Prezentace aplikace PowerPoint

1
Project Management
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
2
Project Management

• Project

Activity 5
Activity 2
Activity 1
Activity 7
Activity 3
Activity 4
Activity 6
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
3
Project Management
NETWORK graphical representation of the project
Activity ? Node
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
4
Project Management
NETWORK graphical representation of the project
Activity ? Arc
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
5
Project Management

• Event

Activity ADesign a car
Activity BMake a prototype
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
6
Project Management
Activity A immediately PRECEDES activity B
Activity B immediately SUCCEEDS activity A
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
7
Project Management
Activity A is the predecessor of Activity B and C
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
8
Project Management
Activity E (Prototype test) follows Activity B
Activity D (Prototype presentation) follows
Activity B and C
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
9
Project Management
Activity Requirements
- time
- money (cost)
- material
- machines
- people
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
10
Project Management
Phases of Project Management
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
11
Project Management
Methods
Deterministic time
Probabilistic time
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
12
Project Management
CPM
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
13
Project Management
CPM

• Finish time of the project

• Start and finish times of each activity

• A critical path consisting of critical activities

• Non-critical activities and their possible delay

_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
14
Project Management
CPM
Example - Music DM, Inc.

• Christmas compilation of Czech carols

• 11 activities

1) Songs Selection
2) Mastering
3) Promotion Material Elaborating
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
15
Project Management
CPM
Example - Music DM, Inc.

• 11 activities

4) Customers Analysis
5) Promotion Material Production
6) Make CD Copies
7) Customers Selection
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
16
Project Management
CPM
Example - Music DM, Inc.

• 11 activities

8) Data to Printing House
9) Promotion Material to Printing House
10) Laser Print
11) Mailing
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
17
Project Management
CPM
Example - Music DM, Inc.
Activity Description Duration Predecessors
A Songs Selection 15 None
B Mastering 8 A
C Promotion Material Elaborating 6 A
D Customers Analysis 7 A
E Promotion Material Production 4 C, D
F Promotion Material to PH 5 E
G Customers Selection 3 D
_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
18
Project Management
CPM
Example - Music DM, Inc.
Activity Description Duration Predecessors
H Make CD Copies 12 B, D
I Data to PH 3 G
J Laser Print 9 F, I
K Mailing 8 H, J

• All the envelopes have to be delivered until
  December 12

• Objective set the starting date of the project

_______________________________________________
____________________________ Quantitative
Methods of Management ? Jan Fábry
