Title: Standard Grade Technological Studies


1
Standard Grade Technological Studies
  • OR control

2
OR control
  • Sometimes we need to control a pneumatic circuit
    from more than one position
  • To do this we use or control.
  • Although simple, these circuits require another
    component called a shuttle valve.

3
Shuttle Valve
  • A shuttle valve is used to change the direction
    of air in a circuit.
  • It has a small ball inside that gets blown from
    side to side.
  • The symbol for a shuttle valve is shown.

4
Shuttle Valve
  • A picture of the inside of the shuttle valve is
    shown below.
  • When air is supplied from valve A.
  • The ball gets blown across.
  • Air is directed towards the cylinder.

5
Shuttle Valve
  • When air is supplied from valve B.
  • The ball gets blown across.
  • Air is directed towards the cylinder.

6
OR control
  • OR control involves connecting 3/2 valves in
    parallel.
  • This means that pressing either valve will
    outstroke the cylinder.
  • Below is a typical OR control circuit

7
OR control
  • The operation of an OR control circuit can be
    summarised in a truth table.

8
Assignment 10
1. Part of a production line involves a quality
check. If goods are found to be faulty then they
are pushed of the conveyor by a single acting
cylinder.
Two people are employed to make sure that no
faulty good leave the factory. They each operate
the cylinder by pressing a button.
9
Assignment 10
  • Design a circuit that will solve the problem.
  • Using a computer simulation, build and test your
    solution.
  • Construct your circuit using pneumatic
    components.
  • Explain how the circuit works.
  • Some one has suggested changing the shuttle valve
    to a T-piece. Why is this not a good idea?
  • (You may want to build this circuit to
    investigate)

10
Assignment 10
2. A bus door is operated by pneumatics. The
door is opened by a single acting cylinder and is
controlled by a 3/2 valve. In an emergency,
there should be a second valve that allows
passengers to open the doors.
11
Assignment 10
  • Design a circuit to solve the problem with the
    bus doors.
  • Using a computer simulation, build and test your
    solution.
  • Construct your circuit using pneumatic
    components.
  • Explain how your circuit works.
  • Explain your choice of actuators.
