http://www.SpecC.org/

1

• http//www.SpecC.org/

SpecC stands for specification description
language based on C.
2
What is SpecC?

• Design Methodology
• for capturing and exchanging specifications of
  embedded systems
• for consistency and continuity from specification
  to implementation
• System-Level Description Language
• no distinction between HW and SW
• specs and components in one syntax
• functional specs, architectural specs, and
  implementation design under same syntax and
  semantics
• based on ANSI-C
• executable specification from the start

3
SpecC Design Flow
Application Specific Domain
Marketing
Product Planning
Upper CASE Tool
Requirement Specification
Product Spec
Specification Model
SpecC Technology
Architecture Model
Communication Model
Lower CASE Tool
Codes / RTOS
Behavior
High-level Synthesis
Compiler
HW
RTL
SW
Logic Synthesis
Assembly
Gate
Linker
PR
Load Module
Layout
Prototype
Mfg
4
Specification Synthesis
Design Specification
Computational Behavior
IP
Communication Channel
Specification Model
IP
Architecture Exploration
Behavior mapping
Channel mapping
Variable mapping
Architecture Model
IP
Communication Synthesis
Protocol Insertion
Transducer Synthesis
Protocol inlining
Communication Model
Software Model
Hardware Model
5
Methodology Benefits
Rapid, Easy, and Smooth Exploration in the Design
of Embedded Systems, Ubiquitous Computing

• HW/SW Co-Design
• Partitioning/Scheduling in the System Level
• Ready to Product quality of output (HDL,C)
• Easy Optimization of Product Cost/Performance
• Design Tool Interoperability
• Easy to build total design solutions
• IP-Centric Design
• IP reuse for every specification models
• Easy to publish IP-spec by SpecC
• Easy to reuse Interface synthesis
• Education of System Architects
• Established Design Style
• Know-how transfer enabled via Design Legacy

6
Purpose

• Standardize specification description language
• Establish interoperability among design tools
• Promote industry-academia-wide collaboration
• Establish design methodology/guidelinesbased on
  SpecC
• Easy tailoring of design solutions for each
  application segments.
• Aggregation and Reuse of design IPs

7
History

• Nov. 99 Established by 24 endorsers.
• 2001
• Language seminars
• Exhibitions / conferences
• Reference model development
• Free and Open Source Code for SpecC v1.0
• Application Reports / case studies available
• Working Group Activities
• Language Specification WG
• Discussion and Approval of SpecC Syntax and
  Semantics
• Improvement of SpecC language
• Activities are via E-Mail world wide.
• Communication with other language-based
  activities
• Goal is to send LRM to a standardization body.
• Case Study WG
• Members open their examples for discussion of
  usage on SpecC Technology
• Promotion of conference to present case studies
• Presentation of case studies from
  academia/industries at MST

30 Industry Members 30 Academic Members World
wide (Mar. 2002)
8
New Activity in 2002

• SpecC Academic Research Program
• Aims more innovative and leading activities in
  ubiquitous computing era through improving SOC
  design technology.
• Promotes academia-industries collaboration and
  synergy.
• Plans of exhibitions and conferences for mutual
  discussions.
• Provides research environment (tool set) with
  cooperation from 5 major tool vendors.
• InterDesign System Design VisualSpec
• Y Explorations High Level Synthesis eXCite
• CATS CASE ZIPC
• Gaio IDE for ARM OPENplus for ARM
• MISPO RTOS m-iTRON
• 17 professors at 16 major universities join.
• 22 professors at 15 major universities endorse.
• Research topics will come from both of SW and HW
  area.

9
SpecC Summary

• Design Methodology for innovative SoC design
• Well-defined Design Models Well-defined
  Refinement Tasks
• Language for accelerating Methodology spread.
• Based on ANSI-C, with extensions for Systems
  Design
• Support of all Concepts needed in Embedded
  Systems Design
• Separation of Communication Computation for
  Design Reuse
• Executable and Synthesizable
• Impact on Industries
• Easy tailoring of Design Solutions for each
  application domains.
• Enabling smooth Specification IP Exchanges
  between System Houses, Design Houses and
  Fabrications.
• Accelerating Education of System Architects for
  rapid growth in emerging Electronics Industries.
