Gas Chromatography

• an analytical separations technique useful for
  separating volatile organic compounds
• consists of
• Flowing mobile phase (inert gas - Ar, Ne, N)
• Injection port ( rubber septum - syringe injects
  sample)
• kept at a higher temperature than the boiling
  point

3
(No Transcript)
4
Principles

• Separation due to differences in partitioning
  behavior
• selective retardation

5
Key Information

• organic compounds separated due to differences in
  their participating behavior between the mobile
  gas phase and the stationary phase in the column
• in contrast to other types of chromatography, the
  mobile phase does not interact with molecules of
  the analyte its only function is to transport
  the analyte through the column

6
Gas Chromatography

• Separation column containing stationary phase
• since partitioning behavior independent of
  temperature - kept in thermostat - controlled
  oven
• Detector

7
(No Transcript)
8
Schematic of a gas Chromatograph
9
The Beginning

• concept of GC announced in 1941 by Martin and
  Synge (also did liquid partition chromatography)
• 10 years later GC used experimentally
• 1955, first commercial apparatus for GC appeared
  on the market

10
Today

• estimate 200, 000 gas chromatographs are
  currently used through out the world.
• 30 instrument manufactures
• 130 different models
• cost 1,500 to 40,000 dollars
• improvements computers- automatic control open
  tubular columns-separate a multitude of analytes
  in relatively short times

11
Uses of Gas Chromatography

• Determination of volatile compounds (gases
  liquids)
• Determination of partition coefficients and
  absorption isotherms
• Isolating pure components from complex mixtures

12
Instrumentation
13
Instrumentation

• flowing mobile phase
• injection port
• separation column
• detector

14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
GC detectorsanother powerpoint
19
Liquid Chromatography much slower diffusion in
liquid as compared to gas
20
Liquid liquid extraction repeated extraction is
basis for LC
21
Retardation of solutes in liquid onto a solid
phase
22
Elution chromatography

• Increasing polarity of pure solvents
• hexane
• ether
• acetone
• methanol
• water
• acetic acid

• Solvents mixed
• hexane and methanol
• miscible
• can be mixed continuously (solvent programming)

23
Types of Liquid Chromatography

• Liquid-solid adsorption on solid which is
  generally polar (silica gel, alumina, magnesium
  silicates) or reverse phase (cellulose, poly
  amides)
• Ion exchange specific interactions with ionic
  species (change relative strengths of acid or
  base)

24
Types of Liquid Chromatography

• Liquid-liquid partition between 2 bulk phases
  (one immobilized) is highly selective
• Liquid exclusion molecular sieve separates
  molecules on basis of ability to diffuse into
  immobile support

25
Retardation based on size of molecule as it
diffuses into porous solid
26
High Performance Liquid Chromatography

• Once called High Pressure Liquid Chromatography

27
Outline

• What is HPLC?
• An Overview
• Types of HPLC
• Partition Chromatography
• Adsorption Chromatography
• Ion Chromatography
• Size-Exclusion Chromatography

28
What is HPLC?

• The most widely used analytical separations
  technique
• Utilizes a liquid mobile phase to separate
  components of mixture
• uses high pressure to push solvent through the
  column
• Popularity
• sensitivity
• ready adaptability to accurate quantitative
  determination
• suitability for separating nonvolatile species or
  thermally fragile ones

29
HPLC is.

• Popularity
• widespread applicability to substances that are
  of prime interest to industry, to many fields of
  science, and to the public
• Ideally suited for separation and identification
  of amino acids, proteins, nucleic acids,
  hydrocarbons, carbohydrates, pharmaceuticals,
  pesticides, pigments, antibiotics, steroids, and
  a variety of other inorganic substances

30
History lesson

• Early LC carried out in glass columns
• diameters 1-5 cm
• lengths 50-500 cm
• Size of solid stationary phase
• diameters 150-200 ?m
• Flow rates still low! Separation times long!
• Eureka! Decrease particle size of packing causes
  increase in column efficiency!
• diameters 3-10 ?m
• This technology required sophisticated
  instruments
• new method called HPLC

31
Advantages to HPLC

• Higher resolution and speed of analysis
• HPLC columns can be reused without repacking or
  regeneration
• Greater reproducibility due to close control of
  the parameters affecting the efficiency of
  separation
• Easy automation of instrument operation and data
  analysis
• Adaptability to large-scale, preparative
  procedures

32
Advantages to HPLC

• Advantages of HPLC are result of 2 major
  advances
• stationary supports with very small particle
  sizes and large surface areas
• appliance of high pressure to solvent flow

33
Liquid chromatography

• Instrumentation
• Mobile Phase Reservoir
• Pumping Systems
• Sample Injection Systems
• Liquid-Chromatographic Columns
• Detectors

34
Schematic of liquid chromatograph
35
LC column
LC injector
36
Types of HPLC

• Liquid-solid (adsorption) chromatography
• Liquid-liquid (partition) chromatography
• Ion-exchange chromatography
• Size exclusion chromatography

37
(No Transcript)
38
Partition Chromatography

• Most widely used
• Bonded-phase Chromatography
• Silica Stationary Phase
• OH OH OH OH
• O O O

• Si Si Si
  Si
• Siloxanes O CH3
• Si O Si R
  R C8, C18
• O CH3

39
Partition Chromatography II

• Reverse Phase Chromatography
• Nonpolar Stationary Phase
• Polar Mobile Phase
• Normal Phase Chromatography
• Polar Stationary Phase
• Nonpolar Mobile Phase
• Column Selection
• Mobile-Phase Selection

40
Partition Chromatography III

• Research Applications
• Parathion in Insecticides
• O
• CH3CH2O P O NO2
• CH3CH2O
• Cocaine in Fruit Flies A Study of
  Neurotransmission by Prof. Jay Hirsh, UVa

41
(No Transcript)
42
Adsorption Chromatography

• Classic
• Solvent Selection
• Non-polar Isomeric Mixtures
• Advantages/ Disadvantages
• Applications

43
What is Ion Chromatography?

• Modern methods of separating and determining ions
  based on ion-exchange resins
• Mid 1970s
• Anion or cation mixtures readily resolved on HPLC
  column
• Applied to a variety of organic biochemical
  systems including drugs, their metabolites,
  serums, food preservatives, vitamin mixtures,
  sugars, pharmaceutical preparations

44
The Mobile Phases are...

• Aqueous solutions
• containing methanol, water-miscible organic
  solvents
• also contain ionic species, in the form of a
  buffer
• solvent strength selectivity are determined by
  kind and concentration of added ingredients
• ions in this phase compete with analyte ions for
  the active site in the packing

45
Properties of the Mobile Phase

• Must
• dissolve the sample
• have a strong solvent strength leads to
  reasonable retention times
• interact with solutes in such a way as to lead to
  selectivity

46
Ion-Exchange Packings

• Types of packings
• pellicular bead packing
• large (30-40 µm) nonporous, spherical, glass,
  polymer bead
• coated with synthetic ion-exchange resin
• sample capacity of these particles is less
• coating porous microparticles of silica with a
  thin film of the exchanger
• faster diffusion leads to enhanced efficiency

47
Ion-Exchange Equilibria

• Exchange equilibria between ions in solution and
  ions on the surface of an insoluble, high
  molecular-weight solid
• Cation exchange resins
• sulfonic acid group, carboxylic acid group
• Anion exchange resins
• quaternary amine group, primary amine group

CM Cellulose Cation Exchanger
DEAE Cellulose Anion Exchanger
48
(No Transcript)
49
Eluent Suppressor Technique

• Made possible the conductometric detection of
  eluted ions.
• Introduction of a eluent suppressor column
  immediately following the ion-exchange column.
• Suppressor column
• packed with a second ion-exchange resin
• Cation analysis
• Anion analysis

50
(No Transcript)
51
Size Exclusion Chromatography(SEC)

• Gel permeation(GPC), gel filtration(GFC)
  chromatography
• Technique applicable to separation of
  high-molecular weight species
• Rapid determination of the molecular weight or
  molecular-weight distribution of larger polymers
  or natural products
• Solute and solvent molecules can diffuse into
  pores -- trapped and removed from the flow of the
  mobile phase

52
SEC(continued)

• Specific pore sizes.average residence time in the
  pores depends on the effective size of the
  analyte molecules
• larger molecules
• smaller molecules
• intermediate size molecules

53
SEC Column Packing

• Small (10 µm) silica or polymer particles
  containing a network of uniform pores
• Two types (diameters of 5 10 µm)
• Polymer beads
• silica-based particles

54
Advantages of Size Exclusion Chromatography

• Short well-defined separation times
• Narrow bands--gt good sensitivity
• Freedom from sample loss, solutes do not interact
  with the stationary phase
• Absence of column deactivation brought about by
  interaction of solute with the packing

55
Disadvantages

• Only limited number of bands can be accommodated
  because the time scale of the chromatogram is
  short
• Inapplicability to samples of similar size, such
  as isomers.
• At least 10 difference in molecular weight is
  required for reasonable resolution

56
(No Transcript)
57
Instrumentation

• Instruments required
• Mobile phase reservoir
• Pump
• Injector
• Column
• Detector
• Data system

58
Schematic of liquid chromatograph
59
Mobile phase reservoir

• Glass/stainless steel reservoir
• Removal of dissolved gases by degassers
• vacuum pumping system
• heating/stirring of solvents
• sparging
• vacuum filtration

60
Elution methods

• Isocratic elution
• single solvent of constant composition
• Gradient elution
• 2 or more solvents of differing polarity used

61
(No Transcript)
62
Pumping System I

• Provide a continuous constant flow of the solvent
  through the injector
• Requirements
• pressure outputs up to 6000 psi
• pulse-free output
• flow rates ranging from .1-10 mL/min
• flow control and flow reproducibility of .5 or
  better
• corrosion-resistant components

63
Pumping System II

• Two types
• constant-pressure
• constant-flow
• Reciprocating pumps
• motor-driven piston
• disadvantage pulsed flow creates noise
• advantages small internal volume (35-400 ?L),
  high output pressures (up to 10,000 psi), ready
  adaptability to gradient elution, constant flow
  rates

64
Pumping System III

• Displacement pumps
• syringe-like chambers activated by screw-driven
  mechanism powered by a stepper motor
• advantages output is pulse free
• disadvantage limited solvent capacity (20 mL)
  and inconvenience when solvents need to be
  changed
• Flow control and programming system
• computer-controlled devices
• measure flow rate
• increase/decrease speed of pump motor

65
Sample Injection Systems

• For injecting the solvent through the column
• Minimize possible flow disturbances
• Limiting factor in precision of liquid
  chromatographic measurement
• Volumes must be small
• .1-500 ?L
• Sampling loops
• interchangeable loops (5-500 ?L at pressures up
  to 7000 psi)

66
(No Transcript)
67
LC column
LC injector
68
Liquid Chromatographic Column

• Smooth-bore stainless steel or heavy-walled glass
  tubing
• Hundreds of packed columns differing in size and
  packing are available from manufacturers
  (200-500)
• Add columns together to increase length

69
Liquid Chromatographic Columns II

• Column thermostats
• maintaining column temperatures constant to a few
  tenths degree centigrade
• column heaters control column temperatures (from
  ambient to 150oC)
• columns fitted with water jackets fed from a
  constant temperature bath

70
Detector

• Mostly optical
• Equipped with a flow cell
• Focus light beam at the center for maximum energy
  transmission
• Cell ensures that the separated bands do not
  widen

71
Some Properties of Detector

• Adequate sensitivity
• Stability and reproducibility
• Wide linear dynamic range
• Short response time
• Minimum volume for reducing zone broadening

72
More Properties of Detector

• High reliability and ease of use
• Similarity in response toward all analytes
• Selective response toward one or more classes of
  analytes
• Non-destructive

73
Types of Detector

• Refractive index
• UV/Visible
• Fluorescence
• Conductivity
• Evaporative light scattering
• Electrochemical

74
Refractive Index I

• Measure displacement of beam with respect to
  photosensitive surface of dectector

75
Refractive Index II

• Advantages
• universal respond to nearly all solutes
• reliable
• unaffected by flow rate
• low sensitive to dirt and air bubbles in the flow
  cell

76
Refractive Index III

• Disadvantages
• expensive
• highly temperature sensitive
• moderate sensitivity
• cannot be used with gradient elution

77
UV/Visible I

• Mercury lamp
• ? 254nm
• ? 250, 313, 334 and 365nm with filters
• Photocell measures absorbance
• Modern UV detector has filter wheels for rapidly
  switching filters used for repetitive and
  quantitative analysis

78
UV/Visible II
79
UV/Visible III

• Advantages
• high sensitivity
• small sample volume required
• linearity over wide concentration ranges
• can be used with gradient elution

80
UV/Visible IV

• Disadvantage
• does not work with compounds that do not absorb
  light at this wavelength region

81
Fluorescence I

• For compounds having natural fluorescing
  capability
• Fluorescence observed by photoelectric detector
• Mercury or Xenon source with grating
  monochromator to isolate fluorescent radiation

82
Fluorescence II

• Advantages
• extremely high sensitivity
• high selectivity
• Disadvantage
• may not yield linear response over wide range of
  concentrations

83
Conductivity

• Measure conductivity of column effluent
• Sample indicated by change in conductivity
• Best in ion-exchange chromatography
• Cell instability

84
Evaporative Light Scattering I

• Nebulizer converts eluent into mist
• Evaporation of mobile phase leads to formation of
  fine analyte particles
• Particles passed through laser beam scattered
  radiation detected at right angles by silicon
  photodiode
• Similar response for all nonvolatile solutes
• Good sensitivity

85
Evaporative Light Scattering II
86
Electrochemical I

• Based on reduction or oxidation of the eluting
  compound at a suitable electrode and measurement
  of resulting current

87
Electrochemical II

• Advantages
• high sensitivity
• ease of use
• Disadvantages
• mobile phase must be made conductive
• mobile phase must be purified from oxygen, metal
  contamination, halides

88
Data System

• For better accuracy and precision
• Routine analysis
• pre-programmed computing integrator
• Data station/computer needed for higher control
  levels
• add automation options
• complex data becomes more feasible
• software safeguard prevents misuse of data system

89
Electrophoresischarged species migrate in
electric fieldSeparation based on charge or
mobility
90
Capillary electrophoresishigher voltages can be
used as the heat can be dissipated
91
Capillary electrophoresis
92
The End
