Forces and Motion

1
Forces and Motion
5.1 Use measurement time-distance graphs to
represent the motion of an object in terms of its
position, direction or speed.
2
(No Transcript)
3
Motion

• Motion is a change in position of an object with
  respect to time.
• The following terms are used to describe and
  measure motion.
• Position
• Direction
• Speed

4
Position

• Position the location of an object. Change in
  position is measured by distance (length of the
  path) moved from one position (reference point)
  to another.
• What is a reference point?
• Class demonstration One volunteer and the rest
  of the class is split into two groups. This
  activity will illustrate the idea of a reference
  point.

5
Reference Point is a place or object used for
comparison to determine if something is in
motion. An object is in motion if it changes
position relative to a reference point.
6
Direction

• Direction is the relationship of the position
  of a moving object to another position.

7
Speed

• Speed is the rate of change in position or
  rate of motion. How long it takes to move from
  point A to B.
• Speed does not necessarily mean that something
  is moving fast.

8
Average Speed

• The average speed of an object tells you the
  (average) time at which it covers a given
  distance.
• Average speed is the result of the total distance
  divided by the total time taken.

9
Calculating Average Speed(v d/t)

• v d/t where
• v is the average speed of an object
• d is the distance or length of the path of the
  object
• t is the time taken to cover the path
• Speed is measured using the following types of
  units
• meters per second (m/s)
• kilometers per hour (km/h)
• miles per hour (mph)

10
What is the difference between speed and velocity?
Velocity is speed with direction
11
Vd/t
td/v
dvt
d
v
t
12
TO HELP SOLVE EQUATIONS, HERE IS A STEP BY STEP
GUIDE TO FOLLOW. G U E S S
G find your Givens U what is your Unknown
(trying to find) E what is the Equation you
need? S Substitute your givens S - Solve
13
Examples

• Calculate the speed of an object using the
  following information
• t 35 s and d 50m
• Step 1 GUESS
• Givens are t 35 s and d 50 m
• Unknown v
• Equation v d / t
• Substitute v 50 / 35
• Solve v 50 divided by 35

14
Examples

• Suppose a cyclist travels 32 kilometers during
  the first two hours of riding, and 13 kilometers
  during the next hour. Calculate the average
  speed
• -total distance 32km 13km
• -total time 2h 1h
• Average speed 45km/3h 15km/h or
• 15 kilometers per hour

15
Examples

• Use the speed equation to determine how far an
  object traveled.
• v7m/s
• t3s
• How far did the object travel?
• Rearrange vd/t
• dvt
• d7m/s(3s)
• d21m

16

• How long will it take to get to Atlanta, GA for a
  Falcons game from Greenville, SC (145 miles or
  233 km). You know you can travel about 70 mph?
• 2. If a bamboo plant grows 28 centimeters in 11
  days, what was the average speed the plant grew
  per day?
• 3. A soccer player was practicing on the soccer
  field last week. He ran back and forth on the
  field for a total of 750 yards. His average speed
  was 12 yards per second. How long did it take him
  to finish?

17
Graphing Speed

• Do you think it is possible to represent speed
  using a graph?
• If so, what type of graph would you use?
• Line graph, bar graph, circle graph????

18

• When graphing speed you would use a line graph.
• A line graph shows the relationship between
  distance and time and how it relates to speed.
• The slope of the line gives us information about
  the speed and direction of an object.

19

• You graph speed by taking measurements of time
  and distance.
• For instance The following measurements were
  taken on how fast a turtle walks along a path.

Time (h) Distance (m)
0 0
1 5
2 10
3 15
4 15
5 15
6 10
7 5
20
(No Transcript)
21
B
C
A
At position A, is the object moving away from or
towards the reference point? At position C, is
the object moving away from or towards the
reference point?
22
The flatter the slope, the slower the speed.
The steeper the slope, the faster the speed.
23
When the slope of the line is horizontal to the
x-axis, the speed is zero (the object is not
moving)
24
Examples

• Lets graph the motion of a drag racer.

Time (s) Distance (m)
0 0
5 20
10 40
15 60
20 80
30 100
40 120
Have to allow for a 25 and 35 on your X axis!
25
First, we need to label the data x and y.
X axis
Y axis
Time (s) Distance (m)
0 0
5 20
10 40
15 60
20 80
30 100
40 120
26
Next, draw and label the graph.
27
Now, you need to plot the points.
Time (s) Distance (m)
0 0
5 20
10 40
15 60
20 80
30 100
40 120
28
Practice Problem

• Graph the speed of an object as it travels down
  hill.

Time (s) Distance (m)
0 0
1 2
2 5
3 9
4 15
5 20
Time (s) Distance (m)
0 0
1 10
2 8
3 5
4 3
5 1
Graph the speed of an object as it travels up
hill.
