Testing: General Requirements, DFT, Multilevel Testing

1
Testing General Requirements, DFT, Multilevel
Testing
Testing General Requirements DFT Multilevel
Testing-- System, Black Box, White or Glass Box
Tests
2
Testing--General Requirements and Strategies

• Testing--general requirements
• thorough
• ongoing
• DEVELOPED WITH DESIGN (DFT--design for test)
  note this implies that several LEVELS of
  testing will be carried out efficiently
• Carried out independently of design/implementation

• Testing--strategies
• Fault avoidance reduce possibility of faults
  through techniques such as configuration
  management, good development process
• Fault detection use debugging and testing to
  find and remove faults
• Fault tolerance (for remote systems or
  safety-critical systems, e.g.) use techniques
  such as 3 or more redundant modules, let them
  vote on what the output should be

3
Testing goals
At different points in the development cycle,
tests may have different goals,
e.g. --verification--functions correctly
implemented (according to specifications)
--validation--we are implementing the correct
functions (according to requirements)
4
Efficiency / How Thoroughly Can We Test?
gatesn2
Testing is difficult example VLSI
chip--200 inputs 2000 flipflops (one-bit
memory cells) exhaustive tests?
What is the overall time to test if we can
do1 test / msec? 1 test / msec? 1 test
/nsec? Testing functionality (as with the above
chip) is an example of an NP-complete problem,
i.e., a problem for which the only algorithms we
know to actually find the answer would take time
exponential in the problem size Testing software
is even harder, there are usually semantic issues
which are difficult to deal with
I/O4n
5
Good, Bad, and Successful Tests

• Psychology of testing
• good test has a high probability of finding an
  error
• ("bad test" not likely to find anything new)
• successful test finds a new error

6
Most Effective Testing Is Independent
most effective testing by an "independent third
party It is more difficult to see the errors
you have included in your own work --subconsciou
sly you want the system to work --you may know
what you intended and overlook what is actually
there --an independent tester brings a fresh
viewpoint to the question of what works and what
doesnt --testing requires expertise common
practice of putting the most inexperienced team
members in charge of testing is not really
effective Question what does this imply about
your team testing strategy for the quarter
project? What about in waterfall model? In XP?
7
Automated Testing
Automated testing Testing must be thorough and
must be repeated frequently during
development. Thus it is a good candidate for
automation. Example system for automated testing
in JavaJUnit (Fig. 11-29)
TestResult
Test run (TestResult)
TestCase
TestSuite
ConcreteTestCase
8
TestingUML extension
Example U2TPUML 2 Testing Profile (2005
extension to UML) Extends UML to allow the
modeling of testing Can be used with manual or
automated testing Example Figure
11-31 ----Context organize test cases, test
components, system under test (SUT) ----Components
set up tests ----SUT what is being tested
9
TestingUML extension
Example UML interaction diagram to describe
testing ref www.site.uottawa.ca/awilliam/csi511
8_w08/UMLTestingProfile.ppt
10
Matching Testing with Design and Language
How will testing match with design/language? e.g.
procedural example--sort an arrayprogram
has access to all array information oo
example--develop an "array classonly the owner
class and friends have direct access to the
array structure what kinds of test need to be
done in each case? Can you trust that the array
class has tested its sorting routine sufficiently?
11
Design for Testability (DFT)

• Design for Testability (DFT)--what makes software
  "testable"?
• understandability you understand module,
  inputs, and outputs
• decomposability you can decompose into smaller
  problems and test each separately
• operability only a few errors
  possible--incremental test strategy
• controllability you can control state input
  to test
• observability you can see the results of the
  test
• simplicity you choose the simplest solution
  that will work
• stability same test will give same results
  each time

12
Design for Testability (DFT) useful strategies
Some useful strategies --pretest test before
carrying out an action example test divisor
is not zero before division --posttest test
that you got a valid result example if you
are calculating a grade, test that the
result is between 0 and 100 --invariant test
that iterations dont change value/range
example test that loop counter stays within
bounds
13
Spiral design/testing strategy
A general design/testing strategy can be
described as a "spiral requirements ? design
? code system test ?module,integ. tests ?unit
test (system) (black
(white box) box) when
is testing complete? One model "logarithmic
Poisson model f(t)(1/p)ln(I0pt1) f(t)
cumulative expected failures at time t I0
failures per time unit at beginning of testing p
reduction rate in failure intensity
Design/Module Tests
Code/Unit Tests
Design/Integration Tests
START
END
Requirements, Specs/System Tests
14
Development and Testing Stages
levels of test development stage
white or glass box code black box
class integration class (ER) diagram
system use case
We will use these stages for the quarter
project. We will use a modified XP strategy
----develop test with design at each
stage ----during implementation, all tests must
be passed (100) ----if modifications are made,
all tests must be rerun ----if errors are found,
new tests must be written to cover them
(regression testing) ----complete test suite,
updated during development, must be maintained
15
Types of testing

• Types of testing
• white box--"internals (also called "glass
  box")
• black boxmodules and their "interfaces (also
  called "behavioral")
• system--functionality (can be based on specs,
  use cases)
• application-specific--
• GUIs
• Client/Server
• Real-time (e.g. drug dosage monitor thermostat)
• Documentation/help

16
Good testing strategy

• steps in good test strategy
• quantified requirements
• test objectives explicit
• user requirements clear
• use "rapid cycle testing"
• build self-testing software
• filter errors by technical reviews
• review test cases and strategy formally also
• continually improve testing process

17
OO testing strategy

• OO testing
• emphasis is on interfaces
• use UML tools to support testing strategies and
  development of test cases
• --system tests use cases quality measurements
• --black box tests ER diagrams, object message
  diagrams,dataflow and state diagrams
• --white box tests class and state diagrams, CRC
  cards

18
Using specifications for system tests
System tests should verify that specifications
have been met For UML-based strategy each
use case ---gt one or more system tests each
quality / performance requirement ? one or
more system tests Additional qualitative or
quantitative tests (not from use
cases) examples is system user-friendly? a
re timing requirements met? are available
resources sufficient?
19
Using specifications for system tests
Example
Associated sequence diagrams 1. 2. 3.

Cellular

network


2. Receive call






Associated test cases 1. 2. 3.
3. Use

scheduler


User





3 use cases

Tests verify use case supported
20
Black box testing--what to test

• black box testing test functional requirements
  of components.
• Must check
• incorrect or missing components
• interface errors
• data structures or external data access
• behavior /performance errors
• initialization and termination errors

21
Black box testing--testing graph

• start point is usually a graph
• objects to be modeled
• relationships connecting them ("links")
• link properties
• example can use ER diagrams, object message
  diagrams, state diagrams, with additional
  information on links as necessary

22
Black box testing--examples

• Examples

Denotes link that leads to one or more test cases
23
Black box testing techniques

• Some useful techniques for black box testing
• transaction flow
• data flow
• state modeling
• timing modeling
• (all "dynamic")
• much testing focuses on "boundary values" between
  components

24
Black box testing--input partitioning
example equivalence partitioning for input for
black box test condition cases of
input Range 1 valid, 2 invalid example 0 lt
x lt 10 test x ? value 1 valid, 2
invalid example y 7 test y ? set
member 1 valid, 1 invalid example j is even
test j ? boolean 1 valid, 1 invalid
25
Black box testing guidelines
General guidelines test BOUNDARIES test
output also choose "orthogonal cases if
possible
not
26
White box testing
White box testing we will look at specific
strategies later on (e.g., path testing)
