Whats New in ArcGIS 10

• Trent Hare
• June 2011

2
Major upgrade

• ESRIs whats new 177 pages!
• http//help.arcgis.com/en/arcgisdesktop/10.0/pdf/w
  hats_new_in_arcgis_10.pdf

1.) Direct support for PDS and ISIS2,3 support
and current limitations 2.) New editing
capabilities (interface changes) 3.) New mosaic
raster type (virtual mosaics) 4.) New virtual
image processing chainable functions (called
Image Analyst). 5.) Hardware acceleration and new
basemap layers (local cache) 6.) A few new
toolbox helper functions and tips for background
processing. 7.) Changes to 3D and Spatial Analyst
(raster environment) 8.) New add-in
environment 9.) if time New temporal tools 10.)
slide new location for planetary radii
definitions 11.) Python fully integrated
3
PDS, ISIS2, ISIS3 support

• The good
• Attached, detached, tiled or raw
• Map projections (most).
• 8, 16, 32 bit
• Multiple bands
• The bad
• Only one NoData value. Means no ISIS saturation
  value support
• Needs statistics to be build to show 16 and 32bit
  ranges
• A couple GDAL bug fixes are not available (e.g.
  new continuation flag in ISIS3 label).
• Still recommend to convert to 8bit using GDAL

4
Editing

• The Editor toolbar has been redesigned.
• Feature templates (more like Illustrator
  editing).
• New snapping environment on by default.
• Start editing by right-clicking a layer.
• The Attributes and other editing windows have
  been redesigned.
• Selecting features and editing vertices is easier
  - select, add, and remove multiple vertices by
  drawing a box.

5
Editing
6
Editing
7
USGS Crater Helper Tools (upgraded)

• Facilitates feature mapping (craters, linear,
  closed)
• Still testing but available (linked below).

http//resources.arcgis.com/gallery/file/arcobject
s-net-api/details?entryIDB8D12158-1422-2418-3433-
E1667CA43176
8
Mosaic Raster Type

• A mosaic dataset is a collection of raster
  datasets (images) stored as a catalog viewed as
  a dynamically mosaicked image.

9
Virtual Image Functions
Demo Hillshade
10
Hardware acceleration and new basemap layers
11
Geoprocessing (background)

• Recommend disabling (for now)

12
ArcPy Environment
13
Planetary definitions (reorgd)
Location C\ArcGIS\Desktop10.0\Coordinate Systems
14
Favorite Projections (location Win7)

• Recommend adding a Connect to Folder in
  ArcCatalog
• C\Users\ltprofilegt\AppData\Roaming\ESRI\Desktop10.
  0\ArcMap\Coordinate Systems
