Draeger Marine Chemist Association

1
Draeger Marine Chemist Association
Image H 3.7 in x W 10.8 in (H 9.4 cm x W 27.53
cm)

• Your Safety is Our Passion
• August 4, 2015 Andy Scanlan

2
Draeger Background

• Draeger is over 100 years old based out of
  Lübeck, Germany. The Company was founded by
  Johann Dräger
• The first Draeger invention was The Lubeca Valve
  Known today as the first beer tap.
• Today Draeger has 4 business units
• Medical
• Fixed Systems
• Interlock
• Safety

3
Sensor Technology

• Draeger Makes All of Its Sensors
• Draeger Sensor technology means less long-term
  drift and fewer calibrations 6 Month
  Calibration Schedule
• Inside the sensor temperature compensation
  results in less temperature drift The 3
  Electrode Patent produces and off gas which means
  less likelihood of poisoning and faster recovery
• Patented seamless sensor housing technology
  eliminates electrolyte leakage, even when sensor
  is damaged
• Sensor technology means that the sensors are
  truly smart including complete calibration and
  setup information - Up to 5 Year Warranties
• Draegers patented Three-Electrode Technology
  maximizes response to the gas of concern and
  minimizes the response to other chemicals.

4
Sensor Technology

• When it is all said and done it is the sensors
  that get workers home safely to their families at
  the end of the day!

5
Fastest Reaction Sensors on the Market

• H2S Response Time

6
Overview portable Gas Detection

• Alarms
• 180
• 90 DB
• Vibrating

Software
Messergebnisse speichern und Gasmessgeräte
professionell konfigurieren das alles macht die
maßgeschneiderte Software von Dräger möglich.
IP 67 Rated
5 Year Sensor Warranty O2, H2S, and CO 3 Year
LEL Option to replace one of the above sensors
with SO2 or NO2
Alarm thresholds be raised or lowered
Marine Chemists Andy Scanlan 8/4/2015
7
Overview portable Gas Detection
Software
Messergebnisse speichern und Gasmessgeräte
professionell konfigurieren das alles macht die
maßgeschneiderte Software von Dräger möglich.

• IR Sensor cannot be poisoned and work at 0 O2
• Smallest 6 gas instrument
• 5 Year Warranty
• 43 Different Sensors Available

Marine Chemists Andy Scanlan 8/4/2015
8
Confined Space Entry with Dräger Pump X-am
1/2/5000
Dräger X-am 2500Applications

• Easy Handling
• Easy to connect the pump without tools and screws
• Pump function automatically starts after
  inserting the measuring instrument
• Guided Flow-Test
• The guided flow test before every start up always
  guarantees a fail-safe operation.
• Connecting the sampling hose and filter is very
  easy by Luer-lock quick release fastener
• Fast change from pump-mode to diffusion-mode
• Easy, one hand operation

Dräger X-am 2500 for customer Rüdiger Weich
March 2013
9
Overview portable Gas Detection
Software
Messergebnisse speichern und Gasmessgeräte
professionell konfigurieren das alles macht die
maßgeschneiderte Software von Dräger möglich.

• Pac Single Gas
• PAC 3500 2 Year H2S, O2, and CO
• PAC 500 2 Year Warranty
• PAC 7000 5 Year Warranty
• Variety of Gas such as CL2, HCN, NH3, OV, and
  many more

Alarm thresholds can be raised or lowered
Marine Chemists Andy Scanlan 8/4/2015
10
Overview portable Gas Detection X Dock
Calibration System

• Calibrates/Bumps up 10 instruments at once
• Up to 6 gases or gas mixes
• Single and Multi Gas in 1 unit
• Charging Function
• Stored Data and Unmatched Reporting
• Networkable, Local, or Stand-Alone
• Significant Less Gas Consumption

Software
Messergebnisse speichern und Gasmessgeräte
professionell konfigurieren das alles macht die
maßgeschneiderte Software von Dräger möglich.
Marine Chemists Andy Scanlan 8/4/2015
11
Overview portable Gas Detection X Dock
Calibration System

• Touch Screen
• Dashboard Reporting
• E-mail reporting Events and Intervals
• Automatic Leak Test
• Ability to assign devices and track bump tests,
  alarms, and skills
• Able to download datalogger

Software
Messergebnisse speichern und Gasmessgeräte
professionell konfigurieren das alles macht die
maßgeschneiderte Software von Dräger möglich.
Marine Chemists Andy Scanlan 8/4/2015
12
Overview portable Gas Detection X Zone

• Works in conjunction with Multi-Gas Instruments
• Closed Network for 16 Units 25 in an open
  network
• Bluetooth
• Integrated Pump allows for continuous confined
  space monitoring from up to 150 120 hours
• 360 Gas Entry
• Red and Green Flashing Alarms _at_ 108Db

Software
Messergebnisse speichern und Gasmessgeräte
professionell konfigurieren das alles macht die
maßgeschneiderte Software von Dräger möglich.
Marine Chemists Andy Scanlan 8/4/2015
13
X-AM 7000

• PID for VOCs
• Up to 5 Gases
• 10.6 Volt Lamp

There will be a new product launch in a PID in
late 2016 or early 2017. A special focus will be
paid to the size and benzene and other VOCs. So
the above product will become old technology.
14
Dräger Saver CF (N)The Product
Easy to see orange hood, with elasticated neck
seal
Inner mask to minimise CO2 build up
Natural rubber neck seal
Photo luminescent panels to ensure user can be
seen in dark environments
Automatic Activation on opening
Pictograms on lid
NIOSH, TC, ABS and SOLAS approvals - meaning
Saver can be used on and off shore
5, 10 and 15 min options
Pressure indicator easily viewed and protected in
bag
15
Dräger Saver CF (N) Key Criteria

• Low cost of ownership
• Requires no service or maintenance for the first
  10 years
• Transparent window on case allows cylinder
  pressure gauge to be easily checked without
  unpacking
• Compact Design
• Freedom or movement and storage
• Easily wall mounted, negating the use of wall box
  making emergency use even less intrusive
• Simple Activation
• Opening the carry system instantly activates the
  Saver. It can be easily reset in the event of a
  false alarm
• Easy of use
• Suitable for untrained personnel, including with
  glasses and facial hair

16
PARAT Escape HoodsWhen every second counts
17
Parat NG
Overall protection 16 years of total service
life (provided the filter is exchanged after 8
years.), Hood provides respiratory and eye
protection
Clearly visible hood Hood in signal color for
high visibility
Internal head harness Thanks to the
automatically adjusting internal head harness,
the mask automatically adjusts to any face.
Clear view Wide field of vision due to a
panoramic visor. A special anti-fog coating
maintains clear vision.
High-performance filter Filter expiration date is
clearly marked the filter is automatically
released from the packaging when opened.
Good fit Specially designed half mask fits a
wide variety of face shapes and sizes
Textile neck seal Flexible textile neck seal,
alternatively. Parat 7500 is available with an
elastomeric neck seal for an even higher
protection level
Exhalation valve Directly leads the exhaled air
out of the half mask
18
Breakthrough Times
Gas Concentration Time (minutes) Cyclohexa
ne (C6H12) 2,500 15 Chlorine (Cl2) 2,500
15 Hydrogen sulfide (H2S) 2,500
15 Hydrogen cyanide (HCN) 2,500
15 Sulphur dioxide (SO2) 2,500 15 Ammonia
(NH3) 2,500 15 Hydrogen sulfide (H2S)
10,000 5 Carbon monoxide (CO) 2,500
15 Acrolein (C3H4O) 100 15 Hydrogen
chloride (HCI) 1,000 15
19
What is Important to the Marine Industry

• Draeger is committed to the safety of all
  industries and have developed application
  multiple application driven products that safety
  professionals need!
• How can Draeger help make your job easier?

20
Thank you!

• Questions
