Cosc 4740

• Chapter 3
• Processes

2
What is a Process?
3

• Code Section Sequence of Instructions
• Static Data Section e.g., global variables and
  arrays
• Dynamic Data Section e.g., malloc() or calloc()
  calls
• Stack Section e.g., local variables,
  function/procedure parameters, and return address
• PC (Program Counter) Next instruction

4
Types of a Process

• Either OS process (e.g., system call) or User
  process
• Either I/O bound process or CPU bound process
• I/O bound processes Issue lots of I/O requests
  and little computation
• CPU bound processes Use CPU frequently and I/O
  infrequently

5

• Either Independent process or Cooperating process
• Independent processes
• Does not affect the execution of other processes
• Is not affected by other processes
• Does not share any data with other processes
• Cooperative processes (e.g., producer/consumer
  example)
• Can affect the execution of other processes
• Can be affected by other processes
• Share data with other processes

6

• Either Foreground process or Background process
• Foreground processes
• Hold the terminal.
• Can receive input and return output from/to the
  user
• Background processes
• Detached from the terminal it was started
• Runs without user interaction.
• The sign will allow you to execute a process
  as a background process in UNIX.

7
Problems

• Process scheduling- problem when and which
  process to give the CPU to
• Inter-process communication
• Mutual exclusion If data is shared we might want
  to restrict other processes access. We want to
  avoid interference between two processes
• Process synchronization We may want processes to
  reach a particular point at specific time.
• Deadlock (recognition and resolution) We need to
  know if it happens and resolve the problem (if we
  allow it to happen at all).

8
Process Scheduling

• Remember Multiprocessing and Timesharing
• As a process executes, it changes state
• new The process is being created.
• running Instructions are being executed.
• waiting The process is waiting for some event
  to occur.
• ready The process is waiting to be assigned to
  a process.
• terminated The process has finished execution.

9
Diagram of Process State
10
PCB (Process Control Block)

• Each process is represented by a PCB in the OS.
• Process state
• PID (Process ID)
• PC (Program counter)
• Contents of the processors registers
• Scheduling information
• Memory management information
• List of I/O devices allocated to the process
• List of open files
• etc. (e.g., priority of the process, amount of
  CPU time used, time limits, )

11
CPU Switch From Process to Process
12
Process Scheduling

• Process scheduler selects among available
  processes for next execution on CPU
• Maintains scheduling queues of processes
• Job queue set of all processes in the system
• Ready queue set of all processes residing in
  main memory, ready and waiting to execute
• Device queues set of processes waiting for an
  I/O device
• Waiting queues The list of PCBs. Each PCB
  represents a waiting process who is waiting for
  termination of the child process or reception of
  a signal/message
• Processes migrate among the various queues

13
Process Representation in Linux

• Represented by the C structure task_structpid t
  pid / process identifier / long state /
  state of the process / unsigned int time slice
  / scheduling information / struct task struct
  parent / this processs parent / struct list
  head children / this processs children /
  struct files struct files / list of open files
  / struct mm struct mm / address space of this
  pro /

14
Ready Queue And Various I/O Device Queues
15
Representation of Process Scheduling
16
Schedulers

• Long-term scheduler
• Job pool In multiprogrammed batch system, there
  are often more processes submitted than can be
  executed immediately. These processes are spooled
  to the HDD (secondary storage).
• Long-term scheduler selects processes from the
  job pool and fills the ready queue.
• Executes infrequently? can takes more time to
  select a process
• Mainly used in Batch systems
• Controls the number of processes in memory1
• Select a good mix of I/O bound processes and CPU
  bound processes to maximize both the I/O devices
  and the CPU

17

• Short-term scheduler (CPU scheduler)
• Executes very frequently?must be very fast to
  avoid wasting CPU time.
• Select a process from the ready queue when the
  current process releases the CPU1.
• 1 Some scheduling techniques force the current
  process to release the CPU (i.e., Preemptive
  scheduling)

18

• Medium-term scheduler
• Swap in/out1 partially executed processes to
  temporary frees up the main memory by reducing
  the degree of multiprogramming (i.e., the number
  of processes in the main memory).
• We may need this scheduler to improve the mix of
  I/O bound processes and CPU bound processes in
  the main memory or to react to an increase in
  dynamic memory requests (e.g., malloc()).

19
Medium-term Scheduler
20
Context Switching

• Occurs when the current process releases the CPU
• Procedure
• The current process releases the CPU voluntarily
  or involuntarily
• OS updates the PCB of the current process with
  the current information (e.g., PC, contents of
  CPU registers, etc.)
• Short-term scheduler selects the next process
  from the ready queue
• OS load CPU registers with new data from PCB of
  the next process to be executed
• Start the instruction pointed by the PC

21

• Frequently occurs and expensive ? decrease the
  system performance
• Some solutions
• Multiple sets of registers
• Special HW instruction (e.g., a single
  instruction to load or store all registers)
• Threads whenever possible (e.g., A single process
  includes both producer and consumer Will be
  discussed in later in much more detail)

22
Process Creation

• Parent process create children processes, which,
  in turn create other processes, forming a tree of
  processes.
• Resource sharing
• Parent and children share all resources.
• Children share subset of parents resources.
• Parent and child share no resources.
• Execution
• Parent and children execute concurrently.
• Parent waits until children terminate.

23
Process Creation (Cont.)

• Address space
• Child duplicate of parent.
• Child has a program loaded into it.
• UNIX examples
• fork system call creates new process
• exec system call used after a fork to replace the
  process memory space with a new program.

24
Process Creation (Cont.)

• If you use wait system call, the parent waits
  until some or all of its children have terminated
• If you dont use wait system call, the parent
  continues to execute concurrently with its
  children
• If you use only fork call, the child process is
  a duplicate of the parent process

• If you use fork in the parent and execv in
  the child, the child process will have a program
  loaded into it.

25
C Program Forking Separate Process

• int main()
• pid_t pid
• / fork another process /
• pid fork()
• if (pid lt 0) / error occurred /
• fprintf(stderr, "Fork Failed")
• exit(-1)
• else if (pid 0) / child process /
• execlp("/bin/ls", "ls", NULL)
• else / parent process /
• / parent will wait for the child to complete
  /
• wait (NULL)
• printf ("Child Complete")
• exit(0)

26
A Tree of Processes on Solaris
27
Process Termination

• Process executes last statement and asks the
  operating system to decide it (exit).
• Output data from child to parent (via wait).
• Process resources are deallocated by operating
  system.
• Parent may terminate execution of children
  processes (abort).
• Child has exceeded allocated resources.
• Task assigned to child is no longer required.
• Parent is exiting.
• Operating system does not allow child to continue
  if its parent terminates.
• Cascading termination.

28
Inter-Process Communication (IPC)

• Cooperative processes Why we need them?
• Information sharing
• Computation speedup for multi-processor systems
• Modularity
• Convenience
• OS should provide Cooperative processes with
  communication mechanisms so that they can
  communicate with each other. (At least read-write
  or send-receive)

29

• Example of Cooperative processes
  Producer-Consumer problem
• Unbounded buffer or bounded buffer
• Buffer can be provided by OS (i.e.,
  message-passing) e.g., pipe()
• Buffer can be programmed in the cooperative
  processes (i.e., shared memory).

30
Direct Communication

• Both sender and receiver must name each other.
  (Symmetric addressing)
• Process Q send (P, message)
• Process P receive (Q, message)
• Only the sender names the recipient. (Asymmetric
  addressing)
• Process Q send (P, message)
• Process P receive (id, message)
• Pros provide some degree of protection
• Cons Limited modularity (changing name of P)

31
Indirect Communication

• Messages are sent and received to/from ports (or
  mailboxes)
• Each port has a unique ID
• Process P send (Port ID, message)
• Process Q receive (Port ID, message)
• Mailbox can belongs to OS or programmed in
  cooperative processes

32
Buffering

• Port has Zero capacity
• Synchronization is necessary Sender wait for
  receiver to send a message. When both of them are
  ready (i.e., Rendezvous), the sender can send a
  message.
• Port has Bounded capacity
• N messages can be stored in Port temporary. Note,
  N is the same as the port size.
• Sender does not wait when the port is not full
• When the port is full, sender wait until one
  message in the port is consumed
• Port has Unbounded capacity
• Sender never has to wait for receiver

33
Bounded-Buffer Shared-Memory Solution

• Shared data
• define BUFFER_SIZE 10
• typedef struct
• . . .
• item
• item bufferBUFFER_SIZE
• int in 0
• int out 0
• Solution is correct, but can only use
  BUFFER_SIZE-1 elements

34
Bounded-Buffer Insert() Method

• while (true) / Produce an item /
• while (((in (in 1) BUFFER SIZE count)
  out)
• / do nothing -- no free buffers /
• bufferin item
• in (in 1) BUFFER SIZE

35
Bounded Buffer Remove() Method

• while (true)
• while (in out)
• // do nothing -- nothing to consume
• // remove an item from the buffer
• item bufferout
• out (out 1) BUFFER SIZE
• return item

36
Synchronization

• Message passing may be either blocking or
  non-blocking
• Blocking is considered synchronous
• Blocking send has the sender block until the
  message is received
• Blocking receive has the receiver block until a
  message is available
• Non-blocking is considered asynchronous
• Non-blocking send has the sender send the message
  and continue
• Non-blocking receive has the receiver receive a
  valid message or null

37
Client-Server Communication

• Sockets
• Remote Procedure Calls
• Remote Method Invocation (Java)

38
Sockets

• A socket is defined as an endpoint for
  communication
• Concatenation of IP address and port
• The socket 161.25.19.81625 refers to port 1625
  on host 161.25.19.8
• Communication consists between a pair of sockets

39
Socket Communication
40
Remote Procedure Calls

• Remote procedure call (RPC) abstracts procedure
  calls between processes on networked systems.
• Stubs client-side proxy for the actual
  procedure on the server.
• The client-side stub locates the server and
  marshalls the parameters.
• The server-side stub receives this message,
  unpacks the marshalled parameters, and peforms
  the procedure on the server.

41
Execution of RPC
42
Remote Method Invocation

• Remote Method Invocation (RMI) is a Java
  mechanism similar to RPCs.
• RMI allows a Java program on one machine to
  invoke a method on a remote object.

43
Marshalling Parameters
44
Issues with IPC

• These issues apply to both message passing and
  shared memory schemes
• Sender or receiver has been terminated and the
  other one is waiting for a message from the
  terminated one. Receiver has been terminated and
  the sender sent a message
• Best solution One of the error return value of
  the send/receive function is the sender/receiver
  has been terminated
• So-So OS terminates the other one.
• Worst solution OS does not care about it.

45

• Message was lost
• Best Its OS responsibility
• So-so OS detect it and tells the sender about
  it.
• Worst Its senders responsibility.
• Message was damaged
• Parity check,

46
Q
A
