Cardiovascular

1

• Cardiovascular
• pharmacology

2
(No Transcript)
3
PROF.AZZA ELMedany

• Department of pharmacology

4
Antiarrhythmic Drugs
5
Objectives

• At the end of lectures the students should know
• Classification of anti-arrhythmic drugs
• Characters of each class
• Examples of drugs in each class
• Pharmacological effects , therapeutic uses , side
  effects of individual drugs

6

•
• CARDIAC CONDUCTION SYSTEM
• - S.A. node
• - Inter-nodal pathways
• - A.V. node
• - Bundle of His and branches
• - Purkinje fibres

7
(No Transcript)
8
(No Transcript)
9

•
• WHAT IS ARRHYTHMIA?
• An Abnormality in the
• Heart rate ......... high
  tachycardia
• low
  bradycardia
• Regularity ..... extrasystoles
• Site of origin ... ectopic pacemakers
• Disturbance in conduction

10
Circus Movement
11
Therapeutic uses of anti-arrhythmic drugs

• The ultimate goal of anti-arrhythmic drugs
  therapy is to restore normal rhythm conduction
• When it is not possible to revert to normal sinus
  rhythm , drugs are used to prevent more serious
  lethal arrhythmias.

12

•
• CLASSIFICATION
• OF
• ANTIARRHYTHMIC DRUGS
• According to Vaughan-Williams

13

• CLASS 1 Na channel blockers
• CLASS II
• ß- adrenoceptor blockers
• CLASS III
• drugs that prolong action potential duration
• ( k channel blockers )
• CLASS IV
• Calcium channel blockers

14
Continue

• Miscellaneous
• Adenosine
• Electrolyte supplement ( magnesium, potassium)
• Digitalis
• Atropine

15
CLASS 1

• Sodium channels blockers , this result in
• a decreased rate of depolarization (
  phase 0).
• Suppression of action potential generation


16
Continue

• Act on non-nodal tissues ( atria,
  ventricles, purkinje tissues ) which are
  depending on sodium ion to start depolarization

• All class 1 have local anesthetic effect that
  slow conduction in atrial ventricular tissues

17
T-Ca2 kanál
18

•
•  CLASS 1
• SUBCLASSIFIED INTO
• Class (1A)
• Class (1B)
• Class (1C)

19
Other actions of Class ( 1A)

• Potassium channel blocking effect
• Prolong the action potential duration
• Prolong Effective refractory period
  (ERP)
• ECG change
• Prolong QT interval

20
(No Transcript)
21

•
• Anticholinergic actions
• ( indirect effect increase AV conduction
  decrease AV conduction time that can precipitate
  lethal arrhythmias )
• Negative inotropic effect

22
Clinical uses of Class 1A

• Atrial flutter or fibrillation
• These drugs should not be used alone for
  treatment of AF or AF because the ventricular
  rate may dramatically increase
• Ventricular tachycardia or fibrillation

23

•
• Examples of Class 1A
• Quinidine
• Has a adrenergic blocking effect

24


• Side effects of quinidine
• GIT
• diarrhea
• CARDIAC
• Torsade de pointes
• ( quinidine syncope )
• Hypotension

25
Torsade de pointes
26


• Adverse effects ( continue)
• Anticholinergic adverse effects
• dry mouth , dry skin , constipation
• Cinchonism
• ( ringing in the ears , diarrhea)

27


• QUINIDINE
• GIVEN ORALLY ....rarely given I.V. because
• of toxicity .

28


• 2 PROCAINAMIDE
• As compared to quinidine
• less toxic on the heart...
• can be given I.V. ( common route)
• More effective in ventricular than in
• atrial arrhythmias
• less depressant on cardiac contractility
• Weak anticholinergic or a-blocking actions

29


• PROCAINAMIDE
• Clinical uses
• Second drug of choice ( after lidocaine ) for
  treatment of ventricular tachycardia after acute
  myocardial infarction

30


•  ADVERSE EFFECTS
• lupus erythematosus-like syndrome
• Hypotension
• Torsade de pointes
• Hallucination psychosis

31

• CLASS 1 B
• Shorten action potential duration
• and effective refractory period of
  Purkinje ventriclular cells
• e.g. lidocaine
• mexiletine

32
(No Transcript)
33

• LIDOCAINE
• Clinical uses
• Very effective for suppressing arrhythmias
  due to ischemia, digitalis toxicity
• First drug of choice for emergency treatment of
  ventricular tachycardia following
• cardiac surgery or acute myocardial
  infarction

34
Pharmacokinetics of lidocaine

• - Given I.V. bolus or slow infusion
• Not given orally because of its extensive first
  pass hepatic metabolism , only 3 of orally
  administered lidocaine appears in plasma.
• T1/2 2 hours

35


• ADVERSE EFFECTS
• Neurological such as
• Convulsions , tremors

36


• MEXILETINE
• Given Orally
• Clinical uses
• Chronic treatment of ventricular arrhythmia
• digitalis-induced arrhythmias
• Adverse effects
• Gastric upset
• Neurological manifestation
• t1/2 long ( 10 hr)

37
CLASS 1C

• Slow conduction in all cardiac tissues.
• Depress cardiac contractility
• ( negative inotropic effect )
• No prominent effect on the duration of the
  action potential
• e.g. Flecainide ,Propafenone


38
(No Transcript)
39
Clinical uses of class 1C

• Paroxysmal atrial flutter or fibrillation
• Life threatening ventricular arrhythmias
• ( Are used in arrhythmias not responding to
  other therapy)

40
Side effects

• Significant risk of
• Heart failure
• Proarrhythmias
• These drugs may increase mortality when
  administered to patients surviving myocardial
  infarction

41
(No Transcript)
42


• CLASS 11
• ß- Adrenergic receptor Antagonists
• blocking ß1- receptors in the heart ? reduce the
  sympathetic effect on the heart causing
• - decrease automaticity of S.A. node and
• ectopic pacemakers
• - slow conduction of the A.V node
• - Heart rate
• - Contractility

43


• CLINICAL USES
• Atrial arrhythmias associated with emotion,
• exercise
• Digitalis-induced arrhythmias
• Drugs of choice to Prevent ventricular
  fibrillation following myocardial infarction.
• e.g. Propranolol
• Esmolol

44
Class III

• Potassium channels blocking drugs
• Prolong the action potential duration effective
  refractory period .
• (Prolong phase 3 )

45
(No Transcript)
46


• AMIODARONE
• Main effect is to prolong action potential
  duration and refractory period
• Has an additional actions of classes 1,
  11 1V
• Has an a and ß-adrenoceptor blocking effects

47


• Clinical uses of amiodarone
• Treatment of recurrent ventricular tachycardia
  Fibrillation
• It is restricted for life-threatening
  arrhythmias.

48


• ADVERSE EFFECTS
• Bradycardia heart block, heart failure
• pulmonary fibrosis ,interstitial
  pneumonitis
• hyper- or hypothyroidism
• Skin deposits causes photodermatitis ,
  gray-blue skin rash.

49


• (CONTiNUE)
• Peripheral neuropathy
• constipation
• corneal opacities
• Hypotension

50


• Pharmacokinetics of Amiodarone
• extremely long t1/2 13 - 103 DAYS
• Drug Interactions
• reduce renal clearance of several drugs

51
Ibutilide

• Given by a rapid I.V. infusion
• Used for acute ( rapid ) conversion of atrial
  flutter or atrial fibrillation to normal sinus
  rhythm.
• Adverse effect
• QT interval prolongation ( precipitates
  torsade de pointes ).

52
Class 1V calcium channel blockers

• e.g. Verapamil, Diltiazem
• Site of action is A.V.N S.A.N .
• Inhibits calcium entry through L-type calcium in
  the myocardium and depress AV nodal transmission.


53


• Clinical uses of calcium channel blockers
• Atrial flutter - fibrillation
• Av nodal reentry
• NOT effective in ventricular arrhythmias

54
Side effects

• Sinus arrest or complete AV nodal blockade in the
  presence of ß-adrenergic receptor blockers

55
Miscellaneous Group

• e.g. ADENOSINE

56


• ADENOSINE
• - Naturally occurring nucleoside
• half-life less than 10 sec.
• Mechanism In cardiac tissues
• Binds to type 1 (A1) receptors which are coupled
  to Gi- proteins , activation of this pathway
  causing
• Opening of potassium channels
• (hyperpolarization)

57
Continue

• Decrease cAMP which inhibits L-type
• calcium channels (? calcium influx )
• causing decrease AV nodal conduction

58
(No Transcript)
59
Continue

• Adenosine increases the vagal tone of
• the AV node ? decrease conduction
• velocity in Av node

60


• Clinical uses of adenosine
• Drug of first choice for terminating an
• Episode of
• paroxysmal supraventricular tachycardia
• given 6 mg I.V. bolus followed by 12 mg if
• necessary

61


• Adverse effects
• Flushing headache
• Dyspnea and chest pain
• Hypotension

62


• BRADYARRHYTHMIAS
• ATROPINE
• sinus bradycardia after myocardial infarction
  and in heart block
• severe heart block isoprenaline may be
  combined with atropine

63


• NONPHARMACOLOGIC THERAPY OF ARRHYTHMIAS (CONTD)

• Implantable Cardiac Defibrillator (ICD)
• can automatically detect and treat fatal
• arrhythmias such as ventricular fibrillation


64
(No Transcript)
65
