• Source parameters determination using
  moment tensor inversion

Panagiotis Papadimitriou, Alexandra Moshou,
Konstantinos Makropoulos Department of
Geophysics and Geothermics National and
Kapodistrian University of Athens
2
Contents
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• Determination of seismic parameters of an
  earthquake
• Methodology
• Bodywave modeling by calculation synthetic
  seismograms and fitting with observed
• Non linear inverse problem

• Seismic moment tensor, Mij
• Seismic source
• Depth

• Forward problem
• Inverse problem

3
Bodywave propagation
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
4
Seismic Faults
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• motion between two blocks
• the two sides of a block slippage relative to
  each other with a standard geometry

footwall
Slip vector
Hanging wall
5
Seismic fault plane
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
Slip 3 D representation
f azimuth of the fault plane with respect to
North, 0 lt f lt 360 d dip of the fault plane
from horizontal, 0 lt d lt 90 ? rake of the
direction of slip in the fault plane with
respect to the horizontal -180 lt ? lt 180

6
Calculation of Synthetic Seismograms
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
U(t) displacement seismogram s(t) seismic
source operator m(t) structure response
operator Q(t) attenuation operator I(t)
instrument response operator
7
Bodywave synthetic seismograms
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
8
Equivalent Body forces double couple
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
earthquake
Double couple
Focal mechanism
9
Equivalent body forces representing seismic
sources
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
Single Force
Single couple
Double couple
10

M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
General representation of seismic source using 9
force couples
11
Forward problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
Given initial
parameters of the model
Calculate synthetic seismograms and
comparison with the corresponding

observed Determine
the parameters of the model
by trial and error
12
Forward problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• G is a non square matrix (n x m) whose
  elements are a set of five elementary Greens
  functions.
• m a vector of length
• m 6 the six elements of the moment
  tensor
• m 7 six elements of the moment
  tensor
• depth
• m 9 six elements of the moment
  tensor source location (x, z, t)
• d a vector of length n observations

13
Inverse problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
Given field
observations
Determine parameters of the
model
14
Inverse problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• d n x 1 matrix," lives in data space of n
  components, represents the observed data set
• G non - square n x m matrix, greens function
• m m x 1 vector, the model vector m lives in
  model space of m components

15
Moment tensor inversion - methodology
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

u synthetics seismograms G Greens function m
model of parameters
16
Moment tensor inversion
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
Where n is the number of waveforms, when n gt 6,
the system is overdetermined and it is should be
possible to resolve the system. That means to
found the inverse of G.
17
Moment tensor inversion
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• To determine the model m must be inversed the
  matrix G
• G non square matrix
• The system is overdetermined
• Process 1) determination the transpose of the
• matrix G, GT
• 2) multiplication GTG
• 3) determination G-1
• The non square matrix G lives in work
  space n x m components. The matrix G maps a
  vector from model - space to a vector in data
  space, is composed by a set of five elementary
  Greens function

18
Methods for overcomplete system
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• Normal equations
• QR factorization
• SVD decomposition

19
Normal equations
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
The system of normal equations
and the solution is
pseudo inverse
where

• G non square, n x m

Square matrices
20
QR factorization
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
where

• Q orthogonal matrix, Gram Schmidt
  orthogonalization of G
• R upper triangular,

QR factorization transform the least square
problem into a triangular least - square
where
21
Singular value decomposition
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• Any real matrix G (n x m) can be decomposed in
  three parts

where

• U,V n x n, m x m orthogonal matrices
  respectively
• The columns of U,V are the eigenvectors
  , respectively
• ? unique n x m diagonal matrix, with real and
  non negative
• elements ?i ,(singular values of G) i 1,2, ,
  min (m, n) gt 0, in order

22
Singular value decomposition Determination G-1
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
The matrices U,V are orthogonal, that means
23
Singular value decomposition Determination G-1
M3ST International Conference on Modern
Mathematical Methods in Science and Technology
where
24
Singular value decomposition
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
25
Singular value decomposition
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
26
SVD decomposition
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• We do not need to know if the problem is
  overdetermined or undetermined. The singular
  values in S will show what kind of problem we are
  trying to solve. SVD always produces a solution.
• In the case that the problem is undetermined, SVD
  finds the solution in the complement null
  space. This is the minimum solution.

27
Normal equations QR factorization Singular
value decomposition
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• Normal equations and QR factorization only work
  for fully ranked matrices (i.e. r(A)n). If A
  is rank deficient, there are infinite number of
  solutions to the least squares problems.
• The algorithm of normal equations is the fastest
  and the least accurate among the three.
• Singular value decomposition is the slowest and
  the most accurate.

28
SVD Least squares
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
If the model fit exactly the data, then E is be a
vector with all elements approximate zero. Since
this will not usually be the case, the inverse
problem is designed to find a model that
minimizes E.
be minimum
29
Moment tensor inversion
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• Conditions for double couple solution
• det Mij 0
• trace M 0

30
General moment tensor
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
31
Earthquake Aigio 15/06/1995
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
32
Non linear problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• the problem becomes non linear

Because the derivative of the envelope misfit
function is non linear
33
Example of non linear problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
34
Non linear problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• Methodology for non linear inversion
  conditions

where
35
Non linear problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• where
• µ, 1-µ relative weights of the waveforms
  misfit function E1 (m) and the envelope misfit
  function E2 (m)
• ?1 , ?2 Lagrange multipliers associated with
  the constraints C1 (m), C2 (m)

• Conditions for non linear problem
• ? ? 0 or µ ? 0

36
Non linear problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• Linearization problem
• The source parameters mnew may be determined by
  solving the set of n equations

• Subject the constraint
• C2 (m) 0, when ?2 ? 0
• and
• C1 (m) 0, when ?1 ? 0

37
Non linear problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• In any event, an initial solution m0 is required
  to solve the equation (10). In our case we use
  point source parameters inverted using
  alternative methods as the starting solution. The
  synthetics can be linearize with respect to the
  initial source parameters

then (11) becomes
38
Non linear problem
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
where
39
Non linear problem methodology
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• Newtons method
• We define a vector
• and an initial solution vector

40
Non linear problem methodology
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology

• The (i 1) th iteration can be expressed as
• The source model parameters m, can be determine
  by iterating the following linear system with
  respect to x

41
Non linear problem methodology
M3ST06 International Conference on Modern
Mathematical Methods in Science and Technology
where
42
