Broadband Communication Solution

1
Broadband Communication Solution






2
Broadband Solution

• Passive Optical Network (GEPON)
• VDSL (Very-high-data-rate Digital Subscriber
  Line)
• VDSL
• VDSL2
• ADSL (Asymmetric Digital Subscriber Line)
• ADSL
• ADSL2
• ADSL2
• SHDSL (Symmetric High-speed Digital Subscriber
  Line)
• G.SHDSL
• G.SHDSL.bis

3
Product FeaturesPassive Optical Network (GEPON)
4
GEPON Solution
GEPON ONU
GEPON OLT
EPL-2000 2-PON Port GEPON OLT with Uplink 2-Port
1000Base-X SFP Slot
EPN-103 ( 1-PON Interface, 1-Port FE 1-Port
GbE Interface)

• 1.25Gbps for upstream and downstream
• Up to 20km distance
• Up to 64 ONUs split ratio per GEPON port
• PON interface complies with IEEE 802.3ah
• Dynamic Bandwidth Allocation (DBA) support
• 802.1x authentication engine
• 802.1q VLAN and 802.1p QoS support
• Supports IGMP

5
GEPON Application

• FTTH

6
Product FeaturesVDSL Products
7
VDSL2
Profile 30a Downstream/ Upstream 100/100Mbps
VDSL2 CO Switch
VDSL2 IP DSLAM
Power Slot 1
Power Slot 2
CPE
VDSL2 Router
VDSL2 Bridge
8
Features VDL-2420MR

• High-Performance of Ethernet over VDSL2 Solution
• Up to 100/100Mbps symmetric data rate within 300m

• 24 Full-Duplex VDSL links via RJ-21(Telco-50)
  connector
• 2 10/100/1000Mbps TP and SFP shared combo
  interfaces
• Built-in POTS Splitters flexible link option
• 30a profile
• 100240V AC / 48V DC Dual power redundant
  (Optional)
• Delivers High-Demand Services Connectivity for
  ISP / Triple Play Devices
• VOD (Video on Demand)
• Voice over IP
• Video phone
• IPTV
• Distance education

VDL-2420MR
9
VDL-2420MR Application
Speed up to 100/100Mbps
FTTB
Distance up to 1.4Km
FTTH
10
Features VC-230 / VC-230N

• ITU-T G.993.2 VDSL2 Support, up to 100/100 Mbps
  Up/Downstream
• Two RJ-11 connectors, built-in splitter for POTS
  connection
• VDSL2 CO and CPE mode Support
• Bridge and Router Application
• Selectable VDSL2 profiles (Profile 8a, 8b, 8c,
  8d, 12a, 12b, 17a, 30a Support)
• Universal Plug and Play (UPnP)
• DMZ and DDNS
• QoS support
• SPI Firewall support
• VPN Pass through support
• VC-230N Wireless functions
• IEEE 802.11b/g/n compliant
• 2T2R MIMO Technology, data rate up to 300Mbps
• WPS and WMM
• Multiple Operating Mode - AP, WISP, WDS Mode

VC-230
VC-230N
11
VC-230 / VC-230N Application
12
Product FeaturesADSL 2/2 Products
13
ADSL 2/2
IP DSLAM
IDL-4802 (48 ports, IP / Hardware Stacking)
IDL-2402 (24 ports, IP Stacking)
14
Features IP DSLAM
15
Features IP DSLAM
Model Feature IDL-2402 IDL-4802
DLS ports 24 48
Ethernet ports 1 GbE 2 GbE Combo
Max. Speed (Downstream/ Upstream) 25M / 3M 25M / 3M
Max. Distance 5.6km 5.6km
Web Management V V
Hardware Stackable - Up to 4 Units
IP Stacking Up to 4 Units Up to 4 Units
Co-existing with Voice V V
16
Features ADN-4100

• 802.11n Wireless ADSL2 Broadband VPN Router
• IEEE 802.11n 300Mbps wireless network capability
• IPv6 connection supported
• Built-in ADSL 2/2 Modem
• WDS / WPS for easy wireless connection
• 802.1p QoS compatible
• Firewall with NAT and IP/MAC /Application/URL
  filtering
• UPnP and DDNS function
• PPTP and IPSec VPN security tunnel

ADN-4100
16 / 19
17
ADSL 2/2 Application
18
Product FeaturesG. SHDSL
19
Features G.SHDSL Router
Model Feature GRT-101 GRT-401 GRT-402
Standard G.991.2 rev2 (G.SHDSL.bis) G.991.2 rev2 (G.SHDSL.bis) G.991.2 rev2 (G.SHDSL.bis)
DSL Interface 1x RJ-45, 2-wire 1x RJ-45, 2-wire 1x RJ-45, 4-wire
LAN Interface 1 x RJ-45, 10/100M 4 x RJ-45, 10/100M 4 x RJ-45, 10/100M
Max. Data Rate 2.3 Mbps 2.3 Mbps 4.6 Mbps
Max. Distance 6.7 Km 6.7 Km 6.7 Km
20
G.SHDSL Router Application

• Extend network distance over existing telephone
  wires
• High speed symmetrical Internet connections for
  MB and SOHO users

21

• View PLANET Broadband Communication solution
  online

22
(No Transcript)
23
VDSL 2

• Profile 30a

Distance Throughput (Mbps) Throughput (Mbps)
Distance Upstream Downstream
300m 100 100
400m 90 90
600m 55 70
800m 10 50
