Higher%20Computing%20Computer%20Systems

1
Higher Computing Computer Systems

• Computer Software

2
What is an operating system

• The operating system is a program that controls
  the entire operation of the computer and devices
  which are attached to it
• Most of the OS is permanently stored on hard disk
  and loaded in to RAM when the computer is on

3
The bootstrap loader

• When the computer is switched on the initial part
  of the OS is loaded from chip (ROM)
• The bootstrap loaders function is to load the
  rest of the OS from disk

4
The single user operating system

• A SUOS is only capable of being used by one
  person at a time
• The main functions of a SUOS are
• Interpreting users commands (CLI)
• File management
• Memory management
• I/O management
• Managing processes
• Resource allocation

5
The Command Language Interpreter

• The CLI is the layer with which the user
  interacts in order to give instructions to the
  computer it interprets user commands

6
File management

• The FMS is concerned with the efficient use of
  the computers backing storage devices and media
• The FMS holds the details of where each file (or
  part of) is held on the disk
• The FMS is also known as the Disk Operating System

7
Memory management

• The MMS controls where programs and data are
  placed in main memory
• The MMS keeps track of the total amount of main
  memory available and which programs and data are
  currently loaded

8
Input/Output management

• The I/OMS communicates directly with the
  peripheral devices
• The I/OMS handles the transfer of data between
  the peripherals and the processor

9
Process management the kernel

• The kernel is the part of the OS which is
  responsible for managing interrupts
• e.g. from the printer
• The kernel is responsible for managing processes
• from the CLI e.g. copy. A process initiated by
  the CLI may result in an interrupt

10
Resource allocation

• RS is the way of managing which resource is
  available for use at any one time by a process
• Efficient RS ensures that the processor is kept
  busy, by maintaining a queue of processes that
  are always ready for the processor
• A scheduler prioritises the queue

11
The OS working - an example

• Loading the file myfile from disk
• Using the CLI you issue the command to open a
  folder
• The kernel interrupts the current CLI process and
  passes the request to the FMS
• The FMS requests the I/O system to read the
  disks catalog track and loads a list of file
  names
• The CLI allows the user to choose the filename
  myfile from the list
• The FMS passes the physical location of the file
  to the I/O system
• The I/O system loads the file from disk and hands
  it over to the MMS
• The MMS places the file in the main memory and
  you again have control of the computer

12
Utility programs

• UPs can be part of the OS or a separate program
• Virus checker
• Disc editor
• Defragmenter
• Backup
• Emulators
• Converters, compressors and expanders
• Email and web filters

13
Virus checker

• A virus checker is a utility program which is
  designed to check a computer system for viruses
• A virus checker will then remove the virus
• Virus checkers have to be kept up to date in
  order to be effective against new viruses

14
Disc editor

• A disc editor allows the user to edit data
  directly on the surface of a disk
• DE programs incorporate automatic disk repair and
  data recovery functions
• Newer hard drives smart drives have their own
  software for which monitors the performance of
  the drive

15
Defragmenter

• Files are often split and saved on different
  parts of a disk
• This increases the time taken to access the file
• A defragmenter gathers all the free space on the
  disk together and reunites all the fragmented
  files that can be accommodated

16
Before defragmenting
After defragmenting








Used block
unused block
17
Backup

• Backup software can help to automate the process
  of making regular backups
• Backup software can allow you to synchronise
  files between two devices or media
• When two copies of the same file exist on
  different media the newer copy will replace the
  older version

18
Emulators

• An emulator is a program that allows one type of
  computer to behave as if it was a completely
  different type
• A computer running emulator software will run
  much slower than the computer it is emulating
• Virtual PC allows apple computers to emulate
  Windows OS computers

19
Converters, compressors and expanders

• Converters change the format of a data file from
  one application type to another
• Compressors reduce the size of a data file
• Expanders decompress a compressed data file

20
Printer drivers

• A program that takes the codes in the document
  and translates them into the appropriate code for
  the printer in use

21
Email and web filters

• An email filter is software that monitors emails
  which are sent on a network
• The Regulation of Investigatory Powers Act (2000)
  gives employers the right to monitor employees
  email
• A web filter monitors URLs and the content of web
  pages be accessed by the user

22
File formats

• Standard file formats have been developed to ease
  the transfer of data between software developed
  by different manufacturers e.g. text files - RTF
• Each type of application software has its own set
  of standard file formats e.g. JPEG used in
  photographic manipulation software

23
File formats - GIF

• Graphics Interchange Format
• For low resolution bit-map colour graphics
• 256 colours possible
• Compressed files
• Fast to load and transfer via internet
• Interlacing allowed
• Animations also possible
• GIF uses lossless compression

24
File formats JPEG, MPEG

• Joint Photographic Experts Group
• Standard for still picture compression
• 16.7 million colours
• Uses lossy compression
• Typically achieves 10 to 1 compression with
  little perceivable loss in image quality
• Motion Pictures Expert Group
• Standard for moving pictures

25
File formats - TIFF

• Tag(ged) Image File Format
• For high resolution bit-map images
• Large files unsuitable for WWW
• Uncompressed
• Used by DTP, book and magazine printing

26
Matching software to tasks (1)

• Production of a multimedia catalogue
• Multimedia authoring package e.g. Macromedia
  Director
• Additional software for editing individual
  elements
• Video
• Audio
• Graphic
• Text
• And
• CD or DVD writing software

27
Matching software to tasks (2)

• Setting up a LAN in a school
• Modern OS capable of peer to peer networking
• Client server needs network OS software
• Database servers need specific software e.g.
  Microsoft SQL
• Database application such as Filemaker Pro are
  available in single or network versions

28
Matching software to tasks (3)

• Development of a school website
• Web page creation software with WYSIWYG page
  editing
• Additional software for editing individual
  elements
• Video
• Audio
• Graphic
• Text
• And
• Testing using a range of browser software

29
Software compatibility issues

• Software that works on a computer system is said
  to be compatible
• Issues that can affect the compatibility of the
  software are
• Memory requirements
• Storage requirements
• OS compatibility

30
Memory requirements (RAM)

• If a system cannot meet the minimum RAM
  requirements to run the software the software
  will not run
• If there is insufficient RAM to hold the complete
  program then part of it will be stored on disk,
  virtual memory
• Running programs using VM will slow the program

31
Storage requirements

• Full installation - The amount of backing storage
  needed to hold the complete program after
  installation (and decompression)
• Minimal installation The least amount of
  storage requirement needed to run the program,
  normally the installation CD is still needed to
  run the program

32
OS compatibility

• Three main OS used on desktops and laptops
• Windows
• Unix
• Apple OS
• Users need the correct version of software for
  the different OS
• Windows OS not always backward compatible

33
Viruses

• A virus is a program which can destroy or cause
  damage to data stored on a computer system
• A virus infects host files and is distributed
  along with them

34
Worm

• A worm is a virus that can make copies of itself
  and spread between computers without having to be
  attached to a file

35
Trojan horses

• A Trojan horse is disguised as another type of
  file

36
What viruses infect

• A virus may infect different parts of the
  computer system
• File viruses
• Boot sector viruses
• Macro viruses

37
File viruses

• File viruses attach themselves to files
• They add malicious code into the files
• Typical files that are infected are Windows OS
  files with .COM and .EXE extensions

38
Boot sector viruses

• All magnetic disks contain a boot sector
• The boot code can become infected with a virus
  and is loaded when the machine is rebooted
• Less common now that floppy discs are no longer
  in popular use

39
Macro viruses

• A macro virus infects documents e.g. spreadsheets
  or word processing documents
• A macro virus causes a malicious series of events
  once the document is opened
• The macro virus will also infect any new
  documents created by the same application

40
Virus code actions

• Virus act differently according to how they are
  programmed
• The action the virus may carry out when run
  include
• Replication
• Camouflage
• Watching
• Delivery

41
Replication

• A worm can make copies of itself this is known as
  replication

42
Camouflage

• Mixed in with good code
• Malicious or false code is changed every time it
  runs to avoid detection
• Disguise the code so that it looks harmless
• All these techniques are used to avoid detection
  by anti-virus programs

43
Watching

• Sleeper virus lays in wait for a particular sign
  which will activate it
• A date or time or action
• Time bomb (triggered by a date)
• Logic bomb (triggered by an action)

44
Delivery

• The method used by the virus to enter the system
• Shared backing storage devices
• Connected to the internet
• Web pages
• Downloads
• Emails
• Email attachments

45
Anti-virus detection

• Anti-virus software detection techniques include
• Use of checksum
• Searching for virus signature
• Heuristic detection
• Memory resident monitoring

46
Use of checksum (1)

• A checksum is a value calculated for a given set
  of data
• The answer to the calculation is the checksum
• It is used to check that data has been
  transmitted and received correctly

47
Use of checksum (2)

• The checksum is transmitted along with the data
• The receiving computer performs the same
  calculation and checks the sum
• If they are the same its ok
• If the dont match the anti-virus software will
  issue a virus warning

48
Searching for virus signature

• Anti-virus programs can find viruses inside
  programs by scanning them for virus signatures
• A virus signature is a characteristic pattern in
  a file
• These files can then be disinfected
• Polymorphic viruses modify their code to avoid
  virus signature detection

49
Heuristic detection

• Detect viruses a heuristic or rule of thumb
  method
• Imprecise method although useful
• If it looks like a virus and behaves like a virus
  then its probably a virus
• Used to detect new viruses

50
Memory resident monitoring

• Anti-virus software that loads in to the
  computers memory on start up
• Monitors all programs and data loaded in to the
  computers memory
• Can slow down the processing speed of a computer
  as everything is checked for viruses

51
The End
