlestick (open, high, low,
  close) chart of AMAT from early July to mid
  October 2001

8
Basic Technical Tools

• Trend Lines
• Moving Averages
• Price Patterns
• Indicators

9
Trend Lines

• There are three basic kinds of trends
• An Up trend where prices are generally
  increasing.
• A Down trend where prices are generally
  decreasing.
• A Trading Range.

10
Support Resistance

• Support and resistance lines indicate likely ends
  of trends.
• Resistance results from the inability to surpass
  prior highs.
• Support results from the inability to break below
  to prior lows.
• What was support becomes resistance, and
  vice-versa.

Breakout
Support
Resistance
11
Simple Moving Averages

• SMA over the last N periods.

12
Interactive Example

• finance.yahoo.com
• Ticker GOOG
• Charts basic tech. analysis

13
Head and Shoulders

• Two small peaks on either side of a larger peak.
• Reversal pattern

14
Head Shoulders Example
Sell Signal
Minimum Target Price Based on measurement rule
15
Double Tops and Bottoms

• Similar to the HS formations, but withough head.
• Reversal patterns

16
Double Bottom Example
17
Triangles

• Continuation formations.
• Three flavors
• Ascending
• Descending
• Symmetrical
• Typically break out about half to three-quarters
  of the way through the formation.

18
Rounded Tops Bottoms

• Slow reversal of trend.

19
Rounded Bottom Chart Example
20
Broadening Formations

• Reverse triangles.
• Usually signal a reversal of the trend.

21
DJIA Oct 2000 to Oct 2001 Example
What could you have known, and when could you
have known it?
22
DJIA Oct 2000 to Oct 2001 Example
Nov to Mar Trading range
Descending triangles
Gap, should get filled
Double bottom
23
Technical Indicators

• Moving Average Convergence/Divergence (MACD)
• Relative Strength Index (RSI)
• Bollinger Bands

24
MACD

• A moving average crossover system.
• The difference between a 12-day and 26-day moving
  average.
• A 9-day moving average of this difference is used
  to generate signals.
• Bullish this signal line goes from negative to
  positive
• Bearish the signal line goes from positive to
  negative

25
MACD Example Chart
26
Relative Strength Index (RSI)

• To indicate overbought/oversold levels.
• RSI compares the magnitude of a stock's recent
  gains to the magnitude of its recent losses and
  turns that information into a number that ranges
  from 0 to 100.
• Overbought RSIgt70
• Oversold RSIlt30
• Stocks can remain overbought or oversold for long
  periods of time.

27
RSI Example Chart
Overbought
Oversold
28
Bollinger Bands

• Bollinger Bands Upper and lower bands defined by
  two standard deviations above and below the
  moving average.
• Bullish The stock price closes below the lower
  band
• Bearish The stock price closes above the upper
  band.
• When the bands contract, that is a signal that a
  big move is coming, but it is impossible to say
  if it will be up or down.

29
Bollinger Bands Example Chart
Sell signal
Buy signals
30
On Balance Volume

• Volume precedes price
• Adding volume on up days, and subtracting volume
  on down days.
• Look for OBV to show a change in trend that is
  diverging from the price trend.

31
OBV Example Chart
