A View of the Cell: Cell Structure

1
A View of the CellCell Structure
2
Microscopy

• the use of microscopes to study cells
• Different types of microscopes
• Light microscope
• Transmission electron microscope
• Scanning electron microscope

3
Compound light microscopes

• With light as its energy source, it uses a series
  of lenses to magnify up to 1500X

4
Electron microscope

• Using a beam of electrons as its energy source,
  it can magnify structures up to 500,000 X their
  actual size

(a pin head)
5
Transmission electron microscope

• TEM
• studies cellular interiors

Sample of TEM image
6
Scanning electron microscope

• SEM
• studies cellular surfaces

Sample of SEM image
7
The study of cellular structure and function is
called cytology, while the study of cells and
tissues in an organism is called histology.
8
Levels of Organization

• Atom
• Molecule
• Organelles
• Cell
• Tissue
• Organs
• Systems
• Organisms

9
The 10 Organ Systems
10
Anton van Leeuwenhoek

• Mid-1600s
• Holland
• Used hand lens microscope to observe pond water
• Observed microscopic life, called them
  animicules

11
Leeuwenhoek Microscope
12
Robert Hooke
13
Robert Hooke

• Mid-1600s
• England
• Used microscope to observe living tissues
• Named chambers cells

14
Other Early Discoveries

• Dutrochet (early 1800s) first to suggest parts
  of all organisms are made of cells
• Brown in 1831 was the first to realize nearly
  ever cell contains a nucleus
• Dujardin (mid 1800s) used the term sarcode to
  describe protoplasm

15
German cell biologists
1830s Matthias Schleidan concluded all plants
made from cells
1830s Theodor Schwann concluded that all
animals made from cells
16
Rudolph Virchow

• 1855
• Germany
• New cells can only be produced from existing
  cells, confirmed by French scientist Louis Pasteur

17
Cell Theory

• 1) All organisms are composed of one or more
  cells
• 2) The cell is the basic unit of structure and
  function of living things
• 3) All cells come from pre-existing cells

18
To be a cell

• Plasma membrane (cell membrane) made of 2 layers
  of phospholipids
• -controls what enters and leaves cell
• -separates cell from its environment
• Cytoplasm carbohydrate and water based solution
  that suspends all internal parts of the cell
• -transports chemical substances in the cell
• - within the cell, but outside the nucleus

19
To be a cell

• Ribosomes tiny round bodies that produce
  proteins
• DNA genetic material made of nucleic acids
• a) chromatin mass of fibers scattered
• through the nucleus (thread-like)
• b) chromosomes compact chromatin
• -direct store instructions for all
  cell
• functions
• -control inheritance of traits

20
Two types of cells

• Prokaryote bacteria, archaebacteria
• Eukaryote protists, fungi, plants, animals

21
(No Transcript)
22
Prokaryotic cell

• No nucleus
• No membrane bound organelles
• Small
• Simple
• Plasma membrane, ribosomes, cytoplasm, DNA

23
Prokaryotic cell

• Capsule durable outer covering that some
  bacteria have for protection against water,
  acids, and viruses
• Flagella movement
• Cell wall protective layer around plasma
  membrane
• Pili anchoring and DNA exchange

24
Eukaryote

• More complex
• 4 basic components organelles
• Organelles small structures that carry out
  specialized functions within a cell
• Many variations

25
Plasma Membrane

• A flexible boundary between the cell and its
  environment maintains a balance of nutrients, etc
• Selective permeability
• A process in which a membrane allows some
  molecules to pass through while keeping others
  out

26
(No Transcript)
27
Structure of the Plasma membrane

• Phospholipids
• A double layer that creates water-soluble
  outsides surrounding water insoluble insides
• TransporProteins
• Span the entire membrane to regulate which
  molecules enter and which leave

28
(No Transcript)
29
Eukaryotic Cell Structures
30
Nucleus ? cell control

• Chromatin
• Strands of genetic material (DNA) that contains
  the directions for making proteins. Forms
  chromosomes
• Nucleolus
• A prominent body within the nucleus, produces
  granules rich in RNA, each granule will become
  part of a ribosome
• Nuclear Envelope
• Surrounds the nucleus to keep chromatin and
  nucleolus in, while allowing RNA and proteins to
  exit

31
Cytoplasmic Organelles

• Endoplasmic reticulum (Smooth and Rough)
• network of interconnected membranes (ER),
  storage, separation, and transport of substances
  made within the cell
• Smooth no ribosomes
• Rough dotted with ribosomes
• Ribosomes
• Free or bound to the ER, they carry out protein
  synthesis from amino acids

32
Cytoplasmic Organelles

• Golgi apparatus
• A flattened stack of membranes that packages
  proteins into vesicles to be secreted by the cell
• Like a Post office or UPS.

33
Cytoplasmic Organelles

• Vacuoles
• Membrane-bound compartments for temporary storage
  of materials
• May be very large in plant cells

34
Cytoplasmic Organelles

• Lysosomes
• Small bodies filled with digestive enzymes that
  digest worn-out organelles, food particles, and
  even engulfed bacteria
• Responsible for the cells recycling of materials

35
Cytoplasmic Organelles

• Chloroplasts
• Containing the green pigment, chlorophyll, these
  oval bodies capture light energy and turn it into
  chemical energy (photosynthesis)

36
Cytoplasmic Organelles

• Mitochondria
• Rod-shaped organelle with many inner folds, which
  breaks down sugar to release its stored energy
  for cell use (cell respiration)
• Powerhouse of the cell

37
Cytoplasmic Organelles

• Cytoskeleton
• Tiny rods and filaments (called microtubules and
  microfilaments) that form a supporting framework
  for the cell and function in cytoplasmic streaming

38
Cytoplasmic Organelles

• Centrioles
• Pairs of clustered microtubules that play an
  important role in cell division

39
Cytoplasmic Organelles

• Cilia Flagella
• External microtubules that aid the cell in
  locomotion or feeding

40
Prokaryotic cell

• No nucleus
• No membrane bound organelles
• Small
• Simple
• Plasma membrane, ribosomes, cytoplasm, DNA

41
Plant and Animal Cell Similarities

• Cell membrane that surrounds the cell
• Cytoplasm
• Nucleus that houses DNA
• Ribosomes for protein production
• Mitochondria that breaks down food and releases
  energy for the cell.
• Vacuoles for storage of food, water, and waste.
  Plants have one large vacuole and animals have
  many small vacuoles.
• Endoplasmic Reticulum (ER)
• Golgi bodies

42
Differences in Plant and Animal Cells

• Plants contain a cell wall that surrounds the
  cell membrane and provides shape and support.
• Plants contain chloroplasts for photosynthesis
• Plant cells have a brick-like shape where as
  animal cells are more spherical.
• Plants use chloroplasts to store energy in
  glucose.
• Plants have one large vacuole animals have many
  small vacuoles.
