Work

1
Work Simple Machines
2
Define / Describe WORK
3
Define / Describe WORK

• Work is done when a force causes an object to
  move in the direction that the force is applied.
• The formula for work is W F X D
• Unit is joules
• If there is no movement, there is no work

4
Two things must happen for work to be done.
What are they?
5
Two things must happen for work to be done.
What are they?

• A force must applied to an object
• The object must move in the same direction as the
  force.

6
Types of Energy

1. Potential energy- stored energy
2. Kinetic energy- energy in motion
3. Mechanical energy- combination of potential and
   kinetic energy.

http//www.teachertube.com/video/story-of-kinetic-
and-potential-energy-127812
7
Law of conservation of energy- no matter how
energy in transferred or transformed, all of the
energy is still present.
8
What is purpose of a machine?
9
What is purpose of a machine?

• To make work easier.

10
How do machines make work easier?
11
How do machines make work easier?

• They can change the amount of force
• They can change the distance
• (Remember that Work Force X Distance)
• They can also change the direction

MORE
12
How do machines make work easier?

• Any change in the size of the force changes the
  distance. No machine can increase both force and
  distance.
• Multiply force which decreases distance the load
  moves.
• Multiply the distance which decreases force.
• Or, they leave force and distance alone but
  change the direction in which the load moves.

13
What is mechanical advantage?
14
What is mechanical advantage?

• The number of times a machine multiplies the
  effort or input force.

15
What are the 6 types of simple machines?
16
What are the 6 types of simple machines?

• There are three simple machines
• The lever, the pulley, and the inclined plane
  The wheel and axle, the wedge, and the screw are
  modifications of these simple machines.

17
What is a compound (or complex) machine?
18
What is a compound (or complex) machine?

• A machine made up of two or more simple
  machines.

19
Describe LEVER
20
Describe LEVER

• A simple machine made with a rigid bar free to
  pivot (move) around a fixed point called a
  fulcrum

https//www.youtube.com/watch?vUs2KfO_yrPA
21
Describe the 3 types of levers
22
Describe the 3 types of levers

• A first class lever is like a teeter-totter or
  see-saw. One end will lift an object (child) up
  just as far as the other end is pushed down.
• A second class lever is like a wheel barrow. The
  long handles of a wheel barrow are really the
  long arms of a lever.
• A third class lever is like a fishing pole. When
  the pole is given a tug, one end stays still but
  the other end flips in the air catching the fish.

MORE
23
Diagrams of Levers
Effort force input force Load output force
24
Diagrams of Levers
http//www.professorbeaker.com/lever_fact.html
25
Describe PULLEYS
26
Describe PULLEYS

• A simple machine made with a rope, belt or chain
  wrapped around a grooved wheel. A pulley works
  two ways.

27
Diagrams of Pulleys

• Fixed pulley

http//www.smartown.com/sp2000/machines2000/pulley
2.htm
Movable Pulley
http//www.smartown.com/sp2000/machines2000/pulley
3.htm
28
How does a pulley work?
29
How does a pulley work?

• A pulley works two ways.
• It can change the direction of a force or it can
  change the amount of force.

https//www.youtube.com/watch?v9T7tGosXM58
30
What are the types of pulleys?
31
What are the types of pulleys?

• Fixed pulley
• Does not multiply force.
• Changes the direction of the effort force.
• Mechanical advantage is equal to one.
• Movable pulley
• Multiplies effort force but cannot change
  direction of the effort force.
• Mechanical advantage is the effort distance
  divided by the resistance distance.
• Pulley system
• A combination of fixed and movable pulleys.
• Mechanical advantage is equal to the number of
  supporting ropes.

32
How does a fixed pulley work?
33
How does a fixed pulley work?

• A fixed pulley changes the direction of the
  applied force. ( Ex. Raising a flag )

34
How does a moveable pulley work?
35
How does a moveable pulley work?

• A movable pulley is attached to the object that
  is being moved.

36
What is an inclined plane?
37
What is an inclined plane?

• A simple machine with no moving parts. It is
  simply a straight slanted surface. ( Ex. a ramp.)

38
Diagram of Inclined Plane
https//www.youtube.com/watch?vAZbPj0pwl0klistP
Ln5LE-J1SgNGBt3-OeM00YmsLnf7Kv7_t
39
What is a wheel and axle?
40
What is a wheel and axle?

• A wheel and axle is a modification of a pulley. A
  wheel is fixed to a axle.
• The wheel and axle must move together to be a
  simple machine.
• Sometimes the wheel has a crank or handle on it.
• Examples of wheel and axles include roller skates
  and doorknobs.

41
Diagram of Wheel Axle
https//www.youtube.com/watch?vP7xu9O0miEc
42
What is a wedge?
43
What is a wedge?

• A modification of an inclined plane that moves .
• It is made of two inclined planes put together.
• Instead of the load being moved up an inclined
  plane, the inclined plane moves the load.

44
Diagram of Wedge
www.angelfire.com/scifi/dschlott/
simplemachines.html
45
What is a screw?
46
What is a screw?

• A simple machine that is like an inclined plane.
• It is an inclined plane that wraps around a
  shaft.

47
Diagram of Screw
https//www.youtube.com/watch?viHeXFRlo17g
48
Go to this link for more information about
machines. Remember to hit the back button on
your browser to return to this slide show.
