Flood Routing

1
Flood Routing Detention Basin Design

• Professor Ke-Sheng Cheng
• Dept. of Bioenvironmental Systems Engineering
• National Taiwan University

2
The storage effect

• The storage effect of a water-retention structure
  or a channel reach can change the shape of the
  inflow hydrograph. Therefore two types of routing
  procedures are needed to calculate the outflow
  hydrograph.
• Level-pool routing
• Channel routing

3
Level-Pool Routing (Reservoir Routing)

• For a reservoir the outflow is uniquely
  controlled by the water depth (or stage) of the
  reservoir pool. Also, the reservoir storage is a
  single-value function of the stage.

Flow velocity in the reservoir is usually very
low.
4
Comparison of flow routing under invariable and
variable stage-discharge relationships
Invariable SQ relationship
Variable SQ relationship
5
Discharge under variable SQ relationship
6
Reservoir routing

• Modified puls method (Storage indication method)

7
(No Transcript)
8
(No Transcript)
9
An example

• Given the following storage-outflow relationship
  and inflow hydrograph, calculate the outflow
  hydrograph. (Use 10-minute routing interval).

10
Stagestorageoutflow relationship
11
(No Transcript)
12
Reservoir routing as a computation of mass balance

• For a reservoir the outflow is uniquely
  controlled by the water depth (or stage) of the
  reservoir pool. Also, the reservoir storage is a
  single-value function of the stage.
• As a result, given a stage the reservoir storage
  and outflow can be uniquely determined, if the
  stagestorage and stageoutflow relationships are
  known.
• An intuitive trial-and-error approach for
  reservoir routing can be implemented.

13
Alternative solution
Stagestorage
Stagedischarge
14
Spreadsheet calculation
15
Inflow-outflow-(10storage)
16
Channel routing
