Client-Server Processing and

1
Chapter 17

• Client-Server Processing and
• Distributed Databases

2
Outline

• Overview of Distributed Processing and
  Distributed Data
• Client-Server Database Architectures
• Web Database Connectivity
• Architectures for Distributed Database Management
  Systems
• Transparency for Distributed Database Processing
• Distributed Database Processing

3
Evolution of Distributed Processing and
Distributed Data

• Need to share resources across a network
• Timesharing (1970s)
• Remote procedure calls (1980s)
• Client-server computing (1990s)

4
Timesharing Network
5
Resource Sharing with a Network of Personal
Computers
6
Client-Server Processing with Distributed
processing only
7
Distributed processing and data
8
Motivation for Distributed Processing

• Flexibility the ease of maintaining and adapting
  a system
• Scalability the ability to support scalable
  growth of hardware and software capacity
• Interoperability open standards that allow two
  or more systems to exchange and use software and
  data

9
Motivation for Distributed Data

• Data control locate data to match an
  organizations structure
• Communication costs locate data close to data
  usage to lower communication cost and improve
  performance
• Reliability increase data availability by
  replicating data at more than one site

10
Summary of Distributed Processing and Data
11
Client-Server Database Architectures

• Client-Server Architecture is an arrangement of
  components (clients and servers) among computers
  connected by a network.
• A client-server architecture supports efficient
  processing of messages (requests for service)
  between clients and servers.

12
Design Issues

• Division of processing the allocation of tasks
  to clients and servers.
• Process management interoperability among
  clients and servers and efficiently processing
  messages between clients and servers.
• Middleware software for process management

13
Tasks to Distribute

• Presentation code to maintain the graphical user
  interface
• Validation code to ensure the consistency of the
  database and user inputs
• Business logic code to perform business
  functions
• Workflow code to ensure completion of business
  processes
• Data access code to extract data to answer
  queries and modify a database

14
Middleware

• A software component that performs process
  management.
• Allow clients and servers to exist on different
  platforms.
• Allows servers to efficiently process messages
  from a large number of clients.
• Often located on a dedicated computer.

15
Client-Server Computing with Middleware
16
Types of Middleware

• Transaction-processing monitors relieve the
  operating system of managing database processes
• Message-oriented middleware maintain a queue of
  messages
• Object-request brokers provide a high level of
  interoperability and message intelligence
• Data access middleware provide a uniform
  interface to relational and non relational data
  using SQL

17
Two-Tier Architecture
18
Two-Tier Client-Server Architecture

• A PC client and a database server interact
  directly to request and transfer data.
• The PC client contains the user interface code.
• The server contains the data access logic.
• The PC client and the server share the validation
  and business logic.

19
Three-Tier Architecture (Middleware Server)
20
Three-Tier Architecture (Application Server)
21
Three-Tier Architecture

• To improve performance, the three-tier
  architecture adds another server layer either by
  a middleware server or an application server.
• The additional server software can reside on a
  separate computer.
• Alternatively, the additional server software can
  be distributed between the database server and PC
  clients.

22
Multiple-Tier Architecture

• A client-server architecture with more than three
  layers a PC client, a backend database server,
  an intervening middleware server, and application
  servers.
• Provides more flexibility on division of
  processing
• The application servers perform business logic
  and manage specialized kinds of data such as
  images.

23
Multiple-Tier Architecture
24
Multiple-Tier Architecture with Software Bus
25
Web Database Connectivity

• Internet commerce depends heavily on database
  access for websites.
• Web database connectivity allows a database to be
  manipulated through a Web page.
• A user may use a Web form to change a database or
  view a report generated from a database.

26
Internet Basics

• Network of networks
• Uses standard protocols TCP/IP
• TCP splits messages into packets
• IP routes messages
• Each computer on the Internet has a unique
  numeric address known as an IP address.

27
Internet and Intranet Relationship
28
World Wide Web

• Most popular application on the Internet
• Supports browsing pages located on any computer
  on the Internet
• Hypertext Transport Protocol (HTTP) establishes a
  session between a browser and a Web server.
• Each page has a unique address known as a URL.

29
Web Page Request Cycle
30
XML/XSL

• Solutions to HTML limitations
• eXtensible Markup Language (XML)
• Separates content and structure of a document
• Use document type declaration or schema to
  specify document structure
• eXtensible Style Language (XSL) supports
  transformation into display languages
• Both are extensible languages

31
The Common Gateway Interface (CGI)

• CGI is an interface that allows a Web server to
  invoke an external program on the same computer.
• The external program uses the parameters passed
  by the Web server to produce output that is sent
  back to the browser.
• Usually, the output contains HTML/XML so that the
  browser can display it properly.

32
Straight CGI
33
Hybrid CGI
34
Server-side connectivity

• Server-side connectivity bypasses the external
  program needed with the CGI approaches.
• Specialized Web server or middleware server is
  needed
• SQL statements and database logic are kept in a
  web page or external file.
• The database code can execute stored procedures
  on the database server.

35
Server-Side Connectivity Approach
36
Server-Side Connectivity with a Middleware Server
37
Client-Side Connectivity

• Client computing capacity can be more fully
  utilized without storing code on the client.
• Provides a more customized interface than
  permitted by HTML
• Supports data buffering by the client to improve
  performance

38
Web Page Request Cycle with Client-Side
Connectivity
39
Summary of Web Connectivity
40
Architectures for Distributed Database Management
Systems

• DBMSs need fundamental extensions.
• Underlying the extensions are a different
  component architecture and a different schema
  architecture.
• Component Architecture manages distributed
  database requests.
• Schema Architecture provides additional layers of
  data description.

41
Global Requests
42
Component Architecture
43
Schema Architecture I
44
Schema Architecture II
45
Transparency for Distributed Database Processing

• Transparency is related to data independence.
• With transparency, users can write queries with
  no knowledge of the distribution, and
  distribution changes will not cause changes to
  existing queries and transactions.
• Without transparency, users must reference some
  distribution details in queries and distribution
  changes can lead to changes in existing queries.

46
Motivating Example
47
Fragments Based on the CustRegion Field
48
Fragments Based on the WareHouseNo Field
49
Fragmentation Transparency

• Fragmentation transparency provides the highest
  level of data independence.
• Users formulate queries and transactions without
  knowledge of fragments (locations, or local
  formats).
• If fragments change, queries and transactions are
  not affected.

50
Location Transparency

• Location transparency provides a lesser level of
  data independence than fragmentation
  transparency.
• Users need to reference fragments in formulating
  queries and transactions.
• However, knowledge of locations and local formats
  is not necessary.

51
Local Mapping Transparency

• Local mapping transparency provides a lesser
  level of data independence than location
  transparency.
• Users need to reference fragments at sites in
  formulating queries and transactions.
• However, knowledge of local formats is not
  necessary.

52
Distributed Database Processing

• Distributed data adds considerable complexity to
  query processing and transaction processing.
• Distributed database processing involves movement
  of data, remote processing, and site
  coordination.
• Performance implications sometimes cannot be
  hidden.

53
Distributed query processing

• Involves both local (intra site) and global
  (inter site) optimization.
• Multiple optimization objectives
• The weighting of communication costs versus local
  processing costs depends on network
  characteristics.
• There are many more possible access plans for a
  distributed query.

54
Distributed Transaction Processing

• Distributed DBMS provides concurrency and
  recovery transparency.
• Independently operating sites must be
  coordinated.
• New kinds of failures exist because of the
  communication network.
• New protocols are necessary.

55
Distributed Concurrency Control

• The simplest scheme involves centralized
  coordination.
• Centralized coordination involves the fewest
  messages and the simplest deadlock detection.
• The number of messages can be twice as much in
  distributed coordination.
• Primary Copy Protocol is used to reduce overhead
  with locking multiple copies.

56
Centralized Coordination
57
Distributed Recovery Management

• Distributed DBMSs must contend with failures of
  communication links and sites.
• Detecting failures involves coordination among
  sites.
• The recovery manager must ensure that different
  parts of a partitioned network act in unison.
• The protocol for distributed recovery is the two
  phase commit protocol (2PC).

58
Voting and Decision Phases
59
Summary

• Utilizing distributed processing and data can
  significantly improve DBMS services but at the
  cost of new design challenges.
• Several client-server architectures provide
  alternatives among cost, complexity, and benefit
  levels.
• Architectures for distributed DBMSs differ in the
  integration of the local databases and level of
  data independence.
