Title: DNA


1
  • DNA DNA Replication

2
History
  • DNA
  • Comprised of genes
  • In non-dividing cell nucleus as chromatin
  • Protein/DNA complex
  • Chromosomes form during cell division
  • Duplicate to yield a full set in daughter cell

3
DNA is Genetic Material
4
From Chapter 2
  • Nucleic acids are polymers
  • Monomers are called nucleotides
  • Nucleotides base sugar phosphate
  • Base purine or pyrimidine
  • Purines adenine, guanine
  • Pyrimidines thymine, cytosine, uracil
  • Sugar deoxyribose or ribose
  • Phosphate, a single phosphate in DNA
  • Sugar of nt 1 is linked to the phosphate of nt 2
    by a phosphodiester bond

5
(No Transcript)
6
Chapter 2 contd
7
DNA is a Double Helix
  • Nucleotides
  • A, G, T, C
  • Sugar and phosphate form the backbone
  • Bases lie between the backbone
  • Held together by H-bonds between the bases
  • A-T 2 H bonds
  • G-C 3 H bonds

8
H - Bonds
  • Base-pairing rules
  • A?T only (A?U if DNA-RNA hybrid)
  • G?C only
  • DNA strand has directionality one end is
    different from the other end
  • 2 strands are anti-parallel, run in opposite
    directions
  • Complementarity results
  • Important to replication

9
Helical Structure
10
Nucleotides as Language
  • We must start to think of the nucleotides A, G,
    C and T as part of a special language the
    language of genes that we will see translated to
    the language of amino acids in proteins

11
Genes as Information Transfer
  • A gene is the sequence of nucleotides within a
    portion of DNA that codes for a peptide or a
    functional RNA
  • Sum of all genes genome

12
DNA Replication
  • Semiconservative
  • Daughter DNA is a double helix with 1 parent
    strand and 1 new strand
  • Found that 1 strand serves as the template for
    new strand

13
DNA Template
  • Each strand of the parent DNA is used as a
    template to make the new daughter strand
  • DNA replication makes 2 new complete double
    helices each with 1 old and 1 new strand

14
Replication Origin
  • Site where replication begins
  • 1 in E. coli
  • 1,000s in human
  • Strands are separated to allow replication
    machinery contact with the DNA
  • Many A-T base pairs because easier to break 2
    H-bonds that 3 H-bonds
  • Note anti-parallel chains

15
Replication Fork
  • Bidirectional movement of the DNA replication
    machinery

16
DNA Polymerase
  • An enzyme that catalyzes the addition of a
    nucleotide to the growing DNA chain
  • Nucleotide enters as a nucleotide tri-PO4
  • 3OH of sugar attacks first phosphate of tri-PO4
    bond on the 5 C of the new nucleotide
  • releasing pyrophosphate (PPi) energy

17
DNA Polymerase
  • Bidirectional synthesis of the DNA double helix
  • Corrects mistaken base pairings
  • Requires an established polymer (small RNA
    primer) before addition of more nucleotides
  • Other proteins and enzymes necessary

18
How is DNA Synthesized?
  • Original theory
  • Begin adding nucleotides at origin
  • Add subsequent bases following pairing rules
  • Expect both strands to be synthesized
    simultaneously
  • This is NOT how it is accomplished

19
Why DNA Isnt Synthesized 3?5
Correction Refer to Figure 6-15 on page 205 of
your textbook for corrected figure. This
figure fails to show the two terminal phosphate
groups attached on the 5 end of the nucleotide
strand located at the top of this figure.
20
How is DNA Synthesized?
  • Actually how DNA is synthesized
  • Simple addition of nucleotides along one strand,
    as expected
  • Called the leading strand
  • DNA polymerase reads 3 ? 5 along the leading
    strand from the RNA primer
  • Synthesis proceeds 5 ? 3 with respect to the
    new daughter strand
  • Remember how the nucleotides are added!!!!! 5 ?
    3

21
How is DNA Synthesized?
  • Actually how DNA is synthesized
  • Other daughter strand is also synthesized 5?3
    because that is only way that DNA can be
    assembled
  • However the template is also being read 5?3
  • Compensate for this by feeding the DNA strand
    through the polymerase, and primers and make many
    short segments that are later joined (ligated)
    together
  • Called the lagging strand

22
DNA Replication Fork Fig 6-12
23
Mistakes during Replication
  • Base pairing rules must be maintained
  • Mistake genome mutation, may have consequence
    on daughter cells
  • Only correct pairings fit in the polymerase
    active site
  • If wrong nucleotide is included
  • Polymerase uses its proofreading ability to
    cleave the phosphodiester bond of improper
    nucleotide
  • Activity 3 ? 5
  • And then adds correct nucleotide and proceeds
    down the chain again in the 5 ? 3 direction

24
Proofreading
25
Starting Synthesis
  • DNA polymerase can only ADD nucleotides to a
    growing polymer
  • Another enzyme, primase, synthesizes a short RNA
    chain called a primer
  • DNA/RNA hybrid for this short stretch
  • Base pairing rules followed (BUT A-U)
  • Later removed, replaced by DNA and the backbone
    is sealed (ligated)

26
Primers contd
  • Simple addition of primer along leading strand
  • RNA primer synthesized 5 ? 3, then
    polymerization with DNA
  • Many primers are needed along the lagging strand
  • 1 primer per small fragment of new DNA made along
    the lagging strand
  • Called Okazaki fragments

27
Removal of Primers
  • Other enzymes needed to excise (remove) the
    primers
  • Nuclease removes the RNA primer nucleotide by
    nucleotide
  • Repair polymerase replaces RNA with DNA
  • DNA ligase seals the sugar-phosphate backbone
    by creating phosphodiester bond
  • Requires Mg2 and ATP

28
Other Necessary Proteins
  • Helicase opens double helix and helps it uncoil
  • Single-strand binding proteins (SSBP) keep
    strands separated large amount of this protein
    required
  • Sliding clamp
  • Subunit of polymerase
  • Helps polymerase slide along strand
  • All are coordinated with one another to produce
    the growing DNA strand (protein machine)

29
Components of the DNA Replication
30
Polymerase Proteins Coordinated
  • One polymerase complex apparently synthesizes
    leading/lagging strands simultaneously
  • Even more complicated in eukaryotes

31
DNA Repair
  • For the rare mutations occurring during
    replication that isnt caught by DNA polymerase
    proofreading
  • For mutations occurring with daily assault
  • If no repair
  • In germ (sex) cells ? inherited diseases
  • In somatic (regular) cells ? cancer

32
Effect of Mutation
33
Uncorrected Replication Errors
  • Mismatch repair
  • Enzyme complex recognizes mistake and excises
    newly-synthesized strand and fills in the correct
    pairing

34
Mismatch Repair contd
  • Eukaryotes label the daughter strand with nicks
    to recognize the new strand
  • Separates new from old

35
Depurination or Deamination
  • Depurination removal of a purine base from the
    DNA strand
  • Deamination is the removal of an amine group on
    Cytosine to yield Uracil
  • Could lead to the insertion of Adenine rather
    than Guanosine on next round

36
Chemical Modifications
37
Thymine Dimers
  • Caused by exposure to UV light
  • 2 adjacent thymine residues become covalently
    linked

38
Repair Mechanisms
  • Different enzymes recognize, excise different
    mistakes
  • DNA polymerase synthesizes proper strand
  • DNA ligase joins new fragment with the polymer
