CS 728 Advanced Database Systems Chapter 14

1
CS 728 Advanced Database Systems Chapter 14

• Database Design Theory
• Introduction to Normalization Using Functional
  Multivalued Dependencies

2
Design Guidelines for Relation Schemas

• 1. Attributes should have clear meanings
  (semantics) and related attributes are grouped
  into single entities.
• 2. Avoid update anomalies by reducing redundant
  data.
• 3. Reduce the NULL values.
• 4. When relations are joined no spurious tuples
  will be generated.

3
Semantics of Relation Attributes

• Guideline 1
• Design a relation schema so that it is easy to
  explain its meaning. Do not combine attributes
  from multiple entity types and relationship types
  into a single relation.
• Design I
• STUDENT(STNO, Name, Address, ANO)
• ADVISOR(ANO, Name, Address, Dept)
• Design II
• Student-Advisor(STNO, Name, Address, ANO,
  A-name, A-address, Dept)
• Design I is better when compared with Design II.

4
Update Anomalies

• Insertion anomalies
• In design II, if we add a new student to
  Student-Advisor, we have to add data related to
  that students advisor. This information should
  be consistent with all other occurrences of that
  advisor. Note that in design II all data related
  to a particular advisor is repeated a number of
  times which equals to the number of students
  supervised by that advisor. In design I, only
  advisor number is repeated.
• It is difficult to add a new advisor who have no
  students yet to the database. This is because we
  have to assign nulls to STNO and STNO is the
  primary key for Student-Advisor.

5
Update Anomalies

• Deletion Anomalies
• If we delete the last student associated with a
  particular advisor, then that advisor cannot
  exist in the database in design II any more.
• Modification Anomalies
• If an advisor changes his/her address, say, then
  we have to modify his/her address in all tuples.
• If we miss some tuples, then we will have several
  addresses for the same advisor.

6
Update Anomalies

• Guideline 2
• Design the base relation schemas so that no
  insertion, deletion, or modification anomalies
  occur.
• If any anomalies are present, note them clearly
  so that the programs that update the database
  will operate correctly.

7
NULL values in Tuples

• Guideline 3
• Avoid placing attributes in a base relation whose
  values may be null.
• If nulls are unavoidable, make sure that they
  apply in exceptional cases only and do not apply
  to majority of tuples in the relation.

8
NULL values in Tuples

• Problems with Nulls
• Waste storage space.
• Have multiple interpretations (not-applicable,
  not-known,).
• Create ambiguities with aggregate functions
  (count, avg, )
• Create ambiguities with joins.

9
NULL values in Tuples

• Example
• If only 10 of employees have phones, then
  Employee(SSN, Name,., Office-phone) is a poor
  design, because 90 of the last column values
  will be nulls
• But
• Employee(SSN, Name, )
• Phone(SSN, Office-phone)
• is a better design.

10
Spurious Tuples

• Guideline 4
• Design relation schemas so that they can be
  joined with equality conditions on attributes
  that are either primary keys or foreign keys in a
  way which guarantees that no spurious tuples are
  generated.

11
Spurious Tuples

• Emp-Proj(SSN, Pno, Hours, Ename, Pname, Plocation)

12
Spurious Tuples

• Emp-locs(Ename, Plocation)
• Emp-Proj1(SSN, Pno, hours, Pname, Plocation)

13
Spurious Tuples

• Emp-Proj(SSN, Pno, Hours, Pname, Plocation)

14
Spurious Tuples

• Result ? Emp-Locs ? Emp-proj1
• Then Result(Ename, Plocation, SSN, Pno, Hours,
  Pname)

15
Spurious Tuples

• If we combine Emp-Locs and Emp_Proj1 on Plocation
  attribute, we will get spurious tuples as you
  have noticed in the previous slide. This is
  because Plocation is the attribute which combines
  the two relations and it is neither a primary key
  nor a foreign key in either Emp-Locs or
  Emp-Proj1

16
Bad Tables (1)

• Alternative designs for a product database
• (1)
• Products(Prod_no, Prod_name, Price, Manu_id)
• Manufacturers (Manu_id, Manu_name, Address)
• (2)
• Prod_Manu (Prod_no, Prod_name, Price, Manu_id,
  Manu_name, Address)

17
Bad Tables (2)

• Problems with the second design
• Redundancy --- the name and address of each
  manufacturer will be repeated once for each
  product made by the manufacturer.
• more storage space needed
• potential inconsistency (update anomalies)

18
Bad Tables (3)

• Insertion anomalies --- a manufacturer's name and
  address cannot be recorded in the database if it
  does not make at least one product (because
  Prod_no is part of the primary key).
• Deletion anomalies --- If we delete all products
  made by a manufacturer, we will unintentionally
  lose track of the manufacturer's name and
  address.
• The first design does not have similar problems.
• The challenge is to identify bad relations and
  convert them into good relations.

19
Functional Dependencies

• R Relation schema.
• r(R) Relation instance
• A1, A2, , An Attributes which belong to
  universal relation.
• X, Y Sets of attributes.

20
Functional Dependencies

• A functional dependency (X ? Y), between X and Y
  specifies a constraint on the possible tuples
  that can form a relation instance r of R.
• The constraint states that for any two tuples t1
  and t2 in r such that t1X t2X, then t1Y
  t2Y
• This means that the Y component of a tuple in r
  depends on (or determined by) the values of the X
  component of that tuple in r.
• Or the values of the X component of a tuple in r
  uniquely or functionally determines the values of
  Y component.

21
Functional Dependencies

• X is said to functionally determine Y (or Y is
  functionally dependent on X) if for every legal
  relation instance r(R), for any two tuples t1 and
  t2 in r(R), we have
• t1X t2X , then t1Y t2Y
• X ? R denotes that X is a subset of the
  attributes of R
• X ?Y denotes that X functionally determines Y.

22
Functional Dependencies

• Note that
• if X is a candidate key then X ? Y is correct
  for any subset of attributes of R.
• if X ? Y, this does not say whether Y ? X is
  correct or not.
• Student(SSN, STNO, Name, Major)
• SSN ? Name
• t1(91910, 980090012, Ahmed, ..)
• t2(91910, 980090012, Ahmed, ..)
• STNO ? Major
• t10((980090012,, Math)
• t12(980090012, , Math)
• SSN ? SSN, Name, STNO, Major

23
Functional Dependencies

• Manager(SSN, Name, . Dept)
• SSN ? Name, Dept (correct)
• SSN uniquely determines the Name and Dept
• Dept ? SSN (correct)
• Dept uniquely determines the SSN
• Name ? SSN (incorrect)

24
Functional Dependencies

• FD is a property of the meaning or semantics of
  attributes
• FD is specified as a constraint on R, all
  extensions of R (i.e. r(R)) should specify that
  constraint (legal extensions) otherwise r(R) are
  called illegal extensions
• Note that we cannot infer FDs from r(R)

25
Diagrammatic Representation of FDs

• SSN ? STNO, NAME, MAJOR
• STNO ? SSN, NAME, MAJOR

Student(SSN, STNO, Name, Major)
FD 1
FD 2
26
Inference Rules for Functional Dependencies

• Let
• F set of functional dependencies defined on R
• F (Closure of F) is the set of all functional
  dependencies that can be defined on R
• The closure of F is the set of all FDs that are
  logically implied by F
• The closure of F is denoted by F
• F X ? Y F X ? Y
• A BIG F may be derived from a small F
• For R(A, B, C) and F A ? B, B ? C
• F A ? B, B ? C, A ? C, A ? A, B ? B,C ? C,
  AB ? AB, AB ? A, AB ? B, ...

27
Inference Rules for Functional Dependencies

• Emp-Dept(SSN, Ename, Bdate, Address, Dnumber,
  Dname, MGR-SSN)
• F
• SSN ? Ename,Bdate,Address,Dnumber, Dnumber ?
  Dname, MGR-SSN
• We can infer the following FDs
• SSN ? SSN (Reflexive)
• SSN ? Ename (Decomposition)
• SSN ?Dname, MGR-SSN (Transitive)
• We usually write F X ? Y to denote that the FD
  X ?Y is inferred from F
• X, Y are subsets of attributes

28
Functional Dependency

• Several equivalent definitions
• X ? Y in R iff for any t1, t2 in r(R), if t1
  and t2 have the same X-value, then t1 and t2 also
  have the same Y-value
• X ? Y in R iff there exist no t1, t2 in r(R)
  such that t1 and t2 have the same X-value but
  different Y-values
• X ? Y in R iff for each X-value, there
  corresponds to a unique Y-value.

29
Functional Dependency

• Question if all X-values are different in all
  possible r(R), does X ? Y in R?
• Theorem 1
• If X is a superkey of R and Y is any subset of R,
  then X ? Y in R
• Note that X ? Y in R is a property that must be
  true for all possible legal r(R), not just for
  the present r(R)

30
Functional Dependency

• Example which is true?
• A B C D A ? B
• a1 b1 c1 d1 A ? C
• a1 b2 c1 d2 C ? A
• a2 b2 c2 d2 A ? D
• a2 b3 c2 d3 B ? D
• a3 b3 c2 d4 AB ? D
• AB ? C
• AB ? CD

31
Identify Functional Dependency

• FD created by assertions.
• Employees(SSN, Name, Years_of_emp, Salary, Bonus)
• Assertion
• Employees hired the same year have the same
  salary
• This assertion implies
• Years_of_emp ? Salary

32
Inference Rules

• IR1 Reflexive Rule ( ?????)
• Y ? X, then X ?Y
• e.g.
• SSN ? SSN
• P, S, Qty ? Qty
• IR2 Augmentation Rule ?????))
• X ? Y XZ ? YZ
• e.g. F SSN ? Address
• F SSN, Name ? Address, Name

33
Inference Rules

• IR3 Transitive rule (??????)
• X ? Y, Y ? Z X ? Z
• e.g.
• F SSN ? Dnumber, Dnumber ? Dname
• F SSN ? Dname
• IR4 Decomposition Rule (????????)
• X ? Y, Z X ? Y and X ? Z
• e.g.
• F SSN ? Ename,BDate,Address, Dnumber
• F SSN ? Ename
• SSN ? Bdate
• SSN ? Address
• SSN ? Dnumber

34
Inference Rules

• IR5 Union (Additive) Rule
• X ? Y, X ? Z X ? Y, Z
• e.g.
• F SSN ? Ename, SSN ? Bdate
• F SSN ? Ename, Bdate
• IR6 Pseudo-transitive Rule
• X ? Y, WY ? Z WX ? Z
• e.g.
• F SSN ? STNO, Major, STNO ? Name
• F Major, SSN ? Name

35
Closure of Attributes

• How to determine if F X ? Y is true?
• Method 1
• Compute F
• If X ?Y ? F, then F X ?Y
• Problem
• Computing F could be very expensive!

36
Closure of Attributes

• Method 2
• Compute X the closure of X under F
• X denotes the set of attributes that are
  functionally determined by X under F.
• X Y X ? Y ? F
• Theorem
• X ?Y ? F if and only if Y ? X

37
Algorithm for Computing X

• Input
• a set of FDs F, a set of attributes X in R
• Output
• X
• Begin
• X X
• Repeat
• oldX X
• for each FD Y ? Z in F do
• if Y ? X then X X ? Z
• until (X oldX )
• end

38
Algorithm for Computing X

• Example
• R(A, B, C, G, H, I) ABCGHI
• X AG
• F A ? B, CG ? HI, B ? H, A ? C
• Compute X (AG)
• Initialization
• X AG

39
Algorithm for Computing X

• 1st iteration
• consider A ? B
• since A is a subset of X, X ABG
• consider CG ? HI
• since CG is not a subset of X, X ABG

• consider B ? H
• since B is a subset of X, X ABGH

• consider A ?C
• since A is a subset of X, X ABCGH
• X is changed from AG to ABCGH

40
Algorithm for Computing X

• 2nd iteration
• consider A ? B
• since A is a subset of X, X ABCGH

• consider CG ? HI
• since CG is a subset of X, X ABCGHI
• consider B ? H
• since B is a subset of X, X ABCGHI

• consider A ? C
• since A is a subset of X, X ABCGHI
• X is changed from ABCGH to ABCGHI

41
Algorithm for Computing X

• 3rd iteration
• consider each FD in F again, but there is no
  change to X, exit
• Result
• (AG) ABCGHI.
• The performance of the algorithm is sensitive to
  the order of FDs in F

42
Algorithm for Computing X

• Theorem
• Given R(A1, ..., An) and a set of FDs F in R, K ?
  R is a
• superkey if K A1, ..., An
• candidate key if K is a superkey and for any
  proper subset X of K, X ? A1, ..., An.

43
Algorithm for Computing X

• Continue the above example
• AG is a superkey of R since
• (AG) ABCGHI.
• Since A ABCH, G G, neither A nor G is a
  superkey.
• Hence, AG is a candidate key

44
Normal Forms Based on Primary Keys

• Normalization of data
• is a process during which unsatisfactory relation
  schemas are decomposed by breaking up their
  attributes into smaller relation schemas that
  posses desirable properties
• We normalize data for several reasons one of them
  is to avoid update anomalies
• We have
• First Normal Form (1NF)
• Second Normal Form (2NF)
• Third Normal Form (3NF)
• Boyce-Codd Normal Form (BCNF) (a stronger
  definition of 3NF)
• All the above normal forms are based on
  functional dependencies.

45
Normal Forms Based on Primary Keys

• Forth Normal Form (4NF) Based on multivalued
  dependencies.
• Fifth Normal Form (5NF) based on join
  dependencies.
• Aside
• Student-Adv(STNO, StName, Major,, Ano, Aname, )

• Has several problems
• Student(STNO, StName, Major, , Ano)
• Advisor(Ano, Aname, .)
• Pay the price of expensive joins

46
Basic Definitions

• R A1, , An)
• Superkey is set of attributes S ? R and t1S
  ? t2S ?i 1, ..., n. S may contain redundant
  attributes.
• Key (K) is a superkey with no redundant
  attributes, i.e. removal of any attribute from K
  will no longer make it a superkey.
• Candidate Key if a relation has more than one
  key, each is called a candidate key. One of these
  keys is arbitrarily chosen as a primary key.
• Prime Attribute is an attribute which is a
  member of any key (primary or candidate) other
  attributes are called nonprime attributes.

47
Basic Definitions

• Student(SSN, STNO, Name, Address, Salary)
• Superkeys
• SSN,Name/SSN,STNO,Name,Address,Salary
• Candidate keys
• SSN, STNO
• Primary Key
• SSN
• Prime Attribute
• SSN and STNO
• Nonprime Attributes
• Name, Address, Salary

48
1NF (First Normal Form)

• A relation schema R is in 1NF if every attribute
  of R takes only single and atomic values.
• Domains of attributes must include only atomic
  values and that the value of any attribute in a
  tuple must be a single value from the domain of
  that attribute.
• In other words, multivalued and composite
  attributes are disallowed.

49
1NF (First Normal Form)

• Student(STNO, StName, Course(CNO, Ctitle)
• The set braces identify the attribute Course
  as multivalued
• The set braces () identify the attribute Course
  as a composite attribute
• Because of the last attribute (Course), the
  Student relation schema is not in 1NF.

50
1NF (First Normal Form)

• Student(STNO, StName, Course(CNO, Ctitle)
• To normalize it to 1NF
• Student(STNO, StName, CNO, Ctitle)
• this is not a good representation because it has
  many disadvantages. Replication of Course
  information and student information. Combining
  attributes which belong to two separate entities
  (namely student and course) into a single
  relation schema.

51
1NF (First Normal Form)

• Student(STNO, StName, Course(CNO, Ctitle)
• Student(STNO, StName, CNO)
• Course(CNO, Ctitle)
• this design suffers from drawback that student
  information has to be repeated in the student
  relations several times (in fact a number of
  times that is equal to the number of courses
  taken by that student).

52
1NF (First Normal Form)

• Student(STNO, StName, Course(CNO, Ctitle)
• Student(STNO, StName)
• Course(CNO, Ctitle)
• Study(STNO, CNO)
• This is the best representation because we have
  reduced the duplication.

53
Second Normal Form (2NF)

• Prime attribute --- an attribute in any candidate
  key.
• Y is fully functionally dependent on X if X ? Y
  and no proper subset of X functionally determines
  Y
• FD X ? Y is a fully functional dependency if
  removal of any attribute A from X means that the
  dependency does not hold any more. In other words
  (X - A) does not determine Y
• A FD X ? Y is a partial FD if exist some
  attribute A which belongs to X and (X - A) ? Y
  still holds

54
Second Normal Form (2NF)

• General Definition of 2NF
• A relation schema R is in 2NF if every nonprime
  attribute A in R is not partially dependent on
  any key of R
• (i.e. if every nonprime attribute is fully
  functionally dependent on every key of R)

55
Second Normal Form (2NF)

• Emp-Proj(SSN, Pnumber, Hours, Ename, Pname,
  Plocation)
• FD1 SSN, Pnumber ? Hours (FD)
• FD2 SSN ? Ename (PD)
• FD3 Pnumber ? Pname, Plocation (PD)
• Because of FD2 and FD3 Emp-Proj is not in 2NF
• 2NF Normalization
• Emp(SSN, Ename)
• Proj(Pnumber, Pname, Plocation)
• Work(SSN, Pnumber, Hours)

56
Second Normal Form (2NF)

• Consider
• Bank-Loans (Bank_name, Assets, Headquarter,
  Loan_no, Customer_name, Amount),
• FD1 Bank_name ? Assets, Headquarter
• FD2 Bank_name, Loan_no ? Customer_name,
  Amount
• Because if FD1, Bank-Loans is not in 2NF.
• 2NF Normalization
• Banks(Bank_name, Assets, Headquarter)
• Loans(Bank_name, Loan_no, Customer_name, Amount)

57
Second Normal Form (2NF)

• 2NF is not good enough
• A relation schema in 2NF can still have serious
  redundancy problem as well as insertion and
  deletion anomalies.
• Consider Parts(Part_no, Name, Location,
  Unit_price, Manu_id, Manu_name, Manu_Address)
• It is obvious that Parts is in 2NF
• Redundancy and various anomalies are introduced
  by
• Manu_id ? Manu_name, Manu_Address

58
Second Normal Form (2NF)

• Consider
• EMP_DEPT(SSN, EName, BDate, Address, DNo, DName,
  DMGRSSN)
• It is obvious that EMP_DEPT is in 2NF
• Redundancy and various anomalies are introduced
  by
• DNo ? DName, DMGRSNN

59
Third Normal Form (3NF)

• Transitive Dependency
• a FD X ? Y in R is transitive if exist some set
  of attributes Z that is not a subset of any key
  of R and both X ? Z and Z ? Y hold.
• A relation schema R is in 3NF if it is in 2NF and
  no nonprime attribute A of R is transitively
  dependent on a key of R

60
Third Normal Form (3NF)

• A relation schema R is in 3NF if for every FD X ?
  A, where A is a single attribute, at least one of
  the following is true
• (a) A ? X (Trivial dependency - Reflexive)
• (b) A is a prime
• (c) X is a superkey

61
Third Normal Form (3NF)

• R is not in 3NF if a non-prime non-trivially
  depends on a non-superkey.
• If R in 3NF, it should not have a nonkey
  attribute functionally determined by another
  nonkey attribute (or by a set of nonkey
  attributes)

62
Third Normal Form (3NF)

• General Definition of 3NF
• A relation schema R is in 3NF if, whenever a
  nontrivial functional dependency X ? A holds,
  either
• (a) X is a superkey of R, or
• (b) A is a prime attribute of R

63
Third Normal Form (3NF)

• Emp-Dept(SSN, Ename, Bdate, Address, Dnumber,
  Dname, DMGR-SSN)
• FD1 SSN ? Ename, Bdate, Address, Dnumber,
  Dname, DMGR-SSN
• FD2 Dnumber ? Dname, DMGR-SSN
• Emp-Dept is in 1NF, 2NF, but because of
• SSN ? Dnumber and
• Dnumber ? Dname and
• Dname is a nonprime attribute, and
• Dnumber is not a superkey,
• Emp-Dept is not in 3NF.
• To transform Emp-Dept into 3NF
• Emp(Enam, SSN, Bdate, Address, Dnumber)
• Dept(Dnumber, Dname, DMG-SSN)

64
Third Normal Form (3NF)

• Employees (SSN, Name, Age, Salary, Dept_name,
  Dept_manager_SSN).
• Employees is in 2NF
• since SSN is the only candidate key and every
  attribute is fully dependent on it.
• Employees is not in 3NF because
• Dept_name ? Dept_manager_SSN

65
Third Normal Form (3NF)

• LOTS(Property-ID, County-Name, Lot, Area,
  Price, Tax-Rate)
• FD1 Property-ID ? County-Name, Lot, Area,
  Price, Tax-Rate
• FD2 County-Name, Lot ? Property-ID, Area,
  Price, Tax-Rate
• FD3 County-Name ? Tax-Rate
• FD4 Area ? Price
• 2 candidate keys Property-ID,County-Name,
  Lot
• LOTS is not in 2NF, because of County-Name ?
  Tax-Rate
• Tax-Rate is partially dependent on the candidate
  key County-Name, Lot.
• 2NF
• LOTS1(Property-ID, County-Name, LOT, Area,
  Price)
• LOTS2(County-Name, Tax-Rate)

66
Third Normal Form (3NF)

• The relation LOTS1 is not in 3NF, because of Area
  ? Price
• Area is not a superkey and Price is not prime
  attribute
• 3NF
• LOTS1A(Property-ID, County-Name, Lot, Area)
• LOTS1B(Area, Price)
• LOT2(County-Name, Tax-Rate)
• The above relation schemas are in 3NF

67
Boyce-Codd Normal Form (BCNF)

• Assume that we have thousands of lots, but
  two-counties
• Marion county and Liberty county.
• Lot areas in Marion county are
• .5, .6, .7, .8, .9 and 1 acres
• Lot areas in Liberty county are
• 1.1,1.2, , 1.9, 2.0 acres
• In this case we have AREA ? County-Name
• LOTS1A(Property-ID, County-Name, Lot, Area)
• FD5 Area ? County-Name
• Still in 3NF , since County-Name is a prime
  attribute

68
Boyce-Codd Normal Form (BCNF)

• A relation schema R is in BCNF if whenever a FD X
  ? A holds in R, then X is a superkey of R.
• R is in BCNF if for every non-trivial FD, the
  left side is a superkey.
• LOTS1A-X(Property-ID, Area, Lot)
• LOTS1A-Y(Area, County-Name)
• To describe a relation schema R as good it
  should be at least in 3NF (general) or BCNF
• If R is in BCNF, then R is also in 3NF
• However, R in 3NF R in BCNF

69
Normal Forms Summary

• Relationships between different NFs.

70
Normal Forms Summary

• 1NF
• Attributes should be single-valued and have
  atomic domain
• Normalize into 1NF
• Form a new relations for each non-atomic
  attribute
• 2NF
• 2NF removes some insertion anomalies and deletion
  anomalies.
• 2NF removes some redundancies, namely,
  redundancies caused by partial dependencies on
  key.

71
Normal Forms Summary

• 3NF
• 3NF removes all insertion anomalies and deletion
  anomalies.
• 3NF also removes some redundancies caused by
  transitive dependencies.
• BCNF
• achieves all achieved by 3NF.
• BCNF removes all redundancies caused by FDs.
