Herbicide Mode of Action

1
Herbicide Mode of Action

• Cecil Tharp, MSU Pesticide Education Specialist

2
Do you know what mode of action means?

1. Yes
2. No
3. Maybe

3
Do you know the mode of action of all pesticides
you use?

1. Yes
2. No

4
What is the mode of action?
5
Mode of Action

• Sequence of events from absorption into the plant
  until the plant dies
• Systemic herbicides translocated from site of
  entry to area in plant where they are active.
  Glyphosate
• Contact herbicides - kill only the area where
  they are applied. Paraquat

6
(No Transcript)
7
Further Break Down into Groups

• Weed Science Society of America has classified
  all modes of action into groups.
• These groups are usually on the pesticide product
  label. This is for Milestone.

8
What does a group 4 mode of action mean?

• Use the handouts available.
• This would be a growth regulator herbicide or a
  synthetic auxin herbicide.
• Causes abnormal growth, extended leaf terminals,
  curled leaves and eventual death
• These target broadleaf weeds
• Many products including 2,4-D, dicamba, picloram,
  clopyralid, aminopyralid, aminocyclopyraclor,
  milestone etc.

9
Common Leaf Symptoms from PGR Exposure
normal
cupped and blistered from PGR exposure
10
We have many modes of action

• ACCase inhibitors (Group 1)
• Inhibit ACCase enzyme in grasses. Stunting,
  browning of grasses,
• Used primarily in broadleaf crops
• Some may be used to selectively control grasses
  in grass crops.
• Poast, Puma, Select
• Sethoxydim, clethodim, fenoxaprop

11
Aromatic Amino Acid Synthesis Inhibitors

• Group 9.
• Glyphosate
• Inhibits amino acid synthesis.
• Slow process that may take weeks.
• Broadspectrum, yellowing of plants, stunting

12
Plateau or Escort Injury Symptoms
Stunting
Chlorosis of youngest tissue
13
ALS Inhibitors

• Inhibit amino acid synthesis
• Sulfonylurea herbicides
• Vulnerable to low pH conditions
• Also imazapic, imazamox, imazethapyr
• Resistance and cross-resistance is common.
• Targets a wide variety of grasses and broadleafs
  while protecting crops (selective read label)

14
(No Transcript)
15
Do you mix your modes of action?

1. Consistently
2. Occasionally
3. Never

16
Who Cares?

• Why do we need to group our modes of action?

17
Plants, Diseases and Insects often develop
resistance to modes of action.
18
(No Transcript)
19
(No Transcript)
20
History of Weed Resistance

• The first reported case of herbicide resistance
  in the United States was reported in the 1950s.
  Field bindweed resistant to 2,4-D was reported in
  Kansas in 1964.
• The greatest number has been observed with the
  ALS inhibitors (imidazolinones,
  pyrimidinylthiobenzoates, sulfonylureas,
  triazolopyrimidines).
• 25 herbicide families have confirmed resistance
  to various weeds.

21
Glyphosate No Longer Effective in Managing Kochia

• From 1984 2013
• Resistant to
• Photo-System II 5 (atrazine)
• ALS Inhibitors 2 (chlorsulfuron, etc.)
• Sythentic Auxin 1 (dicamba, fluroxypyr)
• EPSP Synthase Inhibitor 9 (glyphosate)

22
Wild Oat Resistance

• Cell elongation inhibitors (8)
• Lipid inibitors (8)
• Thiocarbanates
• Difenzoquat
• ALS Inhibitors (2)
• Imazamethabenz methyl
• ACCASE inhibitors (1)
• Clodinafop
• Diclopop-methyl
• Tralkoxydim

23
Resistance to Persian Darnel, Green Foxtail and

• Persian Darnel
• ACCASE inhibitors (1)
• Diclofop-methyl
• Green Foxtail
• ACCase inhibitors (1)
• Diclofop-methyl
• Sethoxydim
• Horseweed
• EPSP synthase inhibitors (9)
• Glyphosate

24
How does the plant develop resistance?
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
How can you combat resistance?

• Mix modes of action from application to
  application
• Dont stay with only one mode of action
• Or use multiple modes of action in a tank mix
• Some pesticide products already deliver multiple
  modes of action
• Use highest rates
• Use multiple control tactics or integrated pest
  management.

29
Are there other reasons to combine modes of
action?
30
Tank Mixing Multiple Products

• Can cause unexpected outcomes
• Enhancement
• Increases efficacy by adding adjuvants
• Synergism
• By combining chemicals increased efficacy of
  either product is achieved
• Antagonism
• Efficacy is lowered by combining the chemicals
• Incompatabilities
• 2,4-D and glyphosate in hard water situations

31
Common Mixing Issues

• WPs and ECs they can form a putty or paste with
  an oily layer that floats on the top of the tank.

• Many physical incompatibility problems
• Combinations of pesticides (ECs, for
• example) are mixed with liquid fertilizers.
• A few pesticides are available in special
  fertilizer-grade formulations that reduce
  incompatibility problems.
• Some poor mixtures result in lower efficacy from
  water issues.

32
Alkaline hydrolysis High pH Water

• Dissociation is the breaking down of a complex
  molecule into simpler units.
• Efficacy often goes down when molecules are
  dissociated. Plants often wont absorb the
  chemical as well. At times this may totally
  inactivate the pesticide.
• pH 6 7 is ideal for most pesticides but it can
  vary.
• Weak Acid Herbicides are the most susceptible to
  alkaline (high ph) dissociation
• Roundup (glyphosate)
• Pursuit (ammonium salt of imazethapyr)
• Liberty (glufosinate ammonium).
• 2-4D salt

33
Hardness of Solution Can Cause Problems in Tank
Mixes

• Hardness is the concentration of multi-valent
  cations (positively charged ions from minerals)
• Cations bind with negatively charged pesticide
  molecules
• pH and hardness work together to reduce efficacy
• Forms insoluble salts

34
When is it a problem?

• If the sum of the concentration (ppm) for the
  cations exceeds 150 ppm action should be
  considered
• 2,4-D amine (gt 150 ppm)
• totally deactivated at 500 ppm)
• Dicamba (gt 150 ppm)
• Glyphosate (gt 150 ppm)
• Clopyralid (gt150 ppm)
• sethoxydim Poast (gt150 ppm)
• Imazethapyr Pursuit (gt150 ppm)
• Reduces efficacy of many
• surfactants
• Scale may plug sprayer

35
If you have a problem

• Add an adjuvant containing sulfate or organic
  acids as they bind with hard minerals
• non-ionic surfactants increase efficacy
• Add ammonium sulfate (8.5 17 lb / 100 gallons)

36
Prior to tank mixing

• Read the pesticide product label on compatibility
  issues or recommended tank mixes.
• Call your product manufacturer for more
  information prior to mixing.
• Last Resort Can perform a jar test
• Check for heat, gumming, foam and scum

37
Order of Mixing

• Always consult the label of each product for
  product-specific mixing instructions
• 1. Fill the tank ¼ to ½ with carrier and
  begin agitation
• 2. Add compatability or defoaming agents if
  needed
• 3. Pesticides, in the order of WP, DF, WDG,
  F, FL, ME, EC, S, SP
• 4. Crop oils or surfactants

38
Do you know what mode of action means?

1. Yes
2. No
3. Maybe

39
Do you know the mode of action of pesticides you
use?

1. Yes
2. No

40
Do you mix your modes of action?

1. Consistently
2. Occasionally
3. Never

41
Thanks

• Cecil Tharp
• Montana State University
• Bozeman, Montana
• [phone]
• ctharp_at_montana.edu
