Foundation v1.5 Enhancements

1
Foundation v1.5Enhancements
Version 2.0
2
New Features in Foundation F1.5

• Integration with Express and Implementation Tools
  via API mechanisms
• Full Verilog Support
• New Look and Feel for Project Manager
• New Device Support
• Virtex
• XC9500XL
• SpartanXL
• Improved Synthesis Engine
• Improved Implementation Engine

3
Express Integration

• Emulation of Express look and feel in Files tab
  and Versions tab
• Local menus
• Files tab source status markers (check, ?, X)
• Files tab entities display
• Versions tab Functional/Optimized Structure and
  entities display
• However, some changes consciously made to improve
  usability
• Example some changes in local menus
• Example dialog box option assertion levels
  (I.e. Do not insert I/O pads changed to insert
  I/O pads)
• Full Constraint Manager and Timing Tracker
  implementation

4
Implementation Tools Integration

• Most Design Manager functions are available from
  Project Manager
• Version, Revision actions available via local
  menus, pull-down menus, and Flow Diagram
  automation
• Ancillary Xilinx tools (e.g., Floorplanner, EPIC,
  etc.) are in Tools gt Implementation pull-down
  menu
• Interactive Flow Engine can be invoked on any
  Revision

5
Full Verilog Support

• State Editor can now generate Verilog behavioral
  code
• Full HDL Editor support
• Color coding
• Language Assistant
• Syntax checking
• Schematic Editor
• Verilog modules (macros)

6
Project Manager

• PCM is now truly Mission Control for Foundation
• Express GUI and Design Manager no longer required
  in most cases (these are still provided in
  Xilinx Foundation Series gt Accessories folder)
• Menus re-organized for ease of use and support of
  integrated synthesis and implementation
  functionality

7
Files Tab (HDL Flow)

• HDL files entities shown via Express API
• Status of each HDL files Analysis shown
• Local Menus provide Power User functions

8
Versions Tab (HDL Flow)

• Displays both Express Elaborated/Optimized
  Structures and Xilinx Versions/Revisions
• Symbology indicates elaboration/optimization
  results (i.e., x, exclamation point, checkmark)
• Local menu pick for FE.LOG
• Interactive Flow Engine can be invoked on any
  Revision at any time

9
More on HDL Flows Versions Tab

• Top-level item in Tab corresponds to Express
  Elaboration and Xilinx Version
• Multiple Versions can exist
• A different package/speed within the same
  architecture can be selected without
  re-synthesizing (results in a new Revision)
• Retargeting the design to a different
  architecture means you should re-synthesize
  (which means a new Version will be created)
• Revision item corresponds exactly to Design
  Manager Revision

10
Versions Tab for Schematic Flow

• Top-level object corresponds to xproj directory
• Target family determined by FilegtProject Type
  dialog setting (as it was in F1.4)
• Changing Project Type will attach new Unified
  Library to Project subsequent Implementations
  will use the new Family

11
Versions Tab Local Menus(HDL Flow)

• Functional Structure Menu Provides Access to
  Express Constraint Manager
• Optimized Structure Menu Includes Pick for
  Express Timing Tracker
• Context-sensitive Local Menu Picks for Express
  Pre- and Post-Optimized Reports

12
Completely Revamped Flow Diagram

• New Phase Box Design Step Grouping
• Some Phases contain individual tool buttons
• Flow Progress Indicators
• Flow-sensitive Diagram Layout
• Schematic Flows diagram does not have Synthesis
  Phase
• New Flow Automation

Single-action Phase button
Multiple tool Phase button
13
Pull Model

• Implemented for Synthesis, Functional Simulation,
  and Implementation Phase Boxes
• Design will be pulled through the required
  processing steps to bring it to point that user
  selects

14
Synthesis/Implementation Dialog

• This dialog is used for both Synthesis and
  Implementation Phase
• Invoked from Files or Versions tab, from the
  Sythesis or Implementation pull-down menus, or as
  a result of selecting the Synthesis, Simulation,
  or Implementation Phase boxes
• Depending on how its invoked, one section or the
  other may be grayed out

15
Messages/Reports

• Express GUI tabs implemented in Console area

• Xilinx Report Browser available via Reports Tab
• Implementation Log File (FE.LOG) also shown

16
Project Pull-down Menu

• Source files are automatically analyzed when
  added to Project
• Single-point Version/Revision Management
• Clear Implementation Data deletes all synthesis
  and implementation data and directories (but
  source files remain)

17
Synthesis and Implementation Pull-down Menus

• Synthesis Menu Provides Design-Global Functions
  Plus a Few Expected Items
• local functions are provided via local
  (right-mouse-button) menus
• Shown in HDL Flow only
• Implementation Menu Provides
• Duplicates Implementation Phase Button and
  Implement local menu pick
• Invokes Xilinx Report Browser
• Invokes Project Options dialog

18
Tools Pull-down Menu

• Tools grouped into Phases
• Implementation menu includes Pin Locking items
  (single command to lock pins)
• Programming Tools are grayed out if not
  applicable to current architecture

19
Whats New in the Express Synthesis Engine

• Integrated project management as discussed
  earlier
• New architecture support
• Virtex
• Addition of some VHDL 93 constructs
• end keyword - component keyword
• is keyword - labels on assignments
• Timage(X) - block in generate
• alias keyword - array slices with others
• Addition of other HDL constructs
• rising_edge / falling_edge
• else
• hex, octal and binary for std_logic_vectors

20
Whats New in the Express Synthesis Engine

• New State Machine Synthesis Options

• FSM Encoding Style
• One Hot
• Binary

• FSM Extraction Method
• Safest (all possible states)
• Smallest (defined states only)

21
Whats New in the Implementation Engine

• No License or Hardware Key Required
• Express configurations require FlexLM
• Software Run Time Enhancements
• Significantly faster timing-driven place route
• Netlist translation and timing annotation steps 6
  to 10 times faster than in v1.4
• New Timing Analysis Algorithms
• designed to handle larger numbers of timing paths
  than in previous releases (critical for
  supporting the new, very large Virtex devices)
• Design-aware Constraint Editor for schematic
  designs
• New FPGA Floorplanner

22
More New Features

• Integrated Installation Program
• Installs Design Entry, Synthesis, and
  Implementation components (1 CD)
• Each Part Family selection will install both the
  applicable schematic symbol library and the
  Implementation data files automatically
• DynaText docs are on a separate CD
• New Interactive (Macromedia) demo/introduction

23
Application Enhancements
Version 2.0
24
Schematic Editor

• Re-implemented Bus behavior
• Complex buses
• Bus editing now more similar to wire editing
• Enhanced wire behavior
• Selection, deletion
• Autowiring
• Rubberbanding
• Local Menus (e.g., right-click gt Hierarchy Push,
  copy/paste, Symbol Properties, etc.)

25
Schematic Editor (continued)

• SC Symbols dialog box enhanced - Project
  components are listed separately from Unified
  Library comps
• Replace Symbol option now has a drop-down
  selector from which to pick new symbol
• Symbol attributes can now be moved directly (no
  need to bring up Properties dialog)
• Multi-level undo (5 levels)
• Copy/Paste enhancement objects to be pasted are
  visible as copy buffer is moved around on the
  schematic
• Enhanced Coregen 1.5 interface (i.e., symbol
  generation)

26
HDL Editor

• New Insert File item in Edit menu
• Provides easy method for insertion of LogiBLOX
  and CoreGen-created instantiation templates
• Verilog syntax checking, color-coding, language
  templates, Schematic Flow macro synthesis
• VHDL Language Assistant templates updated to be
  Express-compliant

27
Gate-Level Simulator

• Virtex LUT support
• New Simulation Script Wizard
• invoked either at Script Editor start-up or from
  Script Editors Tools menu
• Memory allocation tuning to support larger
  netlists
• Signal Selection dialog Search feature enhanced
• New Enable Global Netlist Analysis feature
• can speed up simulation if disabled (not always
  needed)
• Project-specific
• See Whatsnew.HLP for more detail

28
Script Wizard

• A new alternative to using the Simulation Macro
  Assistant

29
Script Wizard

• Resulting Script

30
Migration of F1.4 Designs Into F1.5

• No automatic conversion is done
• F1.4, XACT 6 Projects are opened in their native
  Project Type
• Automatic determination of proper Flow (Schematic
  or HDL)
• Customers with existing designs that contain
  X-VHDL (Metamor) blocks may wish to keep Metamor
  installed for support of those designs
• Metamor can be installed as a standalone
  component from F1.4 Design Entry Tools CD

31
Unequaled ValueFoundation Series Promotional
Pricing
95
495
3995
X
7995
NOTE Promotional Pricing Good Through 12/30/98
32
Foundation Series Product Roadmap
Now Shipping!
Nov 1998
Mid 1999


F1.5
F1.5i / F1.5J
F2.1

• Foundation Ease-of-Use enhancements
• Multi-media Quick-Tour demo
• Embedded FPGA Express
• Unified Project Mgmt.
• Plug-and-Play HDL Simulation solutions
• Advanced Performance Features
• Timespec Constraint Editor
• Floorplanner
• Virtex (Beta), 9KXL, 4KXLA, SpartanXL device
  support

• Foundation Ease-of-Use enhancements
• Internet Access
• New HDL templates
• Advanced Performance Features
• Express 2.1.3 synthesis
• Production Virtex support
• Latest device packages and Speed Grades
• Japanese Localization

• Next Generation Design Environment
• HDL Centric Design Entry Project Management
• Improved Simulator Capacity / Performance
• Foundation Ease-of-Use enhancements
• Improved Push-Button Automation
• Improved Error Navigation
• Robust Version Control
• CPLD Floorplanner

Regular scheduled Xilinx Software service packs
are now distributed via the web.
33
the end.
