ENM 207

1
ENM 207

• Lecture 7

2
Example

• There are three columns entitled Art (A)
  ,Books (B) and Cinema (C) in a new magazine.
  Reading habits of a randomly selected reader with
  respect to choose columns are

3

• What is the probability of reading A given that
  they are reading B or C columns?

4
(No Transcript)
5
Example Mendenhall 3.63

• solution
• There are five suppliers and a company will
  choose at least 2 suppliers, therefore, we must
  find the number of ways to select 2, 3, 4 and 5
  suppliers from the 5.
• At least 2 means that , a company can choose 2 or
  3 or 4 or 5 suppliers from 5.
• The total number of obtions are

6
Example3.65

• Define the following events
• (A) Part is supplied by company A
• B) Part is supplied by company B
• C) Part is defective
• From the problem, P(A)0.8, P(B)0.2,
• P(C\A) 0.05 , P(C\B) 0.03
• We know the given part is defective and we want
  to find
• The probability it come from company A
• And the probability it come from company B
• P(A\C)? , P(B\C)?

7
(No Transcript)
8
(No Transcript)
9
Total Probability And Bayes Theorem

• Partitions Total Probability And Bayes Theorem
• A partition of the sample space may be defined
  like this.

10
Total Probability Law
11
Bayes Theorem

• Another important result of the total probability
  law is known as Bayes Theorem

12
Ex 2.35 page 56 (Montgomery)
13
(No Transcript)
14
Example

• Three machines A,B,C produce respectively 50,
  30, 20 of the total number of items of a
  factory .
• The percentages of defective output of these
  machines are 3 , 4 , 5,respectively. If an
  item is selected at random, find the probability
  that the item is defective.
• Let X be the event that an item is defective.
• Which theorem or which rule is used to solve this
  problem?
• Total probability law.

15
Another way to solve this problem Tree Diagram
16
Example

• Consider the factory in the preceeding example.
  Suppose an item is selected at random and is
  found to be defective. Find the probability that
  the item was produced by machine A
• What is the P(A\X)?
• Which theorem or which law can be used to solve
  this problem?

17
Ex 4.11 p 62/schaums outline series

• In a certain college, 25 of the students failed
  math, 15 of the students failed chemistry, 10
  of the students failed both math and chemistry.
  A student is selected at random.
• a) If he failed chemistry what is the probability
  that he failed math?
• b) If he failed math, what is the probability
  that he failed chemistry?
• c) What is the probability that he failed math or
  chemistry?

18
SYSTEM RELIABILITY

• System- electronic, mechanical or a combination
  of both are composed of components.
• A component of a system is represented by a
  capital letter.
• Two system each composed of tree components A B
  C are shown below.
• Systems according to their components connections
  can be classified in two groups. Such as series
  and parallel.

19
Definition

• If the system fails when any of the components
  fails, it is called a series system.

• If the system fails only when all of its
  components fail, it is called
• a parallel system.

20
This system is composed of five components A, B,
C, D and E as shown above. Components D and E
are from a two-component parallel system. This
subsystem is connected in series with A, B and
C.
21
(No Transcript)
22
(No Transcript)
23
Summary of system reliability
24
(No Transcript)
25
Example 17.22 First subcircuits involves comp.
A,B,C in parallel.
26
(No Transcript)
27
(No Transcript)
