Making B -Trees Cache Conscious in Main Memory

1
Making B-Trees Cache Conscious in Main Memory

• AuthorJun Rao, Kenneth A. Ross

Members Iris Zhang, Grace Yung, Kara Kwon,
Jessica Wong
2
Outline

• 1. Introduction
• 2. Related Work
• 3. Cache Sensitive B-Trees
• 4. Conclusion

3
Motivation

• Significant portion of execution time
• second level data cache misses
• first level instruction cache misses

System Hierarchy
4
Motivation (Contd)

• 2. CPU speeds have been increasing at a much
  faster rate than memory speeds

• Conclusion improving cache behavior is going to
  be an imperative task in main memory data
  processing
• Resolution using memory index structure

5
Cache Memories
Cache memories are small fast static RAM memories
that improve performance by holding recently
referenced data.

• Parameter
• Capacity
• Block Size (cache line)
• Associativity

• Memory reference
• Hit
• Miss

6
Cache Optimization on Index StructuresB-Trees

• Height-balanced tree
• Minimum 50 occupancy (except for root). Each
  node contains d lt m lt 2d entries. The
  parameter d is called the order of the tree.
  (n2d)
• Each node is 1 cache line (cache-line based)
• Full pointer

B-Tree (n 2)
7
Cache Optimization on Index StructuresCSS-Trees

• Similar as B-tree
• Eliminating child pointers
• Storing child nodes in a fixed sized array.
• Nodes are numbered stored level by level, left
  to right.
• Position of child node can be calculated via
  arithmetic.
• No pointer

CSS-Tree
8
Comparison between B-Trees and CSS-Trees

• Cache Line Size12 bytes, Key SizePointer Size4
  bytes
• Search key 3
• B-Tree CSS-Tree

9
Comparison between B-Trees and CSS-Trees(contd)

• B tree
• full pointer
• more cache access and more cache misses
• efficient for updating operation, e.g. insertion
  and deletion

• CSS tree
• no pointer
• fewer cache access and fewer cache misses
• acceptable for static data updated in batches

Conclusion partial pointer elimination
10
Cache Sensitive B-Trees

1. Cache Sensitive B-Trees with One Child Pointer
2. Segmented CSB-Trees
3. Full CSB-Trees

11
Cache Sensitive B-Trees with One Pointer

• Similar as B-tree
• All the child nodes of any given node are put
  into a node group with one pointer
• Nodes within a node group are stored continuously
  and can be accessed using an offset to the first
  node in the group

12
Cache Sensitive B-Trees with One Pointer (contd)

• Cache misses are reduced because a cache line can
  hold more keys than B-Trees and can satisfy one
  more level comparison.
• CSB-Tree can support incremental updates in a
  way similar to B-Tree

Cache Line Size64 bytes, Key SizePointer Size4
bytes B-Tree 7 keys per node CSB-Tree 14 keys
per node
13
Operations on CSB-TreeBulkload
14
Operations on CSB-Tree Insertion

• Search the leaf node n to insert the new entry
• If n is not full, insert the new entry in the
  appropriate place
• Otherwise, split n. Let p be n parent node, f be
  the first-child pointer in p and g be the
  node-group pointed by f
• If p is not full, copy g to g' in which n is
  split in two nodes. Let f point to g'
• If p is full, copy half g to g'. Let f point to
  g'. Split the node-group of p according to step a

15
Operations on CSB-Tree Insertion (contd)
22
key 34
23 57 1213 1619 2022 2425 2730
3133 3639
a CSB-Tree of Order 1
16
Operations on CSB-Tree Insertion (contd)
22
key 34
25 3336
23 57 1213 1619 2022 2425 2730
3133 3436 39
17
Operations on CSB-TreeSearch

• Determine the rightmost key K in the node that is
  smaller than the search key
• Get the address of the child node
• Goto first step until find the search key or
  there is no other node can be checked
• Search method in a node
• basic approach uniform approach variable
  approach

18
Segmented Cache Sensitive B-Trees

• Problem its time consuming to split a node
  group
• ResolutionSCSB-Tree
• method divide node group into two segments with
  one child pointer per segment
• result better split performance, but worse search

19
Full CSB-Tree

• Motivation reduce the split cost
• Method
• pre-allocate space for a full node group
• shift part of the node group along by one node
  when a node split
• Result
• reduce the split cost, but increase the space
  complexity

20
Conclusion

• CSB-Trees are more cache conscious than B-Tree
  because of partial pointer elimination
• CSB-Trees support efficient incremental updates,
  but CSS-Trees do not
• Partial pointer elimination is a general
  technique which can be applied to other memory
  structures
