Inferring Conceptual Knowledge from Unstructured Student Writing

1
Inferring Conceptual Knowledge from Unstructured
Student Writing
Workshop Personalizing Education with Machine
Learning Neural Information Processing Systems
(NIPS) ConferenceLake Tahoe, CA, 8 December 2012

• Norma C. Ming

Vivienne L. Ming
2
The role of assessment in instruction

• Reveals what students already know and what they
  need to learn
• Provides feedback to students and teachers on
  success of learning and instruction

• Timely and specific feedback can guide continued
  instruction (formative assessment)

Graphic from http//www.cmu.edu/teaching/assessmen
t/basics/alignment.html
3
Challenges with assessment

• Large-scale assessment
• Heavy on summative assessment
• Standardized tests, academic analytics systems
• Emphasize performance, not conceptual
  understanding
• Delayed, coarse-grained feedback
• Intrusive
• Interrupt class to administer test
• Modify instruction to adopt others materials
• Alternatives
• Teachers may lack training in designing and
  interpreting other kinds of assessment
• Difficult to aggregate, calibrate

Printable sign available athttp//www.pickens.k12
.ga.us/assessment.html
4
Our goals

• Use continuous, passive assessmentto elucidate
  conceptual knowledge.
• Wealth of unstructured data
• Informal
• Build on teachers existing instruction
• Align with formal assessment, e.g.
• course grades
• standardized tests
• instructor qualitative assessment

5
Research questions

1. Can topic models of unstructured student writing
   predict course outcomes?
2. How does the accuracy of these predictions change
   over time as more student work is analyzed?
3. What does learning the topic hierarchy add beyond
   conventional topic modeling in improving these
   predictions?

6
Dataset Methods

• Online discussion forums
• 5- or 6-week courses
• 2 mandatory discussion questions per week
• Introductory courses at large, for-profit
  university

Biology (undergraduate) Economics (MBA)
Course length (wks) 5 6
discussion question threads per class 10 12
classes 17 45
students (after filtering) 230 970
posts by students 9118 44345
7
Analytical approach

• Outcome of interest Student conceptual
  understanding
• Proxy Outcome Student course grade
• Compare possible data features
• Baseline
• Mean course grade
• Individual student posting characteristics
• Word count
• Conventional Semantic Modeling
• Probabilistic Latent Semantic Analysis (pLSA)
• Feature of Interest
• Hierarchical Latent Dirichlet Allocation (hLDA)

8
Algorithms

• Proof of concept
• Logistic regression on the accumulated topic
  coefficients from each week
• Other supervised algorithms (e.g., SVM) surely
  better
• LR chosen to focus on contribution from hLDA
• Current work utilizes
• HCRF (Hidden-state Conditional Random Fields)
• Improved weekly predictions
• Allows forward prediction in course time

9
Results Biology course

• Prediction accuracy
• Word count gt mean (for 3 wks)
• pLSA gtgt word count
• hLDA gt pLSA
• With more data collected over time
• All predictions improve.

10
Results Economics course

• Prediction accuracy
• Word count gt mean (for 2 wks)
• pLSA gt word count
• hLDA gtgt pLSA
• With more data collected over time
• All predictions improve.

11
Topic modeling can distinguish topics discussed
by final grades.

• Each point represents posts by one student
• Posts projected in 100-D pLSA concept space
• Used local linear embedding (LLE) to reduce to
  2-D

Cs Ds neglect these topics
Increasing final grades
12
Comments by higher grade-earners reveal more
structure.

• Each point represents one post, color-coded by
  grade
• Ds and below cluster in the center
• Higher grades move in specific directions toward
  periphery
• Directions may correspond to course structure or
  instructors guidance
• Not just depth or specificity, but particular
  concepts

13
Structure corresponds to course topics.

• Same points, color-coded by week
• Different weeks on different branches
• Low grades stay in center even when discussion
  topics invite more specific comments.

14
What does hierarchical modeling add?

• Not all language is equal.
• Conventional topic modeling treats all topics as
  equal (and independent).
• Hierarchy implies ranking
• Shallower more frequent and generic language
• Deeper more infrequent and technical language

15
Examining hLDA results (Econ)

• Posts from students earning higher grades
  correlated with

• Higher mean of depth in hLDA
• C grades most language at shallowest level
• A, B grades more language at deeper levels
• More technically proficient language use
• General language more anecdotal comments
• Specific language greater conceptual depth

16
Summary of results

• Can topic models of unstructured student writing
  predict course outcomes?
• YES pLSA, hLDA both better than chance (and
  better than post length).
• How does the accuracy of these predictions change
  over time as more student work is analyzed?
• Extra weeks of data improves predictions.
• By end of course, pLSA predictions are within one
  letter grade.
• What does learning the topic hierarchy add beyond
  conventional topic modeling in improving these
  predictions?
• hLDA gt pLSA
• Higher grades associated with discussion of
  deeper topics in hLDA.

17
Conclusions and Future Work

• There is some collection of topics associated
  with higher grades (and some other collection of
  topics associated with lower grades).
• Deeper topics associated with low/high grades
  could potentially differ analysis yet to be
  done.
• i.e., deep misconceptions such as inheriting
  acquired traits (Lamarckian evolution)
• Next steps
• Create topic map
• Hierarchical relationships
• Normative sources (e.g., textbook, exemplary
  student work)
• Labeled, non-normative sources (common
  misconceptions)

18
Implications

• Extensions to other text data
• Essays, short-answer test questions
• Online tutoring
• Informal learning environments (e.g., Quora,
  Evernote)
• Annotations on e-texts
• Wiki contributions
• Language mediates learning text is everywhere.
  Learn from it, improve it.
