Bubble of Protection Complete System Protection

1
Bubble of ProtectionComplete System Protection

• ITW Linx
• A Division of Illinois Tool Works Inc.

2
Overview

• Why Use Surge Protection?
• Types of Surges
• Technologies
• Standards
• The Bubble of Protection
• Bonding and Grounding
• Example

3
Why Use Surge Protection?

• Safety
• Protect people from electric shock
• Protect equipment from damage
• Protect building wiring from excessive electrical
  current

4
Why Use Surge Protection?

• Safety
• National Electric Code
• National Fire Protection Association
• Telecom equipment under Article 800
• Primary Protection at Building Entrance
• Secondary protection

5
Why Use Surge Protection?

• Safety
• National Electric Code
• Savings
• Blown Equipment
• Service Calls
• Downtime
• Initial Investment with Net Savings

6
Why Use Surge Protection?

• Safety
• National Electric Code
• Savings
• Damaged Equipments Equals.Headaches
• Lost Equipment
• Service Repairs
• System/Business Downtime
• Dissatisfied Customers
• Finger Pointing (Installer, Manufacturer, etc.)

7
Why Use Surge Protection?

• Safety
• National Electric Code
• Savings
• Damaged Equipments Equals.Headaches
• Whos Concerned?
• Telephone and Power Companies
• Facility, Operations, and Telecom Managers
• Architects, Installers, Contractors, Technicians
• Everyone!

8
Types of Surges

• Lightning
• Most catastrophic of all surges
• Does not have to be a direct hit to cause damage
• A lightning strike within a few miles can be
  induced into aerial or buried cables
• 10,000,000 Volts
• 145,000 Amps (145kA)

9
Global Lightning Flashes 2000
10
Lightning in the U.S. 1989-1998
11
Types of Surges

• Lightning
• Power Line Cross
• Excess current on the Communications line
• High Risk of Fire
• Injury to personnel
• Damage to equipment

12
Types of Surges

• Lightning
• Power Line Crosses
• Induction
• Current flow creates a magnetic field
• Two conductors run parallel and close to one
  another
• Field of one conductor can transfer energy to the
  other conductor
• Example Power is first restored following a
  blackout

Field
Current
13
Types of Surges

• Lightning
• Power Line Crosses
• Induction
• Electrostatic Discharge
• Transfer of electrical energy from one material
  to another
• Usually found in dry climates
• Produces high voltage with low current
• Feel sensation at 4kv
• Maximum Voltage 30kV
• Enough energy to damage integrated circuits
  (35V)

14
Shock Thresholds
1mA Perception Threshold
3mA Mild Shock
8mA Severe Shock (involuntary muscle movement)
10mA Freezing Threshold (cant let go)
35mA Respiratory Paralysis
65mA Heart Filtration (no blood flow)
15
Technologies

• Voltage Limiting
• Gas Tube
• Discharge gap between two metal electrodes
• Poor control of peak voltage
• Clamping voltages are too high
• Discharge times are too slow
• Deposits build on the discharge plates with each
  activating surge
• OK for electromagnetic switches, but not for
  todays electronics

16
Technologies

• Voltage Limiting
• Gas Tube
• Solid State
• Provides fast, precise, and long lasting
  protection
• Premium alternative to gas tube protectors
• Fast clamping at low voltages
• Performance can significantly reduce failure
  rates for both protector units and surge
  sensitive equipment
• Improved reliability makes it ideal for critical
  service lines

17
Speed of a Surge
How Fast Does Electricity Travel Through A Wire? 186,000 Miles/Second
Number of Feet in a Mile? 5,280 Feet / Mile
Speed (in ft/sec) Electricity Travels Through a Wire 1,000,000,000 ft/sec
Time Required for Surge to Travel One Ft. 0.0000000001 Sec. (1 Nanosecond)
18
Speed of a Surge
Device Response Time Distance Surge Traveled Past Device Before It Responded
Fuse 300,000 ns 300,000 ft
Carbon Block 5,000-10,000 ns 5,000 - 10,000 ft
Carbon Block 5,000-10,000 ns or 1-2 miles.
Gas Tube 4,000-5,000 ns 4,000 - 5,000 ft
Gas Tube 4,000-5,000 ns Or 1 mile.
Solid-State 2 - 5 ns 2 - 5 ft
19
Technologies

• Voltage Limiting
• Gas Tube
• Solid State
• Current Limiting
• Sneak Current Protector Fuses
• Prevents the current that passes by the primary
  protector undetected from burning down building

20
Technologies

• Voltage Limiting
• Gas Tube
• Solid State
• Current Limiting
• Sneak Current Protector Fuses
• PTCs
• Positive Temperature Coefficient (PTC)
• Automatically reset once the over current is
  removed
• Service calls/costs are dramatically reduced
• Cost of replacement fuses eliminated

21
Standards

• National Electric Code (NEC)
• National Fire Protection Agency for Safety
• Article 800 - Telecommunications
• All conductive paths entering or leaving a
  building shall be protected by a listed primary
  protector as soon as possible, but no more than
  50 feet past the building entrance

22
Standards

• National Electric Code (NEC)
• Underwriters Laboratory (UL)
• Products listed
• Do not start on fire or cause a fire to be
  started, and
• Do not cause a physical safety hazard to the use

23
Standards

• National Electric Code (NEC)
• Underwriters Laboratory (UL)
• UL497 - Primary
• Designed to protect against Lightning and Power
  Crosses
• 100 Amp, 10/1000
• 600V, 350A
• Three Exceptions
• Large metropolitan area
• Less than 140ft
• lt5 Thunderstorm days per year

24
Standards

• National Electric Code (NEC)
• Underwriters Laboratory (UL)
• UL497 Primary
• UL497A Secondary
• Installed in series between the primary protector
  and the equipment
• Must safely limit over currents

25
Standards

• National Electric Code (NEC)
• Underwriters Laboratory (UL)
• UL497 Primary
• UL497A Secondary
• UL497B Isolated Loop (Fire Alarm or Data
  Circuit)
• For lines that are contained within a building
  and not connected to the public network outside
  the building
• These devices protect against transients usually
  caused by electrostatic discharge and electrical
  shock
• NOT INTENDED FOR LIGHTNING PROTECTION

26
Standards

• National Electric Code (NEC)
• Underwriters Laboratory (UL)
• UL497 - Primary
• UL497A Secondary
• UL497B Isolated Loop (Fire Alarm or Data
  Circuit)
• UL1449 Transient Voltage Surge Suppressor
• AC Power listing at 330V
• For electrical safety, NOT equipment safety

27
Risk Assessment

• Where is the facility (Lightning potential)?
• What is the Power Quality?
• Outside Extensions?
• What is the Ground Quality?
• How Critical is the System?
• What Will It Cost to Replace the System?

28
Typical Install
PBX
Primary Protection Telco Demarcation
Secondary
Primary
Primary
29
Bubble of Protection

• Backwards Approach
• Three potential conductive paths
• 1) AC Power
• 2) Communications Lines (Telecom)
• 3) Ground System

30
Bubble of Protection
31
Final Layout
32
Bonding Grounding

• Grounding Establish 0V Reference
• Bonding Maintaining 0V Reference
• Two Point Resistance lt 0.1?
• Direct attachment to the closest point in the
  buildings electrical service grounding electrode
  system is preferred
• 90 of problems are due to improper grounding
• Good grounds
• Structural Steel
• Electrical Service Panel

33
Bonding Grounding

• Ground Impedance lt 1O
• Tightness of Connections (Check Annually)
• Length (Short as Possible)
• Number of Bends (Straight as Possible)
• Bend Radius (Generous)
• Size/Gauge

34
Bonding Grounding

• Ground Impedance (Earth Gnd) lt 1.0 ohms
• Single Point Ground
• Racks
• Cable Trays
• Raised Floor
• Conduits
• Structural Steel
• Equipment
• Cold Water Pipe
• AC Panel

35
Bonding Grounding

• Ground Impedance (Earth Gnd) lt 1.0 ohms
• Single Point Ground
• Protect or Ground Unused Pairs

36
Bonding Grounding

• Ground Impedance (Earth Gnd) lt 1.0 ohms
• Single Point Ground
• Protect or Ground Unused Pairs
• Use proper gauge wire (AWG)
• Receptacle ground for small systems
• TMGB for large systems

37
Ground Size
Primary
Pairs Fuseless Fused
1-2 12 14
3-6 10 14
7-25 6 6

• Secondary
• Not specified by UL or NEC
• Check Manufacturers Specifications
• Depends on size of system and current carry
  capacity

38
Example Airport Installation
The damaged phone switch
39
Example Airport Installation
A Good Single Point Ground But
40
Example Airport Installation
In Another Room, the Ground Wire ITS NOT
CONNECTED TO ANYTHING!
41
Dont let this happen to your system
42
Questions?

• Contact ITW Linx
• 800-336-5493
• www.itwlinx.com
