1
A6 Team RallyePotable Water Still
  • Presented by
  • Nicole Del Rey
  • November 9, 2006

Nicole Del Rey Mike McConnell Tim Rodts
Eric Sabelhaus
2
Design Status
3
Design Status
  • Power (assembled)
  • ? Pedals ? Intermediate Gears? Generator
  • Heat Source
  • (assembled and tested)
  • Heating bowl ? Sand ? Baby bottle
  • Condensing
  • (assembled and tested)
  • ? Tygon tubing, 2nd baby bottle (tested well)
  • Intelligence (purchased)
  • ? Temperature Sensor with Display

4
Prototype Status
5
Updated Schedule
UPDATED SCHEDULE (11/07/2006)
6
Budget
Item Purchaser Price Receipt Total Price
Generator   126.00   352.95
Chair Sabelhaus 5.29
Bikes (2) N/A 2.00 N
Temp. Sensor LCD battery McConnell   N
Temp. Sensor McConnell 13.73
base Nicole 5.75
HDPE Sabelhaus 90.51
Screws/Chair back rod, angle iron, L-brackets, 4 large, 4 small McConnell 28.08
Glass tubes Nicole 5.29
Sprocket sleeve N/A 2.00 N
2x6 and screws Sabelhaus 10.91
Ceramic tile, L-brackets, nuts/bolts Nicole 21.27
Power cord, nuts/bolts Nicole 11.75
Screws/Nuts/Bolts for condenser stand, ceramic tile and adhesive Nicole 23.07
batteries, screws Nicole 7.30
7
Action Items from last week (Week 11)
8
-1-
  • TASK Prepare Temperature Sensor
  • ACTION
  • Consulted with Mr. Brownell to find out that
    current temperature sensors were NOT usable
  • New Sensors were ordered and received
  • LCD, battery and wires have been located

9
-2-
  • TASK Create 3-Way Interface
  • Generator output wire/Voltmeter leads/Female
    outlet
  • ACTION

10
-3-
  • TASK Create driveshaft/sprocket interface
  • ACTION Contacted Value Tool Engineering to help
    us add a hub and set screw to a sprocket we had
    from one of our bikes

11
Action Items for this week (Week 12)
12
-1-
  • TASK Temperature Sensor Set-up
  • ACTION
  • Assemble wires, LCD and Power source
  • Attach the sensor to the polluted water container
  • Program the Micro controller

13
-2-
  • TASK Finish Assembly and Test Prototype
  • ACTION
  • Finish mounting Generator
  • Finish mounting Condensor Supports
  • Test Prototype

14
-3-
  • TASK Finish Documentation
  • ACTION
  • Updates on the website
  • Assign parts of Executive summary
  • Start working on demonstation presentation
    materials

15
Questions?
