Profiling S3D on Cray XT3 using TAU

1
Profiling S3D on Cray XT3 using TAU

• Sameer Shende
• tau-team_at_cs.uoregon.edu

2
Acknowledgements

• Alan Morris UO
• Kevin Huck UO
• Allen D. Malony UO
• Kenneth Roche ORNL
• Bronis R. de Supinski LLNL

3
TAU Parallel Performance System

• http//www.cs.uoregon.edu/research/tau/
• Multi-level performance instrumentation
• Multi-language automatic source instrumentation
• Flexible and configurable performance measurement
• Widely-ported parallel performance profiling
  system
• Computer system architectures and operating
  systems
• Different programming languages and compilers
• Support for multiple parallel programming
  paradigms
• Multi-threading, message passing, mixed-mode,
  hybrid

4
TAU Performance System Architecture
event selection
5
TAU Performance System Architecture
6
Program Database Toolkit (PDT)
Application / Library
C / C parser
Fortran parser F77/90/95
Program documentation
PDBhtml
Application component glue
IL
IL
SILOON
C / C IL analyzer
Fortran IL analyzer
C / F90/95 interoperability
CHASM
Program Database Files
Automatic source instrumentation
TAU_instr
DUCTAPE
7
PAPI

• Performance Application Programming Interface
• The purpose of the PAPI project is to design,
  standardize and implement a portable and
  efficient API to access the hardware performance
  monitor counters found on most modern
  microprocessors.
• Parallel Tools Consortium project
• Developed by University of Tennessee, Knoxville
• http//icl.cs.utk.edu/papi/

8
S3D - Building with TAU

• Change name of compiler in build/make.XT3
• ftngt tau_f90.sh
• cc gt tau_cc.sh
• Set compile time environment variables
• setenv TAU_MAKEFILE /spin/proj/perc/TOOLS/tau_late
  st/xt3/lib/ Makefile.tau-callpath-multiplecounte
  rs-mpi-papi-pdt-pgi
• Choose callpath, PAPI counters, MPI profiling,
  PDT for source instrumentation
• setenv TAU_OPTIONS -optTauSelectFileselect.tau
  -optPreProcess
• Selective instrumentation file eliminates
  instrumentation in lightweight routines
• Pre-process Fortran source code using cpp before
  compiling
• Set runtime environment variables for
  instrumentation control and event PAPI counter
  selection in job submission script
• export TAU_THROTTLE1
• export COUNTER1 GET_TIME_OF_DAY
• export COUNTER2 PAPI_FP_INS
• export COUNTER3 PAPI_L1_DCM
• export COUNTER4 PAPI_RES_STL
• export COUNTER5 PAPI_L2_DCM

9
Selective Instrumentation in TAU
cat select.tau BEGIN_EXCLUDE_LIST MCADIF GETRATE
S TRANSPORT_MMCAVIS_NEW MCEDIF MCACON CKYTCP THE
RMCHEM_MMIXCP THERMCHEM_MMIXENTH THERMCHEM_M
GIBBSENRG_ALL_DIMT CKRHOY MCEVAL4 THERMCHEM_MHIS
THERMCHEM_MCPS THERMCHEM_MENTROPY END_EXCLUDE
_LIST BEGIN_INSTRUMENT_SECTION loops
routine"" END_INSTRUMENT_SECTION
10
TAUs ParaProf Profile Browser - Manager
Derived Metrics Flops PAPI_FP_INS/wallclock time
11
Main Window - 8 cpus (MPI Ranks 0-7)
Some routines execute on different sets of
processors
12
Mean Profile Over 8 cpus -- Exclusive Time
13
Mean Percentage -- Exclusive Time
14
Loop Level Profile With PAPI Counter Data
15
ParaProfs Source Browser
16
Exclusive MFLOPS
17
FP Instructions per L1 Data Cache Miss (rank 0)
18
Level 1 Data Cache Misses
19
Callpath Profiles
20
Callpath Profiles Flops, Resource Stalls
21
Callpath Thread Relations Window
parent
routine
children
22
Flat Profile
23
TAUs ParaProf Profile Browser - Manager
Different sections of code within the same
routine execute on odd and even processors!
24
3D Window Rank, Routine, Time, Instructions
25
3D Window Variations in FP/L1 DCM ratios
26
Getting Access to TAU on Jaguar

• set path(/spin/proj/perc/TOOLS/tau_latest/x86_64/
  bin path)
• Choose Stub Makefiles (TAU_MAKEFILE env. var.)
  from /spin/proj/perc/TOOLS/tau_latest/xt3/lib/Make
  file.
• Makefile.tau-mpi-pdt-pgi (flat profile)
• Makefile.tau-mpi-pdt-pgi-trace (event trace, for
  use with Vampir)
• Makefile.tau-callpath-mpi-pdt-pgi (single metric,
  callpath profile)
• Binaries of S3D can be found in
• sameer/scratch/S3D-BINARIES
• withtau
• papi, multiplecounters, mpi, pdt, pgi options
• without_tau
