Respirators and Dust Hazards

1
Respirators andDust Hazards
2
Introduction

• What is Dust?
• How is Dust generated?
• What types of Dust are there?
• Why is Dust Control necessary?
• What are the Health Hazards of Dust?
• How can Dust be controlled?

3
What is Dust?

• One Micron-Size Dust Particle
• on a Pin Head

4
How is Fresh Dust Generated?

• When Ore is Broken by
• Impact
• Abrasion
• Crushing
• Grinding
• What ore sizing equipment do you have at your
  work site?

5
How is Dust Recirculated?

• Release of previously generated dust during such
  processing operations as
• Loading
• Dumping
• Transferring
• What types of Loading, Dumping, or Transferring
  Equipment do you have?

6
How is Dust Recirculated?

• Also, dust can be recirculated by
• Wind
• Movement of Workers
• Movement of Equipment
• What activities or conditions kick up dust at
  your mine?

7
Dust Classification

• Fibrogenic Dust (Causes Disease)
• Crystalline Silica (Quartz)
• Asbestos
• Beryllium
• Nuisance Dust - Dust that does not contain
  harmful quantities of asbestos less than 1
  quartz.

8
Dust Classification by Size

• Dust is classified by size into two primary
  categories.
• Respirable Dust
• Inhalable Dust

9
Inhaleable Dust

• Dust that enters the body, but is trapped in the
  nose, throat, and upper respiratory tract.

10
Respirable Dust

• Dust particles small enough (less than 10
  Microns) to penetrate past the upper respiratory
  tract and deep into the lungs.

Percent of Particles going deep into the Lungs
11
Dust the Respiratory System
Human Respiratory System
12
Why Control Dust?

• Health Hazards
• Occupational respiratory diseases
• Irritation to eyes, nose, throat
• Skin irritation
• Damage to Equipment
• Impaired Visibility
• Community Relations
• Can you think of other reasons?

13
Health Hazards

• The harm Dust can cause depends on the following
• Dust Composition
• Dust Concentration
• Particle Size and Shape
• Amount of Exposure Time
• Excessive exposure to harmful dusts can cause
  Pneumoconiosis - a dust related lung disease.

14
Dust Related Deaths in Mich.

• 1,426 deaths occurred from dust-related lung
  diseases in Michigan from 1968 to 1991.

Information from NIOSHs StateProfiles/Michigan
Internet Web Site http//www.cdc.gov/niosh/mi.htm
l
15
Dust Related Lung Diseases

• Silicosis
• Caused by Silica Dust
• Black Lung
• Caused by Coal Dust
• Asbestosis
• Caused by Asbestos Dust
• Damage from these diseases is irreversible!

16
Controling Dust Exposure - Safer Machinery
Tools

• Fully enclosing dusty processes.
• Local exhaust ventilation/dust collection
  equipment.
• Tools with dust extraction (vacuum) devices.
• Using water to suppress dust.
• Operator enclosures with an air filtration
  system.
• Use abrasives other than sand for abrasive
  blasting.

17
Dust Control Systems
18
Dust Control Systems
19
Controling Dust Exposure - Safe Work Procedures

• Wetting down dusty work areas or processes prior
  to work.
• Working upwind of dust sources where possible.
• Posting warning Signs where necessary.
• Limiting Exposure time.
• Training all employees on appropriate work
  procedures.
• Good housekeeping practices.

20
Controling Dust Exposure - Respiratory Protection

• Fit testing of all employees required to wear
  respiratory devices.
• Training employees in the proper use of
  respiratory devices.
• Making sure employees understand the hazards of
  dust and the importance of respirator use.
• Regular checking and cleaning of non-disposable
  respirators.

21
Reasons for Repirators?

• Certain Breathing conditions are hazardous to
  life and lung.
• The air can be contaminated with
• Dusts, Mists, Fumes
• Toxic Vapors
• The air can have too little oxygen.

22
How do we control these Airborne Hazards?

• First - Use Engineering Controls to eliminate the
  hazard.
• Second - Use Administrative Controls to reduce
  exposure to the hazard.
• Last - Use Respirators as a temporary protective
  measure until Engineering and Administrative
  Controls are in place.

23
2 Basic Types of Respirators

• Air Purifying Respirators
• Used to filter out or neutralize contaminants
• Examples Dust Organic Vapor
• Air Supply Respirators
• Used when there is a lack of oxygen, when the
  hazard is unknown or is undetectable by smell or
  taste.
• Examples Compressor Hose SCBA

24
Filtering Respirators

• Particulates - Dusts, Mists Fumes
• New Classes N, R, P 95, 99, 100
• Non-Resistant(Oil), Resistant(Oil), (Oil) Proof
• Toxins - Organics, Acids, etc.
• Neutralizing or Absorbing
• Filtering Respirators are Hazard Specific
• Dont expect one respirator to protect you from
  all hazards!

25
How long do Respirators last?

• Particulate (Dust) Filtering Respirators
• Change them when the breathing resistance gets
  high.
• Toxin Filtering Respirators
• Change when you first smell or taste a
  contaminant (Break-through)

26
Health Conditions that Interfere with Respirator
Use

• Heart Conditions
• Asthma or other breathing problem
• Claustrophobia (fear of enclosed space)
• Missing Teeth

27
Other Conditions that can Interfere with
Respirator Use

• Contact Lenses
• Eyeglass Temples (certain types)
• Skullcaps (Beanies)

28
Respirators Used at Your Workplace

• How to don your respirator.
• Look at the manufacturers instructions.
• How to clean Maintain your respirator.
• Look at the manufacturers instructions.
• How to Self-Fit Test your respirator.
• Not possible with Filter-Face Types
• Look at the manufacturers instructions.

29
Quiz

• Silicosis is a disease whose effects can be
  reversed, given time.
• True
• False

30
Quiz

• Dust respirator masks are not the preferred
  protection from dust because
• A. They can leak if not fitted properly.
• B. They are uncomfortable to wear.
• C. They cost very little.
• D. Both A B
