Evolution Part 1

1
Evolution Part 1

• The Evidence

2
Evolution Outline

• I. What is evolution?
• II. Evidence of Evolution
• A. Evidence from the past (Fossils)
• B. Evidence from living organisms
• -Comparative anatomy
• -Comparative embryology
• -Comparative biochemistry
• III. Early Hypotheses Origin of Life
• A. Spontaneous generation
• B. Atmosphere of early earth Stanley Miller
  experiment
• C. Heterotroph hypothesis

3
Evolution Outline (Cont)

• IV. Theories of Evolution
• A. Early Theories
• 1. Lamarck Theory of acquired traits
• Use and disuse
• 2. Darwin and WallaceTheory of evolution by
  natural selection
• B. Synthetic (Modern) Theory of Evolution
• 1. Population Genetics
• 2. Genes, Variation and Evolution
• 3. Hardy-Weinberg Law and Genetic Equilibrium
• V. Adaptations and Natural Selection
• A. Structural Adaptations
• B. Behavioral Adaptations

4
Evolution Outline (Cont)

• VI. Types of Natural Selection
• A. Directional Selection
• B. Stabilizing Selection
• C. Disruptive Selection
• VII. Speciation and Adaptive Radiation
• A. Geographic and reproductive isolation
• B. Convergent evolution
• C. Coevolution
• VIII. Classification and Evolutionary Histories
• A. Phylogenetic trees
• B. Taxonomy

5
What is evolution?

• Evolution is the central and unifying theme in
  biology.
• Nothing in biology makes sense unless cast in
  the light of evolution Theodozius Dobzhonski
• Evolution is the gradual change in a population
  of organisms over time.
• Geologic evolution Refers to the gradual changes
  in the Earth over the last 4.5 billion years
• Organic evolution refers to the changes in life
  forms as they adapt to their changing
  environments.

6
Is evolution real?

• There is no doubt that evolution has occurred, is
  occurring, and will continue to occur as
  organisms constantly adapt to changing
  environments.
• Convincing evidence comes from the fossil record.
• Fossil any trace or remains of an organism that
  has been preserved by natural processes.

7
Transitional Fossils Evidence of Evolution Part
1

• Archeaopteryx
• Had teeth and a long tail like a dinosaur, but
  feathers like a bird.
• This fossils demonstrates how birds are modern
  descendents of dinosaours.

8
Transitional Fossils

• Tiktaalik 375 million year old fish whose fins
  appear to be limbs in the making
• The figure below shows bones in the fins that are
  homologous to bones that make up the fingers,
  wrists, and elbows of terrestrial (land dwelling)
  vertebrates.

9
Transitional fossils

• Evolving from life in the sea to life on land
  required some major limb adjustments
• Tiktaalik is a long awaited piece of the puzzle
  of how life transitioned from sea to land

10
Sealing up gaps in the fossil record.

• Opponents of evolution often point to a lack of
  evidence or gaps in the fossil record to
  justify their position.
• but rarely change their positions when
  confronted with the real evidence.

11
But surely this evolution stuff doesnt apply to
humans.
12
Question to Ponder

• Why arent there more, lots more, transitional
  fossils out there? Most fossils are of organisms
  in their complete state.

13
Evidence for Evolution Part 2 Comparative Anatomy

• What traits would you use to classify
• -Birds
• -Mammals
• -Reptiles
• -Fish

• Feathers, lay eggs
• Fur, milk, live young
• Scales, cold-blooded, lay eggs
• Scales, gills, fins

14
Comparative Anatomy Homologous Structures

• Homologous Structures are characteristics which
  are shared by related species because they have
  been inherited in some way from a common
  ancestor.
• For example, although the arms of four-limbed
  vertebrates externally appear quite different,
  all have the same basic underlying skeletal and
  muscular pattern. Such shared patterns are best
  explained by the inference that they were
  inherited from a common ancestor that also had
  this pattern.

15
Homologous Structures and Wing Development

• The wings of flies, moths and butterflies, and
  beetles are homologous structure derived from a
  four winged common ancestor.

16
There is also homology in gene expression

• Similarities in gene expression between mammals
  and insects demonstrate the common ancestry of
  ALL animals.

17
Comparative Anatomy Analogous Structures

• Insect wings and bird wings are considered
  Analogous Structures.
• Insect wings and bird wings have evolved
  independently of each other.
• They illustrate two different evolutionary
  pathways to the same result wings.
• This is called convergent evolution
• Analogous structures do not demonstrate common
  ancestry between organisms.

• Would you say that a butterfly is more closely
  related to a bird or an ant?
• But birds and butterflies both have wings.
• True, but the underlying structure of those wings
  are completely different.

18
Analogous Structures

• Here we can see why vertebrate forelimbs are
  considered HOMOLOGOUS reflecting the common
  ancestry of all vertebrates.
• And why the wings of insects and birds are
  considered ANALOGOUS reflecting the convergent
  evolution of bird and insect wings.

19
Comparative AnatomyVestigial Organs

• Some of the most compelling evidence supporting
  evolution comes from vestigial organs.
• Vestigial organs Structures that were functional
  in early ancestors, but are now useless in
  present day organisms.
• Ex. Hind-limb bones in whales and snakes, human
  appendix and nictitating membranes

• Why does this early whale fossil have
  non-functional leg bones?
• They were used by a land dwelling ancestor
  similar to modern hippos

20
Vestigial leg bones found in snake fossil

• This fossil demonstrates the evolution of snakes
  from lizards.
• The loss of limbs enables snakes to exploit new
  areas in search of prey, that would not be
  accessible to lizards.
• The only sensible explanation as to why a snake
  fossil would have functionless leg bones is an
  evolutionary explanation

21
Vestigial Eyes in Cave Dwelling Salamanders

• Grotto salamander
• Typhlotriton spelaeus

• This lizard lives in caves with absolutely no
  light.
• Rather than invest precious resources for
  unnecessary eye development, these blind
  creatures have functionless bulbs of tissue
  rather than eyes.

22
Evidence for Evolution Part 3 Comparative
Embryology

• Comparative embryology Refers to the
  similarities and differences between organisms
  during embryological development.
• Vertebrate embryos develop in very similar ways.

23
Evidence for Evolution Part 4 Biochemical
Similarities
24
Comparative Biochemistry

• Just as DNA can be used to demonstrate paternity,
  it can also be used to demonstrate common
  ancestry between species.

25
We dont just look like other primates, we share
most of our DNA with them too!
26
Evidence for Evolution Part 6 Artificial
Selection

• Artificial Selection and Selective breeding has
  enabled humans to develop a variety of dog,
  horse, livestock, and agricultural breeds.
• Darwin argues that humans are simply playing the
  part of the environment in the selection of
  desired traits.

• All of these vegetables come from the same
  mustard plant!

27
Artificial selection in dogs

• All dog breeds (Canis familiaris) are derived
  from domesticated dogs very similar to wolves.
• Artificial selection gives us tremendous
  diversity within the species.
