Title: Text Databases


1
Text Databases
2
Outline
  • Spatial Databases
  • Temporal Databases
  • Spatio-temporal Databases
  • Data Mining
  • Multimedia Databases
  • Text databases
  • Image and video databases
  • Time Series databases

3
Text - Detailed outline
  • Text databases
  • problem
  • full text scanning
  • inversion
  • signature files (a.k.a. Bloom Filters)
  • Vector model and clustering
  • information filtering and LSI

4
Vector Space Model and Clustering
  • Keyword (free-text) queries (vs Boolean)
  • each document -gt vector (HOW?)
  • each query -gt vector
  • search for similar vectors

5
Vector Space Model and Clustering
  • main idea each document is a vector of size d d
    is the number of different terms in the database

document
zoo
aaron
data
indexing
...data...
d ( vocabulary size)
6
Document Vectors
  • Documents are represented as bags of words
  • Represented as vectors when used computationally
  • A vector is like an array of floating points
  • Has direction and magnitude
  • Each vector holds a place for every term in the
    collection
  • Therefore, most vectors are sparse

7
Document VectorsOne location for each word.
  • nova galaxy heat hwood film role diet fur
  • 10 5 3
  • 5 10
  • 10 8 7
  • 9 10 5
  • 10 10
  • 9 10
  • 5 7 9
  • 6 10 2 8
  • 7 5 1 3

A B C D E F G H I
Nova occurs 10 times in text A Galaxy occurs
5 times in text A Heat occurs 3 times in text
A (Blank means 0 occurrences.)
8
Document VectorsOne location for each word.
  • nova galaxy heat hwood film role diet fur
  • 10 5 3
  • 5 10
  • 10 8 7
  • 9 10 5
  • 10 10
  • 9 10
  • 5 7 9
  • 6 10 2 8
  • 7 5 1 3

A B C D E F G H I
Hollywood occurs 7 times in text I Film
occurs 5 times in text I Diet occurs 1 time in
text I Fur occurs 3 times in text I
9
Document Vectors
Document ids
  • nova galaxy heat hwood film role diet fur
  • 10 5 3
  • 5 10
  • 10 8 7
  • 9 10 5
  • 10 10
  • 9 10
  • 5 7 9
  • 6 10 2 8
  • 7 5 1 3

A B C D E F G H I
10
We Can Plot the Vectors
Star
Doc about movie stars
Doc about astronomy
Doc about mammal behavior
Diet
11
Vector Space Model and Clustering
  • Then, group nearby vectors together
  • Q1 cluster search?
  • Q2 cluster generation?
  • Two significant contributions
  • ranked output
  • relevance feedback

12
Vector Space Model and Clustering
  • cluster search visit the (k) closest
    superclusters continue recursively

MD TRs
CS TRs
13
Vector Space Model and Clustering
  • ranked output easy!

MD TRs
CS TRs
14
Vector Space Model and Clustering
  • relevance feedback (brilliant idea) Roccio73

MD TRs
CS TRs
15
Vector Space Model and Clustering
  • relevance feedback (brilliant idea) Roccio73
  • How?

MD TRs
CS TRs
16
Vector Space Model and Clustering
  • How? A by adding the good vectors and
    subtracting the bad ones

MD TRs
CS TRs
17
Cluster generation
  • Problem
  • given N points in V dimensions,
  • group them

18
Cluster generation
  • Problem
  • given N points in V dimensions,
  • group them (typically a k-means or AGNES is used)

19
Assigning Weights to Terms
  • Binary Weights
  • Raw term frequency
  • tf x idf
  • Recall the Zipf distribution
  • Want to weight terms highly if they are
  • frequent in relevant documents BUT
  • infrequent in the collection as a whole

20
Binary Weights
  • Only the presence (1) or absence (0) of a term is
    included in the vector

21
Raw Term Weights
  • The frequency of occurrence for the term in each
    document is included in the vector

22
Assigning Weights
  • tf x idf measure
  • term frequency (tf)
  • inverse document frequency (idf) -- a way to deal
    with the problems of the Zipf distribution
  • Goal assign a tf idf weight to each term in
    each document

23
tf x idf
24
Inverse Document Frequency
  • IDF provides high values for rare words and low
    values for common words

For a collection of 10000 documents
25
Similarity Measures for document vectors
Simple matching (coordination level
match) Dices Coefficient Jaccards
Coefficient Cosine Coefficient Overlap
Coefficient
26
tf x idf normalization
  • Normalize the term weights (so longer documents
    are not unfairly given more weight)
  • normalize usually means force all values to fall
    within a certain range, usually between 0 and 1,
    inclusive.

27
Vector space similarity(use the weights to
compare the documents)
28
Computing Similarity Scores
1.0
0.8
0.6
0.4
0.2
0.8
0.6
0.4
1.0
0.2
29
Vector Space with Term Weights and Cosine Matching
Di(di1,wdi1di2, wdi2dit, wdit) Q
(qi1,wqi1qi2, wqi2qit, wqit)
Term B
1.0
Q (0.4,0.8) D1(0.8,0.3) D2(0.2,0.7)
Q
D2
0.8
0.6
0.4
D1
0.2
0.8
0.6
0.4
0.2
0
1.0
Term A
30
Text - Detailed outline
  • Text databases
  • problem
  • full text scanning
  • inversion
  • signature files (a.k.a. Bloom Filters)
  • Vector model and clustering
  • information filtering and LSI

31
Information Filtering LSI
  • Foltz,92 Goal
  • users specify interests ( keywords)
  • system alerts them, on suitable news-documents
  • Major contribution LSI Latent Semantic
    Indexing
  • latent (hidden) concepts

32
Information Filtering LSI
  • Main idea
  • map each document into some concepts
  • map each term into some concepts
  • Concept a set of terms, with weights, e.g.
  • data (0.8), system (0.5), retrieval (0.6)
    -gt DBMS_concept

33
Information Filtering LSI
  • Pictorially term-document matrix (BEFORE)

34
Information Filtering LSI
  • Pictorially concept-document matrix and...

35
Information Filtering LSI
  • ... and concept-term matrix

36
Information Filtering LSI
  • Q How to search, eg., for system?

37
Information Filtering LSI
  • A find the corresponding concept(s) and the
    corresponding documents

38
Information Filtering LSI
  • A find the corresponding concept(s) and the
    corresponding documents

39
Information Filtering LSI
  • Thus it works like an (automatically constructed)
    thesaurus
  • we may retrieve documents that DONT have the
    term system, but they contain almost everything
    else (data, retrieval)

40
SVD - Detailed outline
  • Motivation
  • Definition - properties
  • Interpretation
  • Complexity
  • Case studies
  • Additional properties

41
SVD - Motivation
  • problem 1 text - LSI find concepts
  • problem 2 compression / dim. reduction

42
SVD - Motivation
  • problem 1 text - LSI find concepts

43
SVD - Motivation
  • problem 2 compress / reduce dimensionality

44
Problem - specs
  • 106 rows 103 columns no updates
  • random access to any cell(s) small error OK

45
SVD - Motivation
46
SVD - Motivation
47
SVD - Detailed outline
  • Motivation
  • Definition - properties
  • Interpretation
  • Complexity
  • Case studies
  • Additional properties

48
SVD - Definition
  • An x m Un x r L r x r (Vm x r)T
  • A n x m matrix (eg., n documents, m terms)
  • U n x r matrix (n documents, r concepts)
  • L r x r diagonal matrix (strength of each
    concept) (r rank of the matrix)
  • V m x r matrix (m terms, r concepts)

49
SVD - Properties
  • THEOREM Press92 always possible to decompose
    matrix A into A U L VT , where
  • U, L, V unique ()
  • U, V column orthonormal (ie., columns are unit
    vectors, orthogonal to each other)
  • UT U I VT V I (I identity matrix)
  • L eigenvalues are positive, and sorted in
    decreasing order

50
SVD - Example
  • A U L VT - example

retrieval
inf.
lung
brain
data
CS
x
x

MD
51
SVD - Example
  • A U L VT - example

retrieval
CS-concept
inf.
lung
MD-concept
brain
data
CS
x
x

MD
52
SVD - Example
doc-to-concept similarity matrix
  • A U L VT - example

retrieval
CS-concept
inf.
lung
MD-concept
brain
data
CS
x
x

MD
53
SVD - Example
  • A U L VT - example

retrieval
strength of CS-concept
inf.
lung
brain
data
CS
x
x

MD
54
SVD - Example
  • A U L VT - example

term-to-concept similarity matrix
retrieval
inf.
lung
brain
data
CS-concept
CS
x
x

MD
55
SVD - Example
  • A U L VT - example

term-to-concept similarity matrix
retrieval
inf.
lung
brain
data
CS-concept
CS
x
x

MD
56
SVD - Detailed outline
  • Motivation
  • Definition - properties
  • Interpretation
  • Complexity
  • Case studies
  • Additional properties

57
SVD - Interpretation 1
  • documents, terms and concepts
  • U document-to-concept similarity matrix
  • V term-to-concept sim. matrix
  • L its diagonal elements strength of each
    concept

58
SVD - Interpretation 2
  • best axis to project on (best min sum of
    squares of projection errors)

59
SVD - Motivation
60
SVD - interpretation 2
SVD gives best axis to project
v1
  • minimum RMS error

61
SVD - Interpretation 2
62
SVD - Interpretation 2
  • A U L VT - example

63
SVD - Interpretation 2
  • A U L VT - example

variance (spread) on the v1 axis
x
x

64
SVD - Interpretation 2
  • A U L VT - example
  • U L gives the coordinates of the points in
    the projection axis

x
x

65
SVD - Interpretation 2
  • More details
  • Q how exactly is dim. reduction done?

66
SVD - Interpretation 2
  • More details
  • Q how exactly is dim. reduction done?
  • A set the smallest eigenvalues to zero

x
x

67
SVD - Interpretation 2
x
x

68
SVD - Interpretation 2
x
x

69
SVD - Interpretation 2
x
x

70
SVD - Interpretation 2

71
SVD - Interpretation 2
  • Equivalent
  • spectral decomposition of the matrix

x
x

72
SVD - Interpretation 2
  • Equivalent
  • spectral decomposition of the matrix

l1
x
x

u1
u2
l2
v1
v2
73
SVD - Interpretation 2
  • Equivalent
  • spectral decomposition of the matrix

m


...
n
74
SVD - Interpretation 2
  • spectral decomposition of the matrix

m
r terms


...
n
n x 1
1 x m
75
SVD - Interpretation 2
  • approximation / dim. reduction
  • by keeping the first few terms (Q how many?)

m


...
n
assume l1 gt l2 gt ...
76
SVD - Interpretation 2
  • A (heuristic - Fukunaga) keep 80-90 of
    energy ( sum of squares of li s)

m


...
n
assume l1 gt l2 gt ...
77
SVD - Interpretation 3
  • finds non-zero blobs in a data matrix

x
x

78
SVD - Interpretation 3
  • finds non-zero blobs in a data matrix

x
x

79
SVD - Interpretation 3
  • Drill find the SVD, by inspection!
  • Q rank ??

x
x
??

??
??
80
SVD - Interpretation 3
  • A rank 2 (2 linearly independent rows/cols)

x
x
??

??
??
??
81
SVD - Interpretation 3
  • A rank 2 (2 linearly independent rows/cols)

x
x

orthogonal??
82
SVD - Interpretation 3
  • column vectors are orthogonal - but not unit
    vectors

0
0
x
x
0

0
0
0
0
0
0
0
83
SVD - Interpretation 3
  • and the eigenvalues are

0
0
x
x
0

0
0
0
0
0
0
0
84
SVD - Interpretation 3
  • A SVD properties
  • matrix product should give back matrix A
  • matrix U should be column-orthonormal, i.e.,
    columns should be unit vectors, orthogonal to
    each other
  • ditto for matrix V
  • matrix L should be diagonal, with positive values

85
SVD - Detailed outline
  • Motivation
  • Definition - properties
  • Interpretation
  • Complexity
  • Case studies
  • Additional properties

86
SVD - Complexity
  • O( n m m) or O( n n m) (whichever is
    less)
  • less work, if we just want eigenvalues
  • or if we want first k eigenvectors
  • or if the matrix is sparse Berry
  • Implemented in any linear algebra package
    (LINPACK, matlab, Splus, mathematica ...)

87
SVD - Complexity
  • Faster algorithms for approximate eigenvector
    computations exist
  • Alan Frieze, Ravi Kannan, Santosh Vempala Fast
    Monte-Carlo Algorithms for finding low-rank
    approximations, Proceedings of the 39th FOCS,
    p.370, November 08-11, 1998
  • Sudipto Guha, Dimitrios Gunopulos, Nick Koudas
    Correlating synchronous and asynchronous data
    streams. KDD 2003 529-534

88
SVD - conclusions so far
  • SVD A U L VT unique ()
  • U document-to-concept similarities
  • V term-to-concept similarities
  • L strength of each concept
  • dim. reduction keep the first few strongest
    eigenvalues (80-90 of energy)
  • SVD picks up linear correlations
  • SVD picks up non-zero blobs

89
References
  • Berry, Michael http//www.cs.utk.edu/lsi/
  • Fukunaga, K. (1990). Introduction to Statistical
    Pattern Recognition, Academic Press.
  • Press, W. H., S. A. Teukolsky, et al. (1992).
    Numerical Recipes in C, Cambridge University
    Press.
Write a Comment
User Comments (0)
About PowerShow.com
