Ch. 6

1
Ch. 6 Thermal Energy
2
Sec. 1 Temperature Heat
ENERGY
Kinetic (KE)
Potential (PE)
Energy of Motion
Energy Stored
3

• Temperature
• Average KE of an objects atoms or molecules
• Measured with a thermometer

4
Temperature Scale Conversions

• 0C K 273
• K 0C 273
• 0F (9/5) x 0C 32
• 0C (5/9) x (0F 32)

What is 00C in K and 0F?
273 K and 32 0F
5
(No Transcript)
6
Thermal Energy KE PE of all atoms in an object
Thermal Energy Temperature
Thermal Energy Mass
7
Heat thermal energy that flows from higher temp
to a lower temp
Units Joules (J) or calories (cal)
8
Specific Heat amount of energy needed to raise
the temp of 1 kg of a material by 1 degree C of K
In other words How fast does a material get hot
or cold? Which has a higher specific heat? Water
or Iron
9
Q m x T x C
Temp (C)
Specific heat (cal/g 0C) or (J/g 0C)
Heat (cal or J)
Mass (g)
Change in
Calculations
10
() Change in Temp heat flows into an object
Melting ice
11
(-) Change in Temp Heat flows out of an object
Freezing a Popsicle
12
Calorimeter Measures specific heat
13
Sec. 2 Transferring Thermal Energy
14
3 Types of Heat Transfer
15
CONDUCTION by touch or contact KE is
transferred as particles collide
16

• CONVECTION
• the movement of heated particles in a fluid
  (liquid or gas)
• Creates circular currents

17
Convection currents create climates.
18
RADIATION heat transfer by electromagnetic waves
Fastest in gases
19
How do these animals control the flow of heat?
20
Conductor vs. Insulator

• Heat doesnt move easily
• Gases
• Ex Thermos, Air, Plastic

• Heat moves easily
• Solids
• Ex Metals
