Critical Infrastructure Protection In the Transportation Network

1
Critical Infrastructure Protection In the
Transportation Network

• A Mathematical Model and Methodology for
  Determining and Analyzing The k-Critical Links
  of a Highway Network

2
Objective

• The objective of this dissertation is to develop
  a methodology, using a SE approach, and apply the
  methodology to a mathematical model, using
  performance metrics such as travel time and flow,
  to simulate the impacts k-Links disconnects have
  on highway networks of major metropolitan cities
  for risk mitigation and resource allocation

3
The Systems Engineering Process

• Problem Definition and Need Identification
• Feasibility Study
• Operational Requirements
• Maintenance Support Concept
• Technical Performance Measures
• Functional Analysis and Allocation

4
The Systems Engineering Process

• Trade-Off Analyses
• System Specification

5
Problem Definition and Need Analysis

• Defining the System System of Systems

6
Example of Model
Problem Definition and Need Analysis
7
Feasibility Study

• What tools are available to perform analysis?
• What methods have been developed in this area?

8
Operational Requirements
Prime Definition Of Mission
Operating Environment
Performance Parameters
Requirements
Operational Deployment
Effectiveness Factors
Operational Life Cycle
Utilization Requirements
9
Maintenance Concept

• Levels of Maintenance
• Repair Policies
• Organizational Responsibilities
• Maintenance Support Elements
• Effectiveness Requirements
• Environment

10
Technical Performance Parameters
Efficiency Of Model
Accuracy Of Model
Simulation
11
Functional Analysis

• Transportation CI SoS

• INPUT
• Disconnects
• Hrs of Op.

• PROCESS
• Mathematical
• model

• OUTPUT
• Performance

Components
Perf. of Defined Links
Efficiently Finding K Links
Movement of Goods
Relationships

• Flow
• Distance

• Links
• Nodes
• Efficiency
• of model

• Disconnects
• Hours of
• operation

Attributes
12
Functional Analysis
System Solution
System Requirements
Functional Analysis
V
Validate Verify
System Objective
Simulation Processing Time
City Boundary
Simulation Processing Time
Section of City
Small Network
Enumeration
Actual Model
13
Network
Trade-Off Analysis
L1
L2
L3

• Output
• Performance
• Travel Time/Throughput

Input Single Disconnect 1/0
I35W
I35E
Hwy 75
I30
L4
I20
I1
I20
L5
L9
I1
I35W
I35E
I45

• Variables
• Temporal
• Time of Day I 1, 2, 3 (peak, norm, other)
• Links l (i,j), (i1), (j1),, (in, jn)

L8
L7
L6
14
Trade-Off Analysis Link (a,b)
Time, Flow
15
Trade-Off Analysis Link (a,b)
D Avg. T 2.5 Min/Veh
16
Trade-Off Analysis All Links
17
Trade-Off Analysis
18
Example of Model Performance for a General Metric
Trade-Off Analysis
OUTPUTS
, ,
Sum of Performance
19
Example of Model
Trade-Off Analysis
OUTPUTS
Worst
k Links 2,11, , 1,12 affecting the
Transportation CI the most
Performance
Best
Links
0 is threshold
20
Validation and Verification
System Specification

• SE Approach
• Integrations Process
• Verify and Validate Requirements
• Model
• Small Network
• Enumeration
• Efficiency of Model

V
21
Research Significance

• Contribution This dissertation provides
  officials a decision-making methodology and tool
  for resource allocation and risk mitigation
• Metrics that measure the performance of the
  network given disconnects occurring
• Ranking of k Links affecting the network the most

22
Research Significance

• Decision Making Methodology and Tool

23
Conclusion

• Transportation CI is important
• To individuals way of life
• To companies way of doing business
• Proposed a Methodology using a Mathematical Model
  to Determine Impact of k Links Disconnects have
  on the Defined Links of a Network for risk
  mitigation and resource allocation

24
Conclusion

• Research Significance
• Society A Methodology and Tool for Officials to
  use in the Decision Making Process
• Engineering
• Systems Engineering Approach for Solving Complex
  Systems
• Efficient and Accurate Network Modeling for Large
  and Complex Systems

25
Terms and Definitions

• Critical Infrastructure (CI)
• System
• Transportation CI
• System of Systems (SoS)
• Major Cities
• City Boundary
• Network

26
Terms and Definitions

• Movement of Goods
• Trucks
• Peak Traffic
• Normal Traffic
• Other Traffic
• Days of Operation

27
Terms and Definitions

• Node
• Arc ? Link
• Disconnect
• Shortest Path
• Steady State
• Snapshot of System

• Highway
• Defined Links
• Worst Link
• Best Link

28
The Systems Engineering Process

• Need Analysis
• Stakeholders
• City
• State and Federal
• Business
• Society

29
The Systems Engineering Process

• Requirements
• Mission Definition
• Performance and Physical Parameters
• Use Requirements

30
The Systems Engineering Process

• Ground Rules and Assumptions
• Highway
• Major Cities
• Steady State
• Disconnect
• Shortest Path
• Snapshot of System

31
The Systems Engineering Process

• Metrics
• Performance of Network
• Travel Time
• Throughput

32
The Systems Engineering Process

• Model
• Most naive process
• Disconnect Link (Ai,j) subject to Time (tn)
• Simulate Network Performance
• Connect Link (Ai,j)
• Repeat until all links tested

33
The Systems Engineering Process

• Model (Continued)
• Objective
• Performance of Network based on Defined Links
• Constraints
• Mathematical model of how the system responds to
  changes in variables
• Variables
• Time of Day
• Disconnected Links

34
Brief Literature Review

• SE
• Osmundson et al, The Journal of The International
  Council on Systems Engineering (INCOSE), 2004
• Tahan et al, The Journal of The INCOSE, 2005
• Bahill et al, The Journal of The INCOSE, 2005
• Blanchard et al, Stems Engineering and
  Analysis, 1990
• INCOSE, Systems Engineering Handbook, 2004
• Hazelrigg, Sys. Eng. An Approach to
  Information-Based Design 1996
• Miller et al, Systems Engineering Management,
  2002
• Stock et al, Strategic Logistics Management,
  1993
• Ibarra et al, Conference for Systems Engineering,
  2005
• Blanchard, Logistics Engineering and
  Management, 2004
• US Department of Homeland Security, Budget in
  Brief, Fiscal Year 2005

35
Brief Literature Review

• Modeling
• Osmundson et al, The Journal of The International
  Council on Systems Engineering (INCOSE), 2004
• Bahill et al, The Journal of The INCOSE, 2005
• Sathe et al, Transportation Research Board, 2005
• Jain et al, Transportation Science, 1997
• Arroyo et al, Transportation Research Board, 2005
• Rardin, Optimizations in Operations Research,
  1998
• Rinaldi et al, IEEE Control System Magazine, 2001
• Murray-Tuite, Dissertation, 2003
• Yan et al, IEEE/ACM, 2000
• Orda et al, IEEE/AMC, 2003

36
Questions

• What is cost of truck if delayed by 15 minutes
• Airplanes at 1,000 per minute 2002 (Vacante)
• Show how it has practical implication
• Convert time to cost
• Tell city fathers what they need to fix and where
  do you beef up security and resources
• If you cannot go straight, then which way?
• Time to fix link?
• Minimize time to fix
• Suggestions to repair

37
Questions

• Minimize risk
• Which rout to take
• Link Reliability of the system given a
  terrorist attack
• How much more time is it going to take to get to
  destination
• Minimize the time, increase throughput
• Value of dissertation
• This will tell you how to get around accidents in
  time and efficient manner
• Create fluid
• Create situation where they do not get stuck in
  other jams
• Probability of accident increases on new route

38
Questions

• Focus on mitigation
• How to mitigate time loss and improve throughput
• Alternate routes for final destination is least
  amount of time

39
Outline

• Terms and Definitions
• Objective
• Brief Literature Review
• Research Significance
• The Systems Engineering (SE) Process

40
Outline

• Network
• Ideas for Improving Algorithmic Model
  Efficiencies
• Validation and Verification
• Conclusion

41
Non-Eventful Days Construction established and
on-going Mon Fri
42
Example of Model
Time
Number of Vehicles traveling from Origin to
Destination during Off-Peak Period
43
Example of Model Routing Assignment
44
Example of Model Effects of Disconnect on Link
(a,b)
D Avg. T 2.5 Min/Veh
Time, Flow
45
Research Significance

• Algorithm for finding efficiently the K Links
  with the greatest impact on the network

Accuracy Vs. Time
Accuracy
Minutes
46
The Systems Engineering Process

• Metrics
• Performance of Network
• Travel Time
• Throughput
• Solution Processing Time of Model (as a
  function of OD table and network topology)

Model / Algorithm
(OD)
Time
Links
Accuracy
47
Ideas for Improving Algorithmic Model Efficiencies

• Restricting the Search Space
• Find least reliable links
• Find largest/lightest flow
• Approximation Methods
• Quickly find Good solution

48
Objective

• Two Objective Steps
• 1. Systems Engineering Approach
• 2. K Links with Highest Affect on Network

49
(No Transcript)
50
(No Transcript)
51
Example of Model Effects of Disconnect on Link
(a,b)
D Avg. T 2.5 Min/Veh
52
Trade-Off Analysis

• Geographical Interdependencies
• Rail lines
• Power plants
• Reliability of link
• Pipe lines
• Population
• Water
• Bridge
