Heat Transfer : An Action due to Thermal Inequilibrium

1
Heat Transfer An Action due to Thermal
Inequilibrium

• P M V Subbarao
• Professor
• Mechanical Engineering Department

A Natural Happening ..
2
A Wake-up Call to Earth
3
A Natural Engineering Process for the Existence,
Growth and Performance.

• A True Design Reason behind Existence of Natural
  Systems..
• A Strong Design Modification for the Performance
  of Artificial Systems.

4
A True Design Reason behind Geometry of Natural
Systems..
5
An Evolution to Perfection of Heat Transfer is
Sustainable
6
A Reason behind Survival of Electonics
7
What is Heat Transfer?

• Thermal energy is related to the temperature of
  matter.
• For a given material and mass, the higher the
  temperature, the greater its thermal energy.
• Heat transfer is a study of the exchange of
  thermal energy through a body or between bodies
  which occurs when there is a temperature
  difference.
• When system and its surroundings are at different
  temperatures, thermal energy transfers from the
  one with higher temperature to the one with lower
  temperature.
• Thermal Energy always travels from hot to cold.
• This spontaneous act is called Heat Action or
  Heat Transfer.

8
Heat Transfer Between System Surroundings

• Heat transfer is typically given the symbol Q,
  and is expressed in joules (J) in SI units.
• The rate of heat transfer is measured in watts
  (W), equal to joules per second, and is denoted
  by Q.
• The heat flux, or the rate of heat transfer per
  unit area, is measured in watts per area (W/m2),
  and uses q" for the symbol.

9
Heat Transfer in Manufacturing

• The need/role of heat transfer is a two fold
  issue.
• Heat Transfer by design.
• Casting
• Hot working
• Sintering
• Heat Transfer due to unavoidable conditions.
• Machining process.

10
What Causes Heat Transfer in Machining?

• First, almost all (90-100) of the work consumed
  in a machining operation finally convert into the
  thermal energy.
• There are several sources of thermal energy
  in cutting with a sharp tool
• Viscous dissipation transformed into heat if the
  cut material are viscoplastic.
• Work done by friction converted to heat.
• Ambient heat source sometimes need be considered
  if thermal deformation is concerned.
• In non-traditional machining, other types of heat
  sources exist

11
Modes of Heat Mass Transfer

• Conduction or Diffusion
• Radiation
• Convection

12
Conduction Heat Transfer

• Conduction is a significant mode of transfer when
  system and surroundings consist of solids or
  static fluids.
• Two mechanisms explain how heat is transferred by
  conduction lattice vibration and particle
  collision.
• Conduction through solids occurs by a combination
  of the two mechanisms heat is conducted through
  stationery fluids primarily by molecular
  collisions.

13
(No Transcript)
14
(No Transcript)
15
Fourier law of heat conduction
A Constitutive Relation

• The rate of heat transfer through the wall
  increases when
• The temperatures difference between the left and
  right surfaces increase,
• The wall surface area increases,
• The wall thickness reduces,
• The wall is changed from brick to aluminum.
• If we measure temperatures of the wall from left
  to right and plot the temperature variation with
  the wall thickness, we get

This is called as Fourier Law of Conduction
16
Circumstances Leading to Heat Conduction
17
Circumstances Leading to Heat Conduction in
Machinging
18
Thermal Image of Laptop Casing
19
Graphite Covering
20
Thermal Image of Laptop Casing with Graphite cover
21
Statement of Fouriers Law
The (mod of) heat flux, q, (the flow of heat
per unit area and per unit time), at a point in
a medium is directly proportional to the
temperature gradient at the point.
Temperature gradient across the slab of thickness
Dx
T
The heat flux across the slab
x
22
Local Heat flux in a slab
Global heat transfer rate
23
Mathematical Description

• Temperature is a scalar quantity.
• Heat flux is defined with direction and Magnitude
  A Vector.
• Mathematically it is possible to have

Using the principles of vector calculus
