Fish Diseases

1
PRINCIPLES OF AQUACULTURE(AKU3201)

• Fish Diseases

2
(No Transcript)
3
(No Transcript)
4
Factors affecting fish health

• Host Environment
• - Stocking density - Poor sanitation
• Handling - Changes in pH, salinity
• - Transport temperature etc.
• Chemotherapy
• Nutrition
• Behaviour
• Disease agent
• Pathogen/ non-pathogen
• Opportunistic pathogen

Disease agent
Disease
Env
Host
5
1) Host susceptibility

• Physical barrier (skin, scales, exoskeleton,
  shell, mucous membranes)

6
Behavioral Signs Failure to feed
properly Flashing (turning on their
sides) Rubbing on the bottom Gathering around the
water inflow Reduced vitality Gasping at the
surface

• Physical Signs
• Blistered areas
• Swollen bellies
• Popped-out eyes
• Bloody (hemorrhaged) areas on fins
• Discoloration or erosion of body parts
• Excessive mucus
• Growths on the body

7

• Physiological defences
• - Immune system, detoxification by liver
• Nutritional well-being
• Age (Young more susceptible)
• Spawners stress due to their reproductive
  functions

8
Sick fish

• Unusual behaviour
• Scrap body to wall
• Coming to surface, gulping for air
• Erratic swim
• Loss appetite
• Physical changes

9
(No Transcript)
10
(No Transcript)
11
Diseases

• Exophthalmia (Pop-eye)

12

• Extended belly

13

• Haemorrhage

14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
2) Environment

• Crucial role in disrupting the balance between
  host pathogen
• Environmental stress gt pathogen host react
• disease occur

19

• Stress
• Anoxia absence of oxygen
• Fright
• Anaesthesia
• Temperature changes
• Injury
• Pollution

20

• High stocking density
• Restricted spaces cages/tanks, raceway
• Large quantity of concentrated feeds/ fertilizer

21
2) Environment

• Do not exceed carrying capacity stocking
  density
• Always monitor water quality
• Maintain proper DO, pH, alkalinity, temperature
• Check accumulation of organic debris, nitrogenous
  waste (ammonia, nitrite), hydrogen sulfide
• Remove pond bottom sludge, dry lime

22

• Temperature changes fluctuation day night
• Poikilothermic
• Hatchery
• Closed system
• If temp. drops, used heater

23
3) Disease agent

• Potential pathogens always present in aquatic
  environment

24
Disease agent

• Parasites (cestodes, nematodes, trematodes
  protozoans)
• Bacteria (vibriosis, edwardsiellosis,
  furunculosis)
• Viruses (IPN, lymphocystis)
• Fungi (saprolegniasis, branchimycosis)

25

• Common entry point
• 1) Wound in skin
• Bacteria/viral infections gt fungal infection
• 2)Gills
• Pathogen enter body through delicate thin
  epithelium
• Protozoa establish themselves on them
• 3) Digestive tract
• Bacteria penetrate intestinal lining
• Protozoa

26
1) Parasites

• Most common cause of fish mortalities
• Especially in larvae fingerling stages
• Multiply rapidly without intermediate host
• Attach themselves to the host special organ
  such as suckers

27

• Penetrate host to multiply invade vital organs
• Invade through ingestion, skin rupture,
  transgression of gill lamellae, penetration to
  the egg membrane

28
Protozoan Ichthyopthirius multifiliis
29
Copepod Argulus, Lernaea
30
Isopod (Sea lice)
31
Monogenean parasites
Dactylogyrus
32
Gyrodactylus
33
Nematode
34
2) Bacterial disease

• Vibriosis
• - Vibrio harveyi

35

• Vibrio anguillarum
• Vibrio alginolyticus

36
Quorum sensing
37
2) Bacterial quorum sensing

• Monitor the environment alter
  behaviour

Quorum sensing (QS)
38
2) Bacterial quorum sensing

• Signal molecules

AHL
(Found in 70 different G- bacterial species)
Diseases controlled by QS
39
(No Transcript)
40

• Aeromonas
• Aeromonas hydrophila
• Aeromonas salmonicida

41
Furunculosis
42

• Edwardsillosis
• Edwardsiella tarda
• Edwardsiella ictaluri

43

• How to identify bacterial isolates

44
Cotton swab
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
Biochemical test
49
Molecular techniques
50
(No Transcript)
51
Serology

• ELISA (Enzyme-linked immunosorbent assay)

Antigen Antibody Enzyme Sensitive method
52
3) Viral disease

• Infectious pancreatic necrosis (IPN)

53
Lymphocystis
54
White spot
55
(No Transcript)
56
4) Fungal disease
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
Case study- Malaysia
62

• Mass mortality June- August

63
Spread of disease between country

• Import- export
• Exotic disease
• Stress during transport
• Fish weak susceptible to disease
• How to overcome
• Discourage/ ban import of live fish
• Quarantine sterilize the fish
• Purchase from reliable source
• Seed free from disease

64
(No Transcript)
65

• Spread of disease in pond/cages
• Through water channel
• Spread pond to pond
• No barrier
• Water current
• Dead fish thrown into open waters
• Other animals as carrier
• Equipments

66
Solution to fish disease

• 1) Integrated health management
• 2) Health inspection disease monitoring
• 3) Disease treatment
• 4) Sanitation
• 5) Immunization
• 6) Genetic resistance to disease
• 7) Farm disinfection

67
1) Integrated health management

• Guidelines for prevention, control eradication
• Correction of disease-causing disease
  spreading conditions
• Adoption implementation of policies
  regulations by the state need cooperative effort

68
2) Health inspection disease monitoring

• Always monitor record health status, water
  quality etc. corrective measures can be taken
• One trained person basic facilities to
  undertake regular health environmental
  monitoring
• - if expensive then twice a year inspection

69
3) Disease treatment

• Chemotherapy temporary, effect on biofiter
• Antibiotic resistant bacteria
• Vaccines specific to certain fish

70
4) Sanitation

• Maintain good sanitation
• Good culture practices
• Monitor water supply ozonation, UV, chlorination
• Egg disinfection

71
(No Transcript)
72

• Quarantine
• particularly to prevent the introduction of
  communicable disease
• - Facilities located away from farm
• Need to disinfect all facilities chlorination

73
5) Immunization

• Mechanism of antibody production
• Antibody specific immunoglobulin (modified
  protein) produced in response to reacts
  specifically with an antigen (foreign substance
  that stimulate the formation of antibodies)
• Vaccines contains antigens that are generally
  attenuated or killed disease agents. When
  administered to a host, they stimulate the
  production of specific antibodies or non-specific
  resistance to that particular disease agent

74

• Vaccination
• Immersion small fish
• Spray-shower fish larger than 4g
• Injection intra-peritoneal
• Retain immunity 300 days

75
6) Genetic resistance to disease

• Disease resistant strains through genetic
  breeding
• Select strains with disease resistant
• High level of genetic diversity hybrid vigour

76
7) Farm disinfection

• Disease outbreak Farmer destroy stock
  disinfect rearing facilities
• Easier fro small, well-controlled facilities
  e.g., hatcheries, tank, raceways.
• Earthern pond difficult

77
Special care during transportation

• During transportation
• Minimize physical injury use smooth net
• Avoid sharp edge tank
• Stop feeding 12-24h to reduce metabolism
  excretion
• Provide high oxygen level
• Salt at 0.3-1 to minimize osmotic stress
• Anesthesia if necessary
• Put bag into Styrofoam box
• Acclimatization- bag left floating for 30 minutes

78

• Quarantine new fish check for pathogen
• Remove dead fish from system
• Dispose dead fish properly
• Good sanitation practices

79
(No Transcript)
80
Ketapang leaves
81
Improve water qualityo
82
Biosecurity

• Biosecurity Steps taken to keep disease from a
  farm to prevent the transmission of disease
  within an infected farm to neighboring farm.
• Consideration on initial facility layout design
• Breeder gt hatchery gt growout (need to ensure
  biosecurity measures)
• Need to have SOP
• Isolation, sanitation control
• Closed system
• Open system?

83
Biosecurity

1. Reduce the risk of disease introductions
2. Minimise the spread of diseases on-farm or to new
   areas
3. Promote fish health
4. Protect economic investment
5. Protect human health

84
Biosecurity

• Avoid the introduction of certain pathogens into
  an aquaculture facilities
• Purchase from a producing selling certified
  specific pathogen-free (SPF) stock
• SPF special stock of animals that are kept in
  specific pathogen free facilities under rigorious
  monitoring system
• Problem Only few spp. of SPF e.g. shrimp
• Shrimp have primitive immune system
• No workable vaccine

85

• d) Tilapia Pangasius no SPF but have vaccine
• e) Vaccinated Pathogen Free seed-stock (VPF)
• VPF Fish vaccinated when they are healthy
  before exposure to the nature
• f) Have own in house broodstock/spawning
  facilities
• g) Have a quarantine/ isolation facilities

86

• 2) Provide a pathogen- free water source
• Mechanical filtration
• Chemical treatment
• UV filtration
• Ozonation
• Well- water
• Biological treatment

87
(No Transcript)
88
Drum-filter filtration of suspend solids in
closed system
89
Protein skimmer remove dissolved organic matter
in water
90

• 3) Disease monitoring
• Always monitor for clinical signs of disease
• Regular scheduled health evaluation
• Sampled for diagnostic health techniques
• Treat if warranted

91

• 4) Disinfection
• Strict adherence to cleaning disinfection
  techniques
• Foot bath hand wash
• Container with disinfectant for nets etc.
• Separate equipments (nets, feed bucket)
• Disinfect vehicles
• E.g disinfectant Hypochlorite
• Maintain good husbandry practices

92
(No Transcript)
93
First chlorine, then thiosulphate to nuetralize
chlorine
94
(No Transcript)
95

• Good aquaculture practices (GAP)
• Improved production, food safety assurance
  preservation of environments
• Hazard Analysis Critical Control Point (HACCP)
• Standard sanitation operating procedures (SSOP)

96
SPLAM

• Malaysian Aquaculture Farm Certification Scheme
• Sijil Pensijilan Ladang Akuakultur Malaysia
  (SPLAM)
• Encourage Good Aquaculture Practice emphasize
  implementation of HACCP
• Aquaculture entrepreneurs need to fulfill
  requirements criteria set by DOF
• Make application, undergo a review audit final
  approval
• Valid for two years

97
Objective SPLAM

• Official recognition to aquaculture entrepreneurs
  who have practiced GAP environmental friendly
  concepts

98
(No Transcript)
