Nonlinear Dimension Reduction

1
Nonlinear Dimension Reduction

• Presenter Xingwei Yang
• The powerpoint is organized from
• 1.Ronald R. Coifman et al. (Yale University)
• 2. Jieping Ye, (Arizona State University)

2
Motivation
Linear projections will not detect the pattern.
3
Nonlinear PCA using Kernels

• Traditional PCA applies linear transformation
• May not be effective for nonlinear data
• Solution apply nonlinear transformation to
  potentially very high-dimensional space.
• Computational efficiency apply the kernel trick.
• Require PCA can be rewritten in terms of dot
  product.

More on kernels later
4
Nonlinear PCA using Kernels

• Rewrite PCA in terms of dot product

The covariance matrix S can be written as
Let v be The eigenvector of S corresponding to
nonzero eigenvalue
Eigenvectors of S lie in the space spanned by all
data points.
5
Nonlinear PCA using Kernels
The covariance matrix can be written in matrix
form
Any benefits?
6
Nonlinear PCA using Kernels

• Next consider the feature space

The (i,j)-th entry of
is
Apply the kernel trick
K is called the kernel matrix.
7
Nonlinear PCA using Kernels

• Projection of a test point x onto v

Explicit mapping is not required here.
8
Diffusion distance and Diffusion map
8/14

• A symmetric matrix Ms can be derived from M as
• M and Ms has same N eigenvalues,
• Under random walk representation of the graph M

f left eigenvector of M y right eigenvector
of M
e time step
9
Diffusion distance and Diffusion map

• e has the dual representation (time step and
  kernel width).

• If one starts random walk from location xi , the
  probability of
• landing in location y after r time steps
  is given by
• For large e, all points in the graph are
  connected (Mi,j gt0) and
• the eigenvalues of M

where ei is a row vector with all zeros except
that ith position 1.
10
Diffusion distance and Diffusion map

• One can show that regardless of starting point
  xi

Left eigenvector of M with eigenvalue l01
with

• Eigenvector f0(x) has the dual representation
• 1. Stationary probability distribution on
  the curve, i.e., the
• probability of landing at location x
  after taking infinite
• steps of random walk (independent of the start
  location).
• 2. It is the density estimate at location
  x.

11
Diffusion distance

• For any finite time r,

• yk and fk are the right and left eigenvectors
  of graph Laplacian M.
• is the kth eigenvalue of M r (arranged in
  descending order).

• Given the definition of random walk, we denote
  Diffusion
• distance as a distance measure at time t
  between two pmfs as

with empirical choice w(y)1/f0(y).
12
Diffusion Map

• Diffusion distance

• Diffusion map Mapping between original space
  and first
• k eigenvectors as

Relationship

• This relationship justifies using Euclidean
  distance in diffusion
• map space for spectral clustering.
• Since , it is justified
  to stop at appropriate k with
• a negligible error of order O(lk1/lk)t).

13
Example Hourglass
14
Example Image imbedding
15
Example Lip image
16
Shape description
17
Dimension Reduction of Shape space
18
Dimension Reduction of Shape space
19
Dimension Reduction of Shape space
20
References

• Unsupervised Learning of Shape Manifolds (BMVC
  2007)
• Diffusion Maps(Appl. Comput. Harmon. Anal. 21
  (2006))
• Geometric diffusions for the analysis of data
  from sensor networks (Current Opinion in
  Neurobiology 2005)
