Title: Capacity of Finite-State Channels: Lyapunov Exponents and Shannon Entropy


1
Capacity of Finite-State ChannelsLyapunov
Exponents and Shannon Entropy
  • Tim Holliday
  • Peter Glynn
  • Andrea Goldsmith
  • Stanford University

2
Introduction
  • We show the entropies H(X), H(Y), H(X,Y), H(YX)
    for finite state Markov channels are Lyapunov
    exponents.
  • This result provides an explicit connection
    between dynamic systems theory and information
    theory
  • It also clarifies Information Theoretic
    connections to Hidden Markov Models
  • This allows novel proof techniques from other
    fields to be applied to Information Theory
    problems

3
Finite-State Channels
  • Channel state Zn ? c0, c1, cd is a Markov
    Chain with transition matrix R(cj, ck)
  • States correspond to distributions on the
    input/output symbols P(Xnx, Yny)q(x ,yzn,
    zn1)
  • Commonly used to model ISI channels, magnetic
    recording channels, etc.

R(c1, c3)
4
Time-varying Channels with Memory
  • We consider finite state Markov channels with no
    channel state information
  • Time-varying channels with finite memory induce
    infinite memory in the channel output.
  • Capacity for time-varying infinite memory
    channels is defined in terms of a limit

5
Previous Research
  • Mutual information for the Gilbert-Elliot channel
  • Mushkin Bar-David, 1989
  • Finite-state Markov channels with i.i.d. inputs
  • Goldsmith/Varaiya, 1996
  • Recent research on simulation based computation
    of mutual information for finite-state channels
  • Arnold, Vontobel, Loeliger, Kavcic, 2001, 2002,
    2003
  • Pfister, Siegel, 2001, 2003

6
Symbol Matrices
  • For each symbol pair (x,y) ? X x Y define a
    ZxZ matrix G(x,y)
  • Where (c0,c1) are channel states at times (n,n1)
  • Each element corresponds to the joint probability
    of the symbols and channel transition

G(x,y)(c0,c1) R(c0,c1) q(x0 ,y0c0,c1), ?
(c0,c1) ? Z
7
Probabilities as Matrix Products
  • Let m be the stationary distribution of the
    channel

The matrices G are deterministic functions of
the random pair (x,y)
8
Entropy as a Lyapunov Exponent
  • The Shannon entropy is equivalent to the Lyapunov
    exponent for G(X,Y)
  • Similar expressions exist for H(X), H(Y), H(X,Y)

9
Growth Rate Interpretation
  • The typical set An is the set of sequences
    x1,,xn satisfying
  • By the AEP P(An)gt1-e for sufficiently large n
  • The Lyapunov exponent is the average rate of
    growth of the probability of a typical sequence
  • In order to compute l(X) we need information
    about the direction of the system

10
Lyapunov Direction Vector
  • The vector pn is the direction associated with
    l(X) for any m.
  • Also defines the conditional channel state
    probability
  • Vector has a number of interesting properties
  • It is the standard prediction filter in hidden
    Markov models
  • pn is a Markov chain if m is the stationary
    distribution for the channel)

m
...
G
G
G
X
X
X


n
)

(
P
X
Z
p
2
1
n

1
n
n
m

...

G
G
G
1
X
X
X
2
1
n
11
Random Perron-Frobenius Theory
  • The vector p is the random Perron-Frobenius
    eigenvector associated with the random matrix GX

For all n we have
For the stationary version of p we have
The Lyapunov exponent we wish to compute is
12
Technical Difficulties
  • The Markov chain pn is not irreducible if the
    input/output symbols are discrete!
  • Standard existence and uniqueness results cannot
    be applied in this setting
  • We have shown that pn possesses a unique
    stationary distribution if the matrices GX are
    irreducible and aperiodic
  • Proof exploits the contraction property of
    positive matrices

13
Computing Mutual Information
  • Compute the Lyapunov exponents l(X), l(Y), and
    l(X,Y) as expectations (deterministic
    computation)
  • Then mutual information can be expressed as
  • We also prove continuity of the Lyapunov
    exponents on the domain q, R, hence

14
Simulation-Based Computation(Previous Work)
  • Step 1 Simulate a long sequence of input/output
    symbols
  • Step 2 Estimate entropy using
  • Step 3 For sufficiently large n, assume that the
    sample-based entropy has converged.
  • Problems with this approach
  • Need to characterize initialization bias and
    confidence intervals
  • Standard theory doesnt apply for discrete symbols

15
Simulation Traces for Computation of H(X,Y)
16
Rigorous Simulation Methodology
  • We prove a new functional central limit theorem
    for sample entropy with discrete symbols
  • A new confidence interval methodology for
    simulated estimates of entropy
  • How good is our estimate?
  • A method for bounding the initialization bias in
    sample entropy simulations
  • How long do we have to run the simulation?
  • Proofs involve techniques from stochastic
    processes and random matrix theory

17
Computational Complexity of Lyapunov Exponents
  • Lyapunov exponents are notoriously difficult to
    compute regardless of computation method
  • NP-complete problem Tsitsiklis 1998
  • Dynamic systems driven by random matrices
    typically posses poor convergence properties
  • Initial transients in simulations can linger for
    extremely long periods of time.

18
Conclusions
  • Lyapunov exponents are a powerful new tool for
    computing the mutual information of finite-state
    channels
  • Results permit rigorous computation, even in the
    case of discrete inputs and outputs
  • Computational complexity is high, multiple
    computation methods are available
  • New connection between Information Theory and
    Dynamic Systems provides information theorists
    with a new set of tools to apply to challenging
    problems
