Collision Avoidance Procedures

1
Collision Avoidance Procedures

• Soaring Safety Foundation
• Flight Instructor Refresher Clinic
• Rich Carlson

2
Sharing Airspace
3
(No Transcript)
4
Regulations

• FAR 91.113 (b)
• Regardless of IFR or VFR all pilots will
  observe See and Avoid procedures
• Advisory Circular 90-48C
• Pilots role in collision avoidance
• AIM Section 4-4-13 (d)
• Describes effective scanning techniques

5
See and Avoid

• Basic Concept
• Look outside and avoid running into other
  aircraft!

6
See and Avoid

• Advantages
• Uses Mark I human eyeball
• Low regulatory overhead
• Limitations
• Pilot must recognize hazard and take action

7
Mark I Eyeball
Supplement Page 8
8
Problems

• Physiological issues
• Blind spot
• Empty Field Myopia
• Physical obstructions
• Seat location
• Canopy rails
• Instruments

9
Visual Scanning

• Peripheral vision detects motion
• Foveal vision identifies objects
• Proper scanning procedures
• Use multiple sectors (10 deg)
• Stop in each sector for a second or 2
• Focus on distant object

10
Known Hazardous Areas

• General areas
• Near VORs
• In and around Class D, C, and B airspace
• Near victor airways
• Within 5 miles and 3000 ft of an airport

11
Known Hazardous Areas

• Glider Specific
• Thermals
• Start/Finish Gate
• Turnpoints
• Ridge line
• Others

12
Aircraft Markings

• Anti-collision markings
• A study by the OSTIV TSP found that high
  visibility color (Safety Orange) reduced the
  visibility of a glider
• Highly reflective mirror tape did a much better
  job

13
Visual Perception

• The blocks on the lower left mark the danger area
  for the speeds quoted, when aircraft are on a
  collision course. This danger area is based on
  the recognition and reaction time shown in the
  table on the lower right.
• From AC 90-48C

14
Reaction time in seconds
15
Visual Perception

• Move back 12 feet from this illustration. From
  that position the silhouettes represent a T-33
  aircraft as it would appear to you from the
  distances indicated in the table on the left.
  The time required to cover these distances is
  given in seconds for a combined speed of 360 and
  600 mph.
• From AC 90-48C

16
(No Transcript)
17
Is a collision imminent?
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Position Reporting

• Where am I
• Where are you
• Aids to position reporting
• GPS distance/bearing
• Altitude
• Known ground reference

28
Electronic Aids

• Radios
• Transponders
• Operation limitations
• Glider only codes

29
Portable Collision Avoidance Boxes
PCAS - XRX
PCAS - MRX
http//www.zaonflight.com/
30
Situational Awareness

• Whats happening now
• Whats going to happen next
• Whats going to happen soon
• Whats he going to do

31
12 Action Items from Jim Shorts Airspace in the
New Century

• Prominent posting of airline arrival/departure
  routes and expected altitudes
• Post NOTAMs for meets and contests
• Define local areas that are relatively safe
• Voluntarily avoid high risk areas
• Increase our personal vigilance at critical
  altitudes
• Consider a Mode C transponder
• Supplement Page 7

32
Summary

• Remember most mid-airs and near mid-airs occur
  during the day, in VFR conditions, close to an
  airport
• See and Avoid procedures need to be taught

33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
