Engaging Computing: Makin

1
Engaging ComputingMakin It Realfor Kids and
Undergrads

• Fred G. Martin
• University of Massachusetts Lowell

2
Overview

• Computational design primitives
• Projects/applications/ideas for
• Elementary school
• Teenagers
• High school and college

3
P-Brick/Handy Board/LEGO RCX Brick/Cricket
4
Computational Jewelry

• Worked in 4th grade classroom in Smithfield, RI
• With Mary Lurgio, a teacher accomplished with
  project-based learning
• And Denis Coffey, an engineer educator

5
Computational Jewelry

• The idea build necklaces that would perform
  personality correlations
• Inspired by MIT Media Lab Thinking Tag project
  (Rick Borovoy)

6
Four Questions

• Are you a girl?
• Are you left-handed?
• Do you have pets?
• Are you 9 yrs. old or younger?

7
Boolean Algebra
8
Implementation
Little expansion board Goes your lapel Has
outputs for 7 lights
Wear the Cricket on your wrist, Aim it at your
friend and they can Communicate with infrared
9
Logo Programming
10
Computational Jewelry
11
Computational Jewelry
12
Computational Jewelry
13
UML DESIGNCAMP

• 1 month of week-long design-oriented classes for
  teenagers
• Shipwreck Electronics,Kinetic Sculpture,
  Sea-Mobiles, Electronics Music, etc
• Created and run by Douglas Prime,
  www.designcamp.org

14
Animatronics Camp
15
Animatronic Dog (2 of 3)
16
Animatronics Dog (3 of 3)
17
Happy Halloween!
18
Animatronics Camp
19
Robot Contests(HS College)

• Botball
• Egghunt
• Trinity Fire-Fighting

20
Botball

• National design contest for middle and HS kids
  run by KIPR.org
• 13 regional contests 1 national
• Focuses on kids doing the engineering themselves

21
Egghunt
22
Trinity Fire-Fighting
23
Big Teams Big Robots

• Big team is gt 3 people
• Big robot is too big to step on
• Such as

24
Power Wheels!
25
When its big

• Technical integration is hard
• Team dynamics can be hard
• Physics matters!

26
The Steering
27
Motors Need Many Amps
28
Demos Dont Always Work
29
Calcomp Pen Plotters
30
Student Work
31
Spiral
32
Midpoint Fractal
33
Random Walk 1
34
Random Walk 2
35
Design Process

• Run the program a bunch of times, capturing
  output to named files
• Preview files on-screen, choosing nice ones to
  print
• Then we thought

36
Each one is an original
37
Portrait Engravings

• Work done by Karthik Ramanathan
• Roland EGX-300 Engraving Machine a
  computer-controlled Dremel tool
• Speaks HPGL just like the pen plotters
• Convert bitmap image into grid of variable depth
  drill hits

38
Portrait Engravings
39
In Closing

• Writing code is fun
• Writing code that controls stuff is fun
• Writing code that controls stuff is a good way to
  learn how to write code.
