Data Representation

1
Data Representation
2
Topics

• Bit patterns
• Binary numbers
• Data type formats
• Character representation
• Integer representation
• Floating point number representation

3
Data Representation

• Data representation refers to the manner in which
  data is stored in the computer
• There are several different formats for data
  storage
• It is important for computer problem solvers to
  understand the basic formats

4
Why is it Important?

• As an example
• We will learn that since we have finite storage,
  it is possible to overflow a storage location by
  trying to store too large a number
• Most programming languages provide multiple data
  types each providing different length storage for
  variables
• It is up to the programmer to choose the data
  type with a length that wont overflow
• Knowing how numbers are represented in storage
  helps one to understand this

5
Bit Pattern

• As you recall from an earlier presentation, data
  may take various forms characters, numbers,
  graphical, etc.
• All data is stored in the computer as a sequence
  of bits, that is, binary digits
• This is a universal storage format for all data
  types, and it is called a bit pattern

6
Bits and Bytes

• A bit is the smallest unit of data stored in a
  computer and it has a value of 0 or 1
• Its like a switch, on (1) or off (0)
• In computers, bits are stored electronically in
  RAM and auxiliary storage devices by two-state
  digital circuits
• The storage device itself doesnt know what the
  bit pattern represents, but software (application
  software, operating system, and I/O device
  firmware) stores and interprets the pattern
• That is, data is coded then stored and when
  retrieved it is decoded
• A byte is a string of 8 bits and is called a
  character when the data is text

7
Binary Numbers

• Each bit pattern is a binary number, that is, a
  number represented by 0s and 1s rather than 0,
  1, 2, , 9 as decimal numbers are
• For example, bit patterns like 1010 and 101001
  are also binary numbers
• Binary numbers are based on powers of 2 rather
  than powers of 10 as decimal numbers are

8
Data Type Formats

• As we have learned, fundamentally all data is
  stored as a bit pattern
• But the different data types have different bit
  pattern formats
• We want to learn the formats for
• Characters (for example, left, Lane, a, ?, \)
• Integers (for example, 1, 453, -10, 0)
• Floating point numbers (for example, 3.14159,
  1.2, -567.235, 0.009)

9
Character Representation

• The American Standard Code for Information
  Interchange (ASCII) is the scheme used to assign
  a bit pattern to each of the characters
• ASCII charts come in different flavors
• Some have 7 bit strings, some 8 or more
• Some show the binary code for the various
  characters as well as the code represented in
  other number systems, e.g., decimal, hex, octal
• For example, the letter A has the ASCII code
• 1000001 in binary for a 7-bit chart
• 65 in decimal
• 41 in hex
• 101 in octal

Note All four of these numbers represent the
same value but using different number systems
10
Subset of ASCII Chart
11
ASCII Chart

• Uppercase characters have different ASCII codes
  than lowercase
• Uppercase characters come before lowercase
• Numbers come before letters
• The special characters are spread around
• The numbers and upper and lowercase characters
  are in adjacent groupings, so that their codes
  increment by one

12
ASCII Chart

• The only difference between the binary codes for
  the upper and lowercase characters is the sixth
  bit, that is, the decimal code for a lowercase
  character is 32 greater than the uppercase
  characters decimal code
• ASCII codes before decimal 32 are control
  characters (nonprintable) like bell, backspace,
  and carriage return
• The final ASCII code in the 7-bit chart is the
  control character DEL with decimal code 127

13
Extended ASCII Unicode

• The eight-bit ASCII chart is sometimes called
  Extended ASCII
• The seven-bit ASCII codes are the same in
  eight-bit chart except have a zero at the left
• Some manufactures use the extra bit to create
  additional special characters, these however are
  nonstandard, e.g., using decimal 171 for ½, or
  246 for
• Unicode is another scheme developed so that the
  many symbols in international languages may be
  represented. It also uses bit patterns. UTF-32
  uses 32 bits.

14
Numeric Representation

• ASCII codes are an inefficient method for
  representing numbers
• For example, the number 1,024 using 8-bit ASCII
  would require four bytes or 32 bits of storage
• Arithmetic operations on numbers represented in
  ASCII are very complicated
• Representing the precision of a number, that is,
  the number of digits stored, may require large
  amounts of space when stored in ASCII
• There are more efficient schemes for numbers

15
Integer Representation

• An integer is a whole number, that is, a number
  without a decimal portion
• Integers may be positive, negative, or zero
• A plus-sign or minus-sign in front of the number
  is used to represent positive and negative
  numbers
• The plus-sign is not required for positive
  numbers and zero
• There are two categories of integer
  representation unsigned and signed

16
Unsigned Integer

• An unsigned integer is an integer without a sign,
  that is, a non-negative integer
• They range from zero to infinity, but no computer
  can store all the integers in that range
• So, a maximum unsigned integer is defined
• This maximum is based on the number of bits used
  to store an integer
• Lets use 8 and 16-bit (1 and 2 bytes) storage
  locations in our examples
• The length of storage is set by the data type the
  programmer specifies for a variable

17
Unsigned Integer

• An unsigned integer is stored as its value when
  represented as a binary number
• Leading zeros are added to fill out the storage
  location
• For example, the decimal number 9 is represented
  as 00001001 when stored in 1-byte because
  000010012 910
• When stored in a 2-byte location, 9 would be
  represented as 0000000000001001

18
Unsigned Integer

• One may use the following table to work with
  binary numbers
• For example, given 00001001, what decimal number
  does it represent?
• Add the non-negative powers of two, that is, 8
  1 9

19
Unsigned Integer

• One may use the same table to go the other way,
  that is, given the decimal number 13, what is its
  binary representation?
• Find the largest power of 2 that doesnt exceed
  the number and place a 1 in that cell
• Subtract that power of 2 from the number and use
  this as the new number 13 8 5

20
Unsigned Integer

• Then continue in this way until the sum of the
  powers of two equals the number
• Now, 5 4 1, and so finally
• Note that 8 4 1 13

21
Unsigned Integer

• Then fill in the remaining cells with zeros
• So, the unsigned integer representation of
  decimal 13 is 00001101 when stored in 1-byte

22
Unsigned Integer

• If one tries to store a number in a memory
  location that is not large enough we have what is
  called overflow
• In this case, depending on the system, one may or
  may not receive an error message
• So, one must not store a number that is larger
  than the maximum for a given length of storage
• The maximum number storable in 1-byte is 255

23
Unsigned Integer

• For example, if one tries to store 256 in 1-byte
  there is overflow because the largest value
  storable in 8 bits is 255 as one can see from the
  following table
• Note that 128 64 32 16 8 4 2 1
  255

24
Signed Integer

• A sign-and-magnitude format is used to allow for
  positive and negative numbers (and zero)
• The leading bit is designated as the sign bit 0
  for positive or zero, 1 for negative
• The remaining bits represent the value
• So, in 1-byte of storage the maximum number
  storable is not 255 as it was for the unsigned
  integer representation, but 127
• Note that 64 32 16 8 4 2 1 127

25
Signed Positive Integer

• To determine what the sign-and-magnitude
  representation of a positive decimal number is
• Convert the decimal number to binary
• If needed add leading zeros to fill the storage
  location
• For example, decimal 12 is represented in 1-byte
  as 00001100 because 8 4 12

26
Signed Positive Integer

• Going the other way, given a sign-and-magnitude
  representation for a positive number, one can
  interpret it as follows
• Leftmost bit will be 0 indicating positive
• Convert the remaining bits to a decimal number
• For example, 00010001 is decimal 17
• Because 16 1 17

27
Signed Negative Integer

• For negative numbers, twos complement format is
  used
• Twos complement is still a sign-and-magnitude
  format
• In twos complement, some of the magnitude bits
  are flipped from 0 to 1 or 1 to 0

28
Signed Negative Integer

• To determine what the twos complement
  representation of a negative decimal number is
• Ignore the sign and convert the decimal number to
  binary
• If needed add leading zeros to fill the storage
  location
• Leave all the rightmost 0s and first 1
  unchanged, but flip the remaining bits
• Make the sign bit 1
• For example, decimal -14 is represented in 1-byte
  as 11110010 because (see next slide)

29
Signed Negative Integer

• Convert 14 to binary (8 4 2 14) and make
  leading bits zero
• Leave the rightmost 0s and first 1 as is, but
  flip the remaining bits
• Make sign bit 1

30
Signed Negative Integer

• Going the other way, given a twos complement
  representation for a negative number, one can
  interpret it as follows
• Leave the rightmost bits up to and including the
  first 1 unchanged, but flip the remaining bits
• Convert the binary number to decimal
• Put a minus-sign in front
• For example, 11101010 is decimal 22 because (see
  next slide)

31
Signed Negative Integer

• Flip all but the rightmost 1 and any following
  0s
• Convert the binary number to decimal
• We get 22 because 16 4 2 22
• Put a minus-sign in front yielding -22

32
Signed Negative Integer

• Twos complement is the standard representation
  for negative integers in modern computers
• This is because arithmetic operations are simple
  to implement when integers are stored this way
  (but this concept is beyond the scope of the
  course)
• Although on the surface it seems complicated, at
  a deeper level it allows for simplicity of
  operations

33
Signed Negative Integer

• An alternative but equivalent method for
  converting a negative number to its twos
  complement representation is
• Ignore the sign and convert the decimal number to
  binary
• If needed add leading zeros to fill the storage
  location
• Flip all the bits
• Add 1 to the result of the last step
• Make the sign bit 1
• Some people find this easier

34
Signed Negative Integer

• For example, -14. First, convert 14 to binary (8
  4 2 14) and make leading bits zero
• Flip all the bits
• Add 1
• Make the sign bit 1

35
Floating Point Number Representation

• Float point numbers are those that have a decimal
  portion (mathematicians call these real numbers)
• Numbers like 3.14159, 50000.3, and 0.000005
• The method that is used allows for very large or
  very small numbers to be stored using the same
  format

36
Floating Point

• The main idea in this format is that the decimal
  point is allowed to float
• That is, there is an actual decimal location in
  the original number, and there is stored
  decimal location that is usually different
• The original number is normalized by moving the
  decimal place so there is only one digit to the
  left

37
Floating Point

• The basic idea can be seen from an example
  although this description glosses over many
  details
• The number 102.39 is normalized by moving its
  decimal point two places to the left to become
  1.0239, and this number is stored and is called
  the mantissa
• Also, the fact that the decimal point was moved
  left by 2 is stored so that the original number
  may be reconstructed and this is called the
  exponent
• The sign of the number is also stored (0 for
  positive or zero, 1 for negative)

38
Floating Point

• However, it is actually more complicated than
  that
• The exponent and mantissa are actually stored in
  binary
• And the value stored as the mantissa is only the
  fractional part of the binary number once the
  decimal point has been moved so that there is a
  binary 1 at the left, that is, 1.101001 is stored
  as 101001 and the leading 1 is assumed

39
Floating Point

• The representation of numbers in floating point
  involves a couple procedures that are complicated
  and beyond the scope of the course
• These are repetitive multiplication of a decimal
  fraction by 2, and the excess system for
  storing positive and negative numbers
• So, we wont be converting the numbers manually
  ourselves

40
Floating Point

• However, the procedure used to store a number in
  floating point representation is
• Store a 0 (positive) or 1 (negative) in the sign
  field
• Convert the integer part to binary
• Convert the decimal part (fraction) to binary by
  using repetitive multiplication by 2
• Combine the two binary numbers with a decimal
  point between
• Move the decimal point so that there is a 1 bit
  at the left and store the remaining bits in the
  mantissa field
• Store the number of places moved using the
  excess system in the exponent field

41
Floating Point

• Computers store data in binary and in finite
  space, i.e., they are discrete, finite systems
• However real numbers form a continuous, infinite
  system
• Hence, computers can only approximate real
  numbers
• The precision of a floating point number is how
  close the stored number is to the original number

42
Floating Point

• Small Basic Example
• Mathematically c should be 0 but what does the
  program display for c?

a 2 / 3 b 2 (1 / 3) c a -
b TextWindow.WriteLine(c)
43
Floating Point

• The more bits available for the mantissa field
  the more digits of the original number may be
  stored
• Programming languages normally allow the
  programmer to define the precision by the data
  type chosen

44
Floating Point

• Institute of Electrical and Electronics Engineers
  (IEEE) standards
• Single-Precision (4 bytes)
• Double-Precision (8 bytes)

45
Floating Point

• Trade off
• Double precision numbers require more space and
  therefore programs using them may run slower
• But operations using double precision numbers
  will be more precise

46
Summary

• Data are stored as bit patterns
• A bit pattern is a binary number
• There are various data type formats
• Characters are represented in ASCII

47
Summary

• Integers are represented as either
• Unsigned stored as the binary number equivalent
  to the original
• Signed Positive stored using the
  sign-and-magnitude format where the magnitude is
  the binary equivalent
• Signed Negative stored using the
  sign-and-magnitude format where the magnitude is
  in the twos complement format
• Floating point numbers are represented using
  sign, exponent, and mantissa

48
Terminology

• Data representation
• Bit
• Byte
• Bit pattern
• Binary number
• Character
• Integer
• Floating point number
• ASCII
• Control characters
• Extended ASCII
• Unicode

• Unsigned integer representation
• Overflow
• Sign-and-magnitude representation
• Sign
• Twos complement representation
• Floating point representation
• Normalize
• Exponent
• Mantissa
• Precision
• Single-precision
• Double-precision

49
End
