Title: Threads, SMP, and Microkernels


1
Threads, SMP, and Microkernels
  • Chapter 4

2
(No Transcript)
3
Multithreading
  • Operating system supports multiple threads of
    execution within a single process
  • MS-DOS supports a single thread
  • UNIX supports multiple user processes but only
    supports one thread per process
  • Windows, Solaris, Linux, Mach, and OS/2 support
    multiple threads

4
(No Transcript)
5
Process
  • Resource ownership - process includes a virtual
    address space to hold the process image and
    access to I/O
  • Scheduling/execution- follows an execution path
    that may be interleaved with other processes
  • These two characteristics are treated
    independently by the operating system

6
Process
  • Dispatching is referred to as a thread or
    lightweight process
  • Resource of ownership is referred to as a process
    or task

7
Thread
  • An execution state (running, ready, etc.)
  • Saved thread context when not running
  • Has an execution stack
  • Some per-thread static storage for local
    variables
  • Access to the memory and resources of its process
  • all threads of a process share this

8
User-Level Threads
9
User-Level Threads
  • All thread management is done by the application
  • The kernel is not aware of the existence of
    threads
  • I/O requests causes the whole process to be
    blocked.

10
Kernel-Level Threads
11
Kernel-Level Threads
  • Windows is an example of this approach
  • Kernel maintains context information for the
    process and the threads
  • Scheduling is done on a thread basis
  • I/O requests only cause the affect thread to be
    blocked.

12
VAX Running UNIX-Like Operating System
13
Combined Approaches
14
Combined Approaches
  • Example is Solaris
  • Thread creation done in the user space and kernel
    space
  • Bulk of scheduling and synchronization of threads
    within application in both kernel and user space
  • Communication between threads can be done in
    kernel or user space.

15
Benefits of Threads
  • Takes less time to create a new thread than a
    process
  • Less time to terminate a thread than a process
  • Less time to switch between two threads within
    the same process
  • Since threads within the same process share
    memory and files, they can communicate with each
    other without invoking the kernel

16
Uses of Threads in a Single-User Multiprocessing
System
  • Foreground to background work Managing
    different processes with different levels of
    priority.
  • Asynchronous processing Threads that can
    execute without care of what the other threads
    are doing.
  • Speed of execution Faster to swap out threads
    than processes.

17
Threads - Review
  • Suspending a process involves suspending all
    threads of the process since all threads share
    the same address space
  • Termination of a process, terminates all threads
    within the process

18
Thread States
  • States associated with a change in thread state
  • Spawn
  • Spawn another thread
  • Block/Unblock
  • Ready/Running
  • Finish
  • Deallocate register context and stacks

19
(No Transcript)
20
Processor Architectures
21
Categories of Computer Systems
  • Single Instruction Single Data (SISD) stream
  • Single processor executes a single instruction
    stream to operate on data stored in a single
    memory
  • Single Instruction Multiple Data (SIMD) stream
  • Each instruction is executed on a different set
    of data by the different processors

22
Categories of Computer Systems
  • Multiple Instruction Single Data (MISD) stream
  • A sequence of data is transmitted to a set of
    processors, each of which executes a different
    instruction sequence. Never implemented
  • Multiple Instruction Multiple Data (MIMD)
  • A set of processors simultaneously execute
    different instruction sequences on different data
    sets

23
(No Transcript)
24
Symmetric Multiprocessing(MIMD)
  • Kernel can execute on any processor
  • Typically each processor does self-scheduling
    form the pool of available process or threads

25
(No Transcript)
26
Symmetric Multiprocessing(MIMD)
  • What new issues might we have to deal with?
  • Having to worry about proper sharing of Memory
  • Two processes executing the same code either on
    purpose or by accident
  • The Kernel can be running on multiple processors
    at the same time.

27
Multiprocessor Operating System Design
Considerations
  • Simultaneous concurrent processes or threads
  • Scheduling
  • Synchronization
  • Memory management
  • Reliability and fault tolerance

28
Microkernels
29
Microkernels
  • Small operating system core
  • Contains only essential core operating systems
    functions
  • Many services traditionally included in the
    operating system are now external subsystems
  • Device drivers
  • File systems
  • Virtual memory manager
  • Windowing system
  • Security services

30
(No Transcript)
31
Benefits of a Microkernel Organization
  • Uniform interface on request made by a process
  • Dont distinguish between kernel-level and
    user-level services (Where are all the services?)
  • All services are provided by means of message
    passing
  • Extensibility
  • Allows the addition of new services
  • Flexibility
  • New features added
  • Existing features can be subtracted

32
Benefits of a Microkernel Organization
  • Portability
  • Changes needed to port the system to a new
    processor is changed in the microkernel - not in
    the other services
  • Reliability
  • Modular design
  • Small microkernel can be rigorously tested

33
Benefits of Microkernel Organization
  • Distributed system support
  • Message are sent without knowing what the target
    machine is
  • Object-oriented operating system
  • Components are objects with clearly defined
    interfaces that can be interconnected to form
    software

34
Microkernel Design
  • Low-level memory management
  • Mapping each virtual page to a physical page
    frame (Kernel)
  • Memory protection and allocation (User-Level)

35
Microkernel
  • Supporting External Paging and Virtual Memory
    Management
  • Grant A User-Level process can grant/assign
    memory to another process.
  • Map Placing one or more pages of memory in
    overlapping space.
  • Flush The granter process can reclaim any
    memory.

36
Microkernel Design
  • Interprocess communication
  • Uses messages that contains a header and a body.
  • I/O and interrupt management
  • Interrupts recognized by the kernel, but handed
    off to a user-level process.

37
Closer Look at Windows and Solaris
38
Windows Processes
  • Implemented as objects
  • An executable process may contain one or more
    threads
  • Both processes and thread objects have built-in
    synchronization capabilities
  • Threads and Processes run in kernel mode

39
(No Transcript)
40
Solaris
  • User-level and Kernel-level Threads
  • Process includes the users address space, stack,
    and process control block
  • Accessible by the Kernel Threads
  • Lightweight processes (LWP)
  • Shadow of the Process that allows the User-Level
    threads to function without making direct calls
    to the Kernel threads.

41
(No Transcript)
42
Windows 2000Thread States
43
(No Transcript)
44
End
45
Remote Procedure Call Using Single Thread
46
Remote Procedure Call Using Threads
47
Multithreading
48
Adobe PageMaker
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
Closer Look at Solaris
53
Solaris Lightweight Data Structure
  • Identifier
  • Priority
  • Signal mask
  • Saved values of user-level registers
  • Kernel stack
  • Resource usage and profiling data
  • Pointer to the corresponding kernel thread
  • Pointer to the process structure

54
(No Transcript)
55
Linux Task Data Structure
  • State
  • Scheduling information
  • Identifiers
  • Interprocess communication
  • Links
  • Times and timers
  • File system
  • Address space
  • Processor-specific context

56
(No Transcript)
57
Linux States of a Process
  • Running
  • Interruptable
  • Uninterruptable
  • Stopped
  • Zombie
